2. Overview of Key Concepts and Paradigms
2.1. Cyber–Physical Systems
2.2. Internet of Things
2.3. Data Analytics and Machine Learning
2.4. Emerging Paradigms in Manufacturing
2.4.1. Smart Manufacturing
2.4.2. Cyber–Physical Production Systems
2.4.3. Industry 4.0
2.4.4. Cloud Manufacturing
3. Interoperability in Manufacturing
3.1. Definitions of Interoperability
- The ability of one system to receive and process intelligible information of mutual interest transmitted by another system .
- Interoperability means the ability of two or more parties, machine or human, to make a perfect exchange of content. Perfect means no perceptible distortions or unintended delays between content origin, processing and use .
- Interoperability among components of large-scale, distributed systems is the ability to exchange services and data with one another .
- The condition achieved between systems when information or services are exchanged directly and satisfactorily between the systems and/or their users .
- The ability to integrate data, functionality and processes with respect to their semantics .
- Interoperability, in a broad sense, refers to the use of computer-based tools that facilitate coordination of work and information flow across organizational boundaries, focusing mainly on inter-enterprise distributed BPs and flows .
- The ability of systems, units, or forces to provide services to and accept services from other systems, units, or forces and to use the services so exchanged to enable them to operate effectively together .
3.2. Challenges in Implementation of Interoperability
- Transfer of data between systems that may be similar or dissimilar (commercially).
- Transfer of data between software made by the same vendor (or creator) but having different versions on the systems.
- Compatibility between different versions of software (newer and older versions).
- Misinterpretation of terminology used or in the understanding of the terminology used for exchange of data or information.
- The use of non-standardized documentation on which the exchange of data is processed or formatted.
- Not testing the applications that are deemed conformant, due to the lack of means to do so between systems.
3.3. Generic Approaches to Implement Interoperability
3.3.1. Syntactic Interoperability
3.3.2. Semantic Interoperability
3.4. Factory Interoperability (Vertical Integration)
3.5. Cloud-Manufacturing Interoperability (Horizontal Integration)
- Behavioral interoperability. This type selects from a list of anticipated responses when requests are received for our services. By setting conditions on the requests, computer simulations with the help of human responses can anticipate the outcomes of the service request and be ready to offer a solution.
- Policy interoperability. This type ensures that all the systems in the cloud follow and conform to the regulations and policies while interacting within the cloud environment.
4. Reference Architectures for Interoperable Manufacturing
- The physical architecture of the components of a system (e.g., automation devices, machines, software, departments).
- The functional architecture representing the set of functions and processes to be accomplished by the systems.
- The allocated architecture describing the mapping between the functional architecture and the physical architecture.
4.1. RAMI 4.0
- Business layer. This layer consists of the business models and information about the business’s components, such as the service and or the products that it offers. The business rules and practices are pre-defined and serve for governing the manner in which business processes are executed.
- Functional layer. The functions of the architecture model are characterized and detailed and their relationships are established. The functions are designed and rendered and are autonomous, not dependent upon the processes or its utilization in the architecture.
- Information layer. This layer controls and governs the data and information that is used in the architecture. It also serves the purpose of analyzing the information that is being exchanged and the level of data quality.
- Communication layer. The communication between layers, systems and all the components that are executed, while at the same time interoperable are described by this layer.
- Integration layer. This layer provides a connection between all the layers of this architecture and the physical components. It also addresses network and software integration.
- Asset Layer. This layer includes all the systems at the physical level such as shop floor machines, the human interaction with the systems as well as other physical objects.
- Business domain. This domain is at the top of the IIRA functional viewpoint and consists of business-related information at the enterprise level. It also manages systems that are used across the business such as Manufacturing Execution Systems (MES) and Enterprise Resource Planning (ERP) in line with objectives and goals pertinent to the business.
- Information domain. This domain consists of functions that are tasked with the purpose of data analysis and assessment of data quality to procure knowledge of all the system’s components.
- Application domain. This domain builds on the information logged by the information domain and applies logic to it to improve system performance and efficiency of operations.
- Operations domain. This domain assesses the operations that are planned and ongoing, performs scheduled maintenance and diagnostics, with the end goal being ensuring optimal performance.
- Control domain. This domain consists of functions that control the implementation of processes at the physical system with feedback.
