Strengthening Mechanisms in Nickel-Copper Alloys: A Review
Abstract
:1. Introduction
2. Role of Alloying Elements
3. Microstructure
4. Strengthening Mechanisms
4.1. Grain Refinement
4.2. Solid Solution Strengthening
4.3. Precipitation Strengthening
4.4. Dislocation Strengthening (Work Hardening)
5. Mechanical Properties
6. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
- Waite, J.G.; Look, D.; Gayle, M. Metals in America’s Historic Buildings: Uses and Preservation Treatments; US Department of the Interior, National Park Service, Cultural Resources: Washington, DC, USA, 1995. [Google Scholar]
- Lippold, J.C.; DuPont, J.; Kiser, S.D. Alloying Additions, Phase Diagrams and Phase Stability. In Welding Metallurgy and Weldability of Nickel-Base Alloys; John Wiley & Sons: Hoboken, NJ, USA, 2009; Chapter 2; pp. 15–45. [Google Scholar]
- Czajkowski, C.; Butters, M. Investigation in Hardsurfacing a Nickel-Copper Alloy (Monel400); Report BNL-52651; Brookhaven National Laboratory: Upton, NY, USA, 2001.
- Heckel, R.W.; Rickets, J.H.; Buchwald, J. Measurement of the degree of segregation in Monel 400 weld metal by X-ray line broadening. Weld. J. 1965, 34, 332–336. [Google Scholar]
- Doherty, R.D.; Feest, E.A.; Holm, K. Dendritic solidification of Cu-Ni alloys: Part I. Initial growth of dendrite structure. Metall. Mater. Trans. A 1973, 4, 115–124. [Google Scholar] [CrossRef]
- Dundar, S. Dendritic solidication in a copper nickel alloy. Turkish J. Eng. Env. Sci. 2004, 28, 129–134. [Google Scholar]
- Algoso, P.; Hofmeister, W.; Bayuzick, R. Solidification velocity of undercooled Ni–Cu alloys. Acta Mater. 2003, 51, 4307–4318. [Google Scholar] [CrossRef]
- Hou, H.; Li, Y.; Xu, X.; Zhao, Y.; Liu, F. Non-equilibrium effects on solid transition of solidification microstructure of deeply undercooled alloys. Mater. Sci. Technol. 2017, 34, 402–407. [Google Scholar] [CrossRef]
- Arjmand, M.; Abbasi, S.; Taheri, A.K.; Momeni, A. Hot workability of cast and wrought Ni–42Cu alloy through hot tensile and compression tests. Trans. Nonferrous Met. Soc. China 2016, 26, 1589–1597. [Google Scholar] [CrossRef]
- Ebrahimi, G.R.; Momeni, A.; Ezatpour, H.; Jahazi, M.; Bocher, P. Dynamic recrystallization in Monel400 Ni-Cu alloy: Mechanism and role of twinning. Mater. Sci. Eng. A 2019, 744, 376–385. [Google Scholar] [CrossRef]
- Es-Said, O.; Zakharia, K.; Ventura, C.; Pfost, D.; Crawford, P.; Ward, T.; Raizk, D.; Foyos, J.; Marloth, R.; Zakharia, Z. Failure analysis of K-monel 500 (Ni–Cu–Al alloy) bolts. Eng. Fail. Anal. 2000, 7, 323–332. [Google Scholar] [CrossRef]
- Harris, Z.D.; Burns, J.T. The effect of isothermal heat treatment on hydrogen environment-assisted cracking susceptibility in Monel K-500. Mater. Sci. Eng. A 2019, 764, 138249. [Google Scholar] [CrossRef]
- Ramkumar, K.D.; Joshi, V.; Pandit, S.; Agrawal, M.; Kumar, O.S.; Periwal, S.; Manikandan, M.; Arivazhagan, N. Investigations on the microstructure and mechanical properties of multi-pass pulsed current gas tungsten arc weldments of Monel 400 and Hastelloy C276. Mater. Des. 2014, 64, 775–782. [Google Scholar] [CrossRef]
- Mani, C.; Karthikeyan, R.; Kannan, S.; Periasamy, C. Optimization of tensile properties of 316L stainless steel and Monel 400 weld joints using genetic algorithm. Mater. Today: Proc. 2020, 27, 2846–2851. [Google Scholar] [CrossRef]
- Heidarzadeh, A.; Chabok, A.; Pei, Y. Friction stir welding of Monel alloy at different heat input conditions: Microstructural mechanisms and tensile behavior. Mater. Lett. 2019, 245, 94–97. [Google Scholar] [CrossRef] [Green Version]
- Available online: https://markets.businessinsider.com/commodities/nickel-price (accessed on 21 August 2020).
