Numerical Implementation of a Hydro-Mechanical Coupling Constitutive Model for Unsaturated Soil Considering the Effect of Micro-Pore Structure
Abstract
:1. Introduction
2. Modified Glasgow Coupled Model (MGCM) Overview
2.1. Effective Degree of Saturation Considering the Influence of the Microscopic Pore Structure
2.2. Constitutive Variables
2.3. Yield Curves
2.4. Hardening Law
2.5. Flow Rule
2.6. Stress–Strain Relationship
3. Fortran Program Prediction and Validation
4. Numerical Implementation
4.1. Solid-Phase and Liquid-Phase Yield Equations
4.2. Matrix Form Stress–Strain Relation
4.3. Implicit Integration Algorithm
5. Model Validation
6. Conclusions