4.3. IBM Industry 4.0 Reference Architecture
- The Edge integrates the Plant and the Enterprise layers, with the ability to connect with legacy systems and equipment and also the protocol that they follow. The Edge can work independent of the Plant and Enterprise layers, without any integration by controlling the systems components at the device level directly. Smart devices and equipment can communicate all the way up through to the Enterprise level from the Edge when integrated. The Edge undertakes the task of data analytics and transformation and communicates this information through the layers.
- The Hybrid Cloud or the Platform consisting of the Plant and the Enterprise levels perform plant wide and enterprise wide analytics. The Plant level can direct MES to take appropriate decisions based on the analyzed data and the Enterprise level can similarly make decisions based on factories, locations, etc.
4.4. NIST Service-Oriented Architecture for Smart Manufacturing
5. Real-World Implementation of Industry 4.0 Components
6. Future Scope and Recommendations
Conflicts of Interest
- DIN. DIN SPEC 91345:2016-04, Reference Architecture Model Industrie 4.0 (RAMI4.0); DIN: Berlin, Germany, 2016. [Google Scholar]
- CSIS. Made in China 2025; CSIS: Washington, DC, USA, 2015. [Google Scholar]
- Manufacturing USA. National Network for Manufacturing Innovation; A National Advanced Manufacturing Portal: Gaithersburg, MD, USA, 2011. [Google Scholar]
- Moghaddam, M.; Cadavid, M.; Kenley, C.R.; Deshmukh, A. Reference architectures for smart manufacturing: A critical review. J. Manuf. Syst. 2018, 49, 215–225. [Google Scholar] [CrossRef]
- Lu, Y.; Morris, K.C.; Frechette, S. Current Standards Landscape for Smart Manufacturing Systems; NIST: Gaitehrsburg, MD, USA, 2016; Volume 8107, ISBN 1069600690287.
- Monostori, L.; Kádár, B.; Bauernhansl, T.; Kondoh, S.; Kumara, S.; Reinhart, G.; Sauer, O.; Schuh, G.; Sihn, W.; Ueda, K. Cyber-physical systems in manufacturing. CIRP Ann. 2016, 65, 621–641. [Google Scholar] [CrossRef]
- Xu, X. From cloud computing to cloud manufacturing. Robot. Comput. Integr. Manuf. 2012, 28, 75–86. [Google Scholar] [CrossRef]
- Ray, S.R.; Jones, A.T. Manufacturing interoperability. J. Intell. Manuf. 2006, 17, 681–688. [Google Scholar] [CrossRef]
- Lee, E.A. Cyber Physical Systems: Design Challenges. In Proceedings of the 2008 11th IEEE International Symposium on Object and Component-Oriented Real-Time Distributed Computing (ISORC), Orlando, FL, USA, 5–7 May 2008; pp. 363–369. [Google Scholar]
- NSF. Cyber-Physical Systems (CPS); National Science Foundation: Arlingation, VA, USA, 2010.
- Nolin, J.; Olson, N. The Internet of Things and convenience. Internet Res. 2016, 26, 360–376. [Google Scholar] [CrossRef]
- Tao, F.; Cheng, Y.; da Xu, L.; Zhang, L.; Li, B.H. CCIoT-CMfg: Cloud Computing and Internet of Things-Based Cloud Manufacturing Service System. IEEE Trans. Ind. Inf. 2014, 10, 1435–1442. [Google Scholar]
- ISO/IEC. ISO/IEC 18384: 2016, Information Technology—Reference Architecture for Service Oriented Architecture (SOA RA); International Organization for Standardization: Geneva, Switzerland, 2016. [Google Scholar]
- Ivezic, N.; Kulvatunyou, B.; Brandl, D.; Machi, M.; Lu, Y.; Noller, D.; Davis, J.; Wuest, T.; Kiritsis, D.; Witherell, P. NIST Advanced Manufacturing Series 100-15—2017 NIST/OAGi Workshop: Drilling down on Smart Manufacturing—Enabling Composable Service-Oriented Manufacturing Systems. NIST AMS 2018. [Google Scholar] [CrossRef]
- Wuest, T.; Weimer, D.; Irgens, C.; Thoben, K.-D. Machine learning in manufacturing: Advantages, challenges, and applications. Prod. Manuf. Res. 2016, 4, 23–45. [Google Scholar] [CrossRef]
- Harding, J.A.; Shahbaz, M.; Kusiak, A. Data Mining in Manufacturing: A Review. J. Manuf. Sci. Eng. 2006, 128, 969–976. [Google Scholar] [CrossRef]