- Available online: https://www.fastmarkets.com/commodities/exchange-data/lme-base-metal-prices-and-charts (accessed on 21 August 2020).
- Available online: https://www.superiorsteel.in/blog/monel-alloy-400-k500-price-list (accessed on 21 August 2020).
- Davis, J.R. Introduction to Nickel and Nickel Alloys. In Nickel, Cobalt, and Their Alloys; ASM Specialty Handbook; ASM International: Materials Park, OH, USA, 2000; Chapter 1. [Google Scholar]
- High-Performance Alloys for Resistance to Aqueous Corrosion, Special Metals Corporation, Publication Number SMC-026. 2000. Available online: https://www.scribd.com/document/55871734/Nickel-Base (accessed on 27 August 2020).
- Stoloff, N.S. Wrought and P/M superalloys. In Properties and Selection: Irons, Steels, and High-Performance Alloys; ASM Handbook; ASM International: Materials Park, OH, USA, 1990; Volume 1, pp. 950–980. [Google Scholar]
- Lippold, J.C.; DuPont, J.; Kiser, S.D. Precipitation-Strengthened Nickel-Base Alloys. In Welding Metallurgy and Weldability of Nickel-Base Alloys; John Wiley & Sons: Hoboken, NJ, USA, 2009; Chapter 4; pp. 157–254. [Google Scholar]
- Monel Alloy 400, High Performance Alloys. Available online: http://www.hpalloy.com (accessed on 27 August 2020).
- Health Hazard Evaluation Report: HETA-97-0141-2819; Special Metals Corporation, Princeton Powder Division: Princeton, KY, USA, 2001.
- Monel Alloy R-405, High Performance Alloys. Available online: http://www.hpalloy.com (accessed on 27 August 2020).
- Dutta, R. Corrosion aspects of Ni–Cr–Fe based and Ni–Cu based steam generator tube materials. J. Nucl. Mater. 2009, 393, 343–349. [Google Scholar] [CrossRef]
- Prabhu, A.G.; Sathishkumar, N.; Pravinkumar, K.; Kumar, P.M.; Balasubramanian, T.; Sudharsan, P. Heat treatment and analysis of nickel super alloy for gas turbine applications. Mater. Today Proc. 2020. [Google Scholar] [CrossRef]
- Ghosh, S.; Dey, G.; Dusane, R.; Grover, A. Improved pitting corrosion behaviour of electrodeposited nanocrystalline Ni–Cu alloys in 3.0wt.% NaCl solution. J. Alloy. Compd. 2006, 426, 235–243. [Google Scholar] [CrossRef]
- Silaimani, S.M.; Vivekanandan, G.; Veeramani, P. Nano-nickel–copper alloy deposit for improved corrosion resistance in marine environment. Int. J. Environ. Sci. Technol. 2014, 12, 2299–2306. [Google Scholar] [CrossRef]
- Monel Alloy 401; Publication SMC-084; Special Metals Corporation: New Hartford, NY, USA, 2004.
- Monel Alloy 404; Publication SMC-059; Special Metals Corporation: New Hartford, NY, USA, 2004.
- Nady, H.; Negem, M. Ni–Cu nano-crystalline alloys for efficient electrochemical hydrogen production in acid water. RSC Adv. 2016, 6, 51111–51119. [Google Scholar] [CrossRef]
- Wang, G.; Li, W.; Huang, B.; Xiao, L.; Lu, J.; Zhuang, L. Exploring the composition—Activity relation of Ni–Cu binary alloy electrocatalysts for hydrogen oxidation reaction in alkaline media. ACS Appl. Energy Mater. 2019, 2, 3160–3165. [Google Scholar] [CrossRef]
- Brooks, R.B. Heat Treatment, Structure and Properties of Nonferrous Alloys; ASM international: Materials Park, OH, USA, 1982. [Google Scholar]
- Roth, H.A.; Davis, C.L.; Thomson, R. Modeling solid solution strengthening in nickel alloys. Metall. Mater. Trans. A 1997, 28, 1329–1335. [Google Scholar] [CrossRef]
- Kako, K.; Kawakami, E.; Ohta, J.; Mayuzumi, M. Effects of various alloying elements on tensile properties of high purity Fe-18Cr-(14-16)Ni alloys at room temperature. Mater. Trans. 2002, 43, 155–162. [Google Scholar] [CrossRef]
- Shang, S.L.; Kim, D.E.; Zacherl, C.L.; Wang, Y.; Du, Y.; Liu, Z.K. Effects of alloying elements and temperature on the elastic properties of dilute Ni-base superalloys from first-principles calculations. J. Appl. Phys. 2012, 112, 053515. [Google Scholar] [CrossRef]
- Pathak, A.; Singh, A.K. Mechanical properties of Ni-based solid solution alloys: A first principles study. J. Appl. Res. Technol. 2017, 15, 449–453. [Google Scholar] [CrossRef]
- Hargather, C.Z.; Shang, S.-L.; Liu, Z.-K. A comprehensive first-principles study of solute elements in dilute Ni alloys: Diffusion coefficients and their implications to tailor creep rate. Acta Mater. 2018, 157, 126–141. [Google Scholar] [CrossRef]
- Yang, Z.-B.; Sun, J.; Lu, S.; Vitos, L. Assessing elastic property and solid-solution strengthening of binary Ni–Co, Ni–Cr, and ternary Ni–Co–Cr alloys from first-principles theory. J. Mater. Res. 2018, 33, 2763–2774. [Google Scholar] [CrossRef]
- Al-Jarba, K.A.; Fuchs, G.E. Carbon-containing single-crystal nickel-based superalloys: Segregation behavior and carbide formation. JOM 2004, 56, 50–55. [Google Scholar] [CrossRef]
- He, L.Z.; Zheng, Q.; Sun, X.F.; Hou, G.C.; Guan, H.R.; Hu, Z.Q. M23C6 precipitation behavior in a Ni-base superalloy M963. J. Mater. Sci. 2005, 40, 2959–2964. [Google Scholar] [CrossRef]
- Dong, X.; Zhang, X.; Du, K.; Zhou, Y.; Jin, T.; Ye, H. Microstructure of carbides at grain boundaries in nickel-based superalloys. J. Mater. Sci. Technol. 2012, 28, 1031–1038. [Google Scholar] [CrossRef]
- Kontis, P.; Kostka, A.; Raabe, D.; Gault, B. Influence of composition and precipitation evolution on damage at grain boundaries in a crept polycrystalline Ni-based superalloy. Acta Mater. 2019, 166, 158–167. [Google Scholar] [CrossRef] [Green Version]
- Liu, T.; Yang, M.; Han, F.; Dong, J. Influence mechanism of silicon on carbide phase precipitation of a corrosion resistance nickel-based superalloy. Materials 2020, 13, 959. [Google Scholar] [CrossRef] [Green Version]