- Radziwon, A.; Bilberg, A.; Bogers, M.; Madsen, E.S. The Smart Factory: Exploring Adaptive and Flexible Manufacturing Solutions. Procedia Eng. 2014, 69, 1184–1190. [Google Scholar] [CrossRef][Green Version]
- Wang, L.; Torngren, M.; Onori, M. Current status and advancement of cyber-physical systems in manufacturing. J. Manuf. Syst. 2015, 37, 517–527. [Google Scholar] [CrossRef]
- Lee, J.; Bagheri, B.; Jin, C. Introduction to cyber manufacturing. Manuf. Lett. 2016, 8, 11–15. [Google Scholar] [CrossRef][Green Version]
- Hofmann, E.; Rüsch, M. Industry 4.0 and the current status as well as future prospects on logistics. Comput. Ind. 2017, 89, 23–34. [Google Scholar] [CrossRef]
- Wu, D.; Rosen, D.W.; Wang, L.; Schaefer, D. Cloud-based design and manufacturing: A new paradigm in digital manufacturing and design innovation. Comput.-Aided Des. 2015, 59, 1–14. [Google Scholar] [CrossRef][Green Version]
- Jiang, P.; Ding, K.; Leng, J. Towards a cyber-physical-social-connected and service-oriented manufacturing paradigm: Social Manufacturing. Manuf. Lett. 2016, 7, 15–21. [Google Scholar] [CrossRef]
- ISO/IEC. ISO 16100-6:2011(E): Industrial Automation Systems and Integration—Manufacturing Software Capability Profiling for Interoperability; International Organization for Standardization: Geneva, Switzerland, 2015; Volume 2011. [Google Scholar]
- 610-1991 IEEE Standard Computer Dictionary. A Compilation of IEEE Standard Computer Glossaries; IEEE Press: Piscataway, NJ, USA, 1991; ISBN 9780738147680.
- Kasunic, M. Measuring Systems Interoperability: Challenges and Opportunities. Available online: http://citeseerx.ist.psu.edu/viewdoc/download?doi=10.1.1.464.9748&rep=rep1&type=pdf (accessed on 1 April 2019).
- Ford, T.C.; Colombi, J.M.; Graham, S.R.; Jacques, D.R. A Survey on Interoperability Measurement. Available online: http://www.dodccrp.org/events/12th_ICCRTS/CD/html/papers/096.pdf (accessed on 1 April 2019).
- Heiler, S. Sandra Semantic interoperability. ACM Comput. Surv. 1995, 27, 271–273. Available online: https://dl.acm.org/citation.cfm?doid=210376.210392 (accessed on 25 March 2019). [CrossRef]
- Curts, R.J.; Campbell, D.E. Architecture: The Road to Interoperability; Command & Control Research Technology Symposium (CCRTS): US Naval War College, Newport, RI, USA, 1999. [Google Scholar]
- Berre, A.-J.; Hahn, A.; Akehurst, D.; Bezivin, J.; Tsalgatidou, A.; Vermaut, F.; Kutvonen, L.; Linington, P.F. State-of-the Art for Interoperability Architecture Approaches—Model Driven and Dynamic, Federated Enterprise Interoperability Architectures and Interoperability for Non-Functional Aspects. Available online: http://citeseerx.ist.psu.edu/viewdoc/download?doi=10.1.1.106.9713&rep=rep1&type=pdf (accessed on 25 March 2019).
- Chituc, C.-M.; Toscano, C.; Azevedo, A. Interoperability in Collaborative Networks: Independent and industry-specific initiatives—The case of the footwear industry. Comput. Ind. 2008, 59, 741–757. [Google Scholar] [CrossRef]
- Morris, E.; Levine, L.; Meyers, C.; Place, P.; Plakosh, D. System of Systems Interoperability (SOSI): Final Report; Carnegie-Mellon University: Pittsburgh, PA, USA, 2004; Available online: https://resources.sei.cmu.edu/asset_files/TechnicalReport/2004_005_001_14375.pdf (accessed on 1 April 2019).
- Chen, D.; Vernadat, F.B. Enterprise Interoperability: A Standardisation View; Springer: Boston, MA, USA, 2003; pp. 273–282. [Google Scholar]
- Kemmerer, S.J. Manufacturing Interoperability Program: A Synopsis, National Institue of Standards and Technology; Technical Reprot for NIST Interagency/Internal Report (NISTIR)-7533: Gaithersburg, MD, USA, 2009. [Google Scholar]
- Mosley, M.; Brackett, M.H.; Earley, S.; Henderson, D.; Data Administration Management Association. DAMA Guide to the Data Management Body of Knowledge (DAMA-DMBOK Guide). 2009. Available online: http://eitbokwiki.org/Interoperability (accessed on 26 February 2019).