- Kozar, R.; Suzuki, A.; Milligan, W.; Schirra, J.; Savage, M.; Pollock, T. Strengthening mechanisms in polycrystalline multimodal nickel-base superalloys. Metall. Mater. Trans. A 2009, 40, 1588–1603. [Google Scholar] [CrossRef]
- Dai, P.; Zhang, C.; Wen, J.C.; Rao, H.C.; Wang, Q.T. Tensile Properties of Electrodeposited Nanocrystalline Ni-Cu Alloys. J. Mater. Eng. Perform. 2016, 25, 594–600. [Google Scholar] [CrossRef]
- Ross, E.W.; Sims, C.T. Nickel-Base Alloys. In Superalloys IIHigh Temperature Materials for Aerospace and Industrial Power; Sims, C.T., Stoloff, N.S., Hagel, W.C., Eds.; Wiley: New York, NY, USA, 1987; pp. 97–133. [Google Scholar]
- Dey, G.; Mukhopadhyay, P. Precipitation in the NiCu-base alloy monel K-500. Mater. Sci. Eng. 1986, 84, 177–189. [Google Scholar] [CrossRef]
- Barbosa, C.; Nascimento, J.; Caminha, I.; Abud, I. Microstructural aspects of the failure analysis of nickel base superalloys components. Eng. Fail. Anal. 2005, 12, 348–361. [Google Scholar] [CrossRef]
- Krishna Reddy, L. Principles of Engineering Metallurgy; New Age International: New Delhi, India, 2007. [Google Scholar]
- Monel Alloy R-405; Publication SMC-085; Special Metals Corporation: New Hartford, NY, USA, 2004.
- Monel Alloy K-500; Publication SMC-062; Special Metals Corporation: New Hartford, NY, USA, 2004.
- Hurlbatt, J.D. Hot rolling of sheet: Nickel-based alloys. Met. Technol. 1975, 2, 326–330. [Google Scholar] [CrossRef]
- Guinier, A.; Lorrain, P.; Lorrain, D.S.M.; Gillis, J. X-Ray diffraction in crystals, imperfect crystals, and amorphous bodies. Phys. Today 1964, 17, 70. [Google Scholar] [CrossRef] [Green Version]
- Product Handbook of High Performance Ni Alloys, Special Metals Corporation. Available online: www.specialmetals.com (accessed on 27 August 2020). Special Metals Corporation.
- Fabrication of Nickel Alloys, Bulletin, Special Metals Corporation. Available online: www.specialmetals.com (accessed on 27 August 2020).
- Ai, J.-H.; Ha, H.M.; Gangloff, R.P.; Scully, J.R. Hydrogen diffusion and trapping in a precipitation-hardened nickel–copper–aluminum alloy Monel K-500 (UNS N05500). Acta Mater. 2013, 61, 3186–3199. [Google Scholar] [CrossRef]
- George, E.P.; Liu, C.T. Alloy Design of Ordered Intermetallics. In MRS Proceedings; Cambridge University Press (CUP): Cambridge, UK, 1990; Volume 186, pp. 913–942. [Google Scholar]
- Lifshitz, I.; Slyozov, V. The kinetics of precipitation from supersaturated solid solutions. J. Phys. Chem. Solids 1961, 19, 35–50. [Google Scholar] [CrossRef]
- Liu, C.; Li, Y.; Zhu, L.; Shi, S. Effect of coherent lattice mismatch on the morphology and kinetics of ordered precipitates. J. Mater. Eng. Perform. 2018, 27, 4968–4977. [Google Scholar] [CrossRef]
- Baker, H. (Ed.) Alloy. Phase Diagrams; ASM International: Materials Park, OH, USA, 1992. [Google Scholar]
- Sims, C.T. Cobalt-base alloys. In The Superalloys; Sims, C.T., Hagel, W.C., Eds.; John Wiley & Sons: New York, NY, USA, 1972; pp. 145–174. [Google Scholar]
- Ardell, A.J.; Nicholson, R.B.; Eshelby, J.D. On the modulated structure of aged Ni-Al alloys (with an appendix on the elastic interaction between inclusions). Acta Metall. 1966, 14, 1295–1309. [Google Scholar] [CrossRef]
- Ben Israel, D.; Fine, M. Precipitation studies in Ni-10 at.% Ti. Acta Metall. 1963, 11, 1051–1059. [Google Scholar] [CrossRef]
- Decker, R.F.; Sims, C.T. The metallurgy of Nickel-base alloys. In The Superalloys; Sims, C.T., Hagel, W.C., Eds.; John Wiley & Sons: New York, NY, USA, 1972; pp. 33–77. [Google Scholar]
- Hansen, M.; Anderko, K.; Salzberg, H.W. Constitution of binary alloys. J. Electrochem. Soc. 1958, 105, 260C. [Google Scholar] [CrossRef]
- Thornton, P.H.; Davies, P.H.; Johnston, T.L. Temperature dependence of the flow stress of the gamma prime phase based upon Ni3Al. Metall. Trans. A 1970, 1, 207–218. [Google Scholar]
- Dey, G.K.; Tewari, R.; Rao, P.; Wadekar, S.L.; Mukhopadhyay, P. Precipitation hardening in nickel-copper base alloy Monel K-500. Metall. Mater. Trans. A 1993, 24, 2709–2719. [Google Scholar] [CrossRef]
- Dupont, J.N.; Notis, M.R.; Marder, A.R.; Robino, C.V.; Michael, J.R. Solidification of Nb-bearing superalloys: Part I. Reaction sequences. Metall. Mater. Trans. A 1998, 29, 2785–2796. [Google Scholar] [CrossRef]
- Davis, J.R. Fabrication and Finishing of Nickel Alloys, Heat Treating of Nickel Alloys. In Nickel, Cobalt, and Their Alloys; ASM Specialty Handbook; ASM International: Materials Park, OH, USA, 2000; Chapter 3. [Google Scholar]
- Murr, L.E.; Smith, P.J.; Gilmore, C.M. Relative interfacial free energies in pure nickel, dispersion hardened nickel, and a precipitation hardened nickel-base alloy. Philos. Mag. 1968, 17, 89–106. [Google Scholar] [CrossRef]
- Kukliński, M.; Bartkowska, A.; Przestacki, D. Microstructure and selected properties of Monel 400 alloy after laser heat treatment and laser boriding using diode laser. Int. J. Adv. Manuf. Technol. 2018, 98, 3005–3017. [Google Scholar] [CrossRef] [Green Version]
- Krelling, A.P.; Melo, F.S.; Almeida, E.A.D.S.D.; Da Costa, C.E.; Milan, J.C.G. Microstructure and properties of borided Monel 400 alloy. Mater. Res. Express 2019, 6, 106410. [Google Scholar] [CrossRef]
- Gallagher, P.C.J. The influence of alloying, temperature, and related effects on the stacking fault energy. Metall. Trans. 1970, 1, 2429–2461. [Google Scholar]
- Kotval, P.S. Identification of the strengthening phase in “Inconel” alloy 718. Trans. AIME 1968, 242, 1764–1765. [Google Scholar]
- Dillamore, I.L. The stacking fault energy dependence of the mechanisms of deformation in fcc metals. Metall. Trans. 1970, 1, 2463–2470. [Google Scholar]
- Deléhouzée, L.; Deruyttere, A. The stacking fault density in solid solutions based on copper, silver, nickel, aluminium and lead. Acta Metall. 1967, 15, 727–734. [Google Scholar] [CrossRef]
- Haouala, S.; Segurado, J.; Llorca, J. An analysis of the influence of grain size on the strength of FCC polycrystals by means of computational homogenization. Acta Mater. 2018, 148, 72–85. [Google Scholar] [CrossRef] [Green Version]
- Ishikawa, K.; Tanimura, S. Strain rate sensitivity of flow stress at low temperatures in 304n stainless steel. Int. J. Plast. 1992, 8, 947–958. [Google Scholar] [CrossRef]
- Gray, G.T.; Chen, S.R.; Vecchio, K.S. Influence of grain size on the constitutive response and substructure evolution of MONEL 400. Metall. Mater. Trans. A 1999, 30, 1235–1247. [Google Scholar] [CrossRef]
- Parker, E.; Hazlett, T. Principles of Solution Hardening; Technical report No. 12; University of California: Berkley, CA, USA, 1953. [Google Scholar]
- Decker, R.F.; Mihalisin, J.R. Coherency strains in gamma prime hardened nickel alloys. Trans. ASM Q. 1969, 62, 481–489. [Google Scholar]
- Mishima, Y.; Ochiai, S.; Hamao, N.; Yodogawa, M.; Suzuki, T. Solid Solution Hardening of Nickel—Role of Transition Metal and B-subgroup Solutes—. Trans. Jpn. Inst. Met. 1986, 27, 656–664. [Google Scholar] [CrossRef] [Green Version]
- Pyczak, F.; Devirent, B.; Mughrabi, H. The effects of different alloying elements on the thermal expansion coefficients, lattice constants and misfit of nickel-based superalloys Investigated by X-Ray Diffraction. Superalloys 718 Metallurgy Appl. (1989) 2004, 827–836. [Google Scholar] [CrossRef]
- Huther, W.; Reppich, B. Interaction of dislocations with coherent, stress-free, ordered particles. Zeitschrift für Metallkunde 1978, 69, 628–634. [Google Scholar]
- Lippold, J.C.; DuPont, J.; Kiser, S.D. Solid-solution Strengthened Ni-base Alloys. In Welding Metallurgy and Weldability of Nickel-Base Alloys; John Wiley & Sons: Hoboken, NJ, USA, 2009; Chapter 3; pp. 47–156. [Google Scholar]
- Wang, Z.X.; Liu, S.; Yuan, S.; Yang, C. Strength and ductility of Ni-Cu-Base alloy Monel K-500. Trans. NFSoc China 1995, 5, 111–115. [Google Scholar]
- Biss, V.; Sponseller, D.L. Effect of molybdenum on gamma prime coarsening and on elevated-temperature hardness in some experimental Ni-base superalloys. Metall. Trans. A 1973, 4, 1953–1960. [Google Scholar] [CrossRef]
- Guard, R.W.; Westbrook, J.H. Alloying behaviour of Ni3Al (γ phase). Trans. AIME 1959, 215, 807–813. [Google Scholar]
- Gallai, Y.S.; Karmanova, E.G.; Zorina, N.A.; Grigor’Eva, M.M. Cold working and recrystallization of nickel alloys. Met. Sci. Heat Treat. 1967, 9, 323–324. [Google Scholar] [CrossRef]
- Marenych, O.; Kostryzhev, A.G.; Pan, Z.; Li, H.; Van Duin, S. Comparative effect of Mn/Ti solute atoms and TiC/Ni3(Al,Ti) nano-particles on work hardening behaviour in Ni Cu alloys fabricated by wire arc additive manufacturing. Mater. Sci. Eng. A 2019, 753, 262–275. [Google Scholar] [CrossRef]
- Martens, V.; Nembach, E. Strengthening of the nimonic alloy PE 16 by ordered particles of Ni3(Al, Ti). Acta Metall. 1975, 23, 149–153. [Google Scholar] [CrossRef]
- Smith, G.D.; Baker, B.A. Nickel and Its Alloys. In Mechanical Engineers’ Handbook; Wiley & Sons: Hoboken, NJ, USA, 2015; pp. 1–22. [Google Scholar]
- Watson, J.F.; Christian, J.L. Low-Temperature Properties of K-monel, inconel-X, Rene´ 41, Haynes 25, and Hastelloy B Sheet alloys. J. Basic Eng. 1962, 84, 265–277. [Google Scholar] [CrossRef]
- Hurlich, A. Low Temperature Materials. In Chemical Engineering; McGraw-Hill Publishing Go. Inc.: New York, NY, USA, 1963; pp. 311–325. [Google Scholar]
- Ramkumar, K.D.; Arivazhagan, N.; Narayanan, S.; Mishra, D. Hot corrosion behavior of monel 400 and AISI 304 dissimilar weldments exposed in the molten salt environment containing Na2SO4 + 60% V2O5 at 600 °C. Mater. Res. 2014, 17, 1273–1284. [Google Scholar] [CrossRef] [Green Version]
- Raffeis, I.; Adjei-Kyeremeh, F.; Vroomen, U.; Westhoff, E.; Bremen, S.; Hohoi, A.; Bührig-Polaczek, A. Qualification of a Ni–Cu Alloy for the Laser Powder Bed Fusion Process (LPBF): Its Microstructure and Mechanical Properties. Appl. Sci. 2020, 10, 3401. [Google Scholar] [CrossRef]
- Marenych, O.; Ding, D.; Pan, Z.; Kostryzhev, A.G.; Li, H.; Van Duin, S. Effect of chemical composition on microstructure, strength and wear resistance of wire deposited Ni-Cu alloys. Addit. Manuf. 2018, 24, 30–36. [Google Scholar] [CrossRef]
Monel Alloys | Ni | Cu | C | Mn | Fe | Co | S | Si | Al | Ti | |
---|---|---|---|---|---|---|---|---|---|---|---|
Monel 400 | Max | - | 34.0 | 0.3 | 2.0 | 2.5 | - | 0.024 | 0.5 | - | - |
Min | 63.0 | 28.0 | - | - | - | - | - | - | - | - | |
Monel 401 | Max | 45.0 | Balance | 0.1 | 2.25 | 0.75 | 0.25 | 0.015 | 0.25 | - | - |
Min | 40.0 | - | - | - | - | - | - | - | - | - | |
Monel 404 | Max | 57.0 | Balance | 0.15 | 0.1 | 0.5 | - | 0.024 | 0.1 | 0.05 | - |
Min | 52.0 | - | - | - | - | - | - | - | - | - | |
Monel R405 | Max | - | 34.0 | 0.3 | 2.0 | 2.5 | - | 0.060 | 0.5 | - | - |
Min | 63.0 | 28.0 | - | - | - | - | 0.025 | - | - | - | |
Monel K500 | Max | - | 33.0 | 0.18 | 1.5 | 2.0 | 0.25 | 0.006 | 0.5 | 3.15 | 0.85 |
Min | 63.0 | 27.0 | - | - | - | - | - | - | 2.3 | 0.35 |
Element | Approximate Atomic Size Difference Compared to Ni, % | Approximate Solubility in Ni at 1000 °C, wt.% [34] |
---|---|---|
Ta | −51 | 14 |
W | −44 | 38 |
Mo | −41 | 34 |
Ti | −27 | 10 |
V | −22 | 20 |
Cr | −17 | 40 |
Mn | −12 | 20 |
Nb | −49 | 6 |
Al | 31 | 7 |
Si | 38 | 8 |
C | 82 | 0.2 |
Fe | −9 | 100 |
Co | −3 | 100 |
Cu | 4 | 100 |
Processing Condition | Yield Strength, MPa | Tensile Strength, MPa | Elongation, % | HB |
---|---|---|---|---|
Monel 400 | ||||
Hot-Finished | 280–690 | 550–760 | 30–60 | 140–240 |
Hot-Finished, Annealed | 170–340 | 520–620 | 35–60 | 110–150 |
Cold-Drawn | 380–690 | 580–830 | 22–40 | 160–225 |
Monel K500 | ||||
Hot-Finished | 280–760 | 620–1070 | 45–20 | 140–315 |
Hot-Finished, Aged | 690–1034 | 965–1310 | 30–20 | 265–346 |
Hot-Finished, Annealed | 280–414 | 621–760 | 45–25 | 140–185 |
Hot-Finished, Annealed and Aged | 586–830 | 896–1140 | 35–20 | 250–315 |
Cold-Drawn, As-Drawn | 483–860 | 690–965 | 35–13 | 175–260 |
Cold-Drawn, Aged | 655–1100 | 931–1280 | 30–15 | 255–370 |
Cold-Drawn, Annealed | 280–414 | 621–760 | 50–25 | 140–185 |
Cold-Drawn, Annealed and Aged | 586–830 | 896–1310 | 30–20 | 250–315 |