- van der Veer, H.; Wiles, A. Achieving Technical Interoperability-the ETSI Approach; European Telecommunications Standards Institute: Sophia Antipolis, France, 2008. [Google Scholar]
- Shukla, A.; Harris, S.; Davies, J. Semantic Interoperability in Practice. In Proceedings of the IEEE 2010 43rd Hawaii International Conference on System Sciences, Honolulu, HI, USA, 5–8 January 2010; pp. 1–10. [Google Scholar]
- Decker, S.; Melnik, S.; van Harmelen, F.; Fensel, D.; Klein, M.; Broekstra, J.; Erdmann, M.; Horrocks, I. The Semantic Web: The roles of XML and RDF. IEEE Internet Comput. 2000, 4, 63–73. [Google Scholar] [CrossRef]
- Lelli, F. Interoperability of the Time of Industry 4.0 and the Internet of Things. Futur. Internet 2019, 11, 36. [Google Scholar] [CrossRef]
- Tassey, G.; Brunnermeier, S.B.; Martin, S.A. Interoperability Cost Analysis of the U.S. Automotive Supply Chain Final Report RTI Project Numer 7007-03; Research Triangle Institute: Research Triangle Park, NC, USA, 1999. [Google Scholar]
- Chen, D.; Doumeingts, G.; Vernadat, F. Architectures for enterprise integration and interoperability: Past, present and future. Comput. Ind. 2008, 59, 647–659. [Google Scholar] [CrossRef]
- ISO/IEC. Information Technology-Cloud Computing-Interoperability and Portability; International Organization for Standardization: Geneva, Switzerland, 2017. [Google Scholar]
- Representational State Transfer (REST). Available online: https://www.ics.uci.edu/~fielding/pubs/dissertation/rest_arch_style.htm (accessed on 28 January 2019).
- ISO/IEC. Information Technology-Message Queuing Telemetry Transport (MQTT) v3.1.1; International Organization for Standardization: Geneva, Switzwerland, 2016. [Google Scholar]
- Mourad, M.; Nassehi, A.; Schaefer, D. Interoperability as a Key Enabler for Manufacturing in the Cloud. Procedia CIRP 2016, 52, 30–34. [Google Scholar] [CrossRef][Green Version]
- Wang, X.V.; Xu, X.W. ICMS: A Cloud-Based Manufacturing System; Springer: London, UK, 2013; pp. 1–22. [Google Scholar]
- Lu, Y.; Xu, X.; Xu, J. Development of a Hybrid Manufacturing Cloud. J. Manuf. Syst. 2014, 33, 551–566. [Google Scholar] [CrossRef]
- Li, B.; Chai, X.; Hou, B.; Zhang, L.; Zhou, J.; Liu, Y. New Generation Artificial Intelligence-Driven Intelligent Manufacturing (NGAIIM). In Proceedings of the 2018 IEEE SmartWorld, Ubiquitous Intelligence & Computing, Advanced & Trusted Computing, Scalable Computing & Communications, Cloud & Big Data Computing, Internet of People and Smart City Innovation (SmartWorld/SCALCOM/UIC/ATC/CBDCom/IOP/SCI), Guangzhou, China, 8–12 October 2018; pp. 1864–1869. [Google Scholar]
- Chai, X.; Hou, B.; Zou, P.; Zeng, J.; Zhou, J. INDICS: An Industrial Internet Platform. In Proceedings of the 2018 IEEE SmartWorld, Ubiquitous Intelligence & Computing, Advanced & Trusted Computing, Scalable Computing & Communications, Cloud & Big Data Computing, Internet of People and Smart City Innovation (SmartWorld/SCALCOM/UIC/ATC/CBDCom/IOP/SCI), Guangzhou, China, 8–12 October 2018; pp. 1824–1828. [Google Scholar]
- Rouse, W.B.; Sage, A.P. Handbook of Systems Engineering and Management; John Wiley & Sons: Hoboken, NJ, USA, 2009; ISBN 9780470083536. [Google Scholar]
- Architecture Alignment and Interoperability an Industrial Internet Consortium and Plattform Industrie 4.0 Joint Whitepaper Contributors. Available online: https://www.iiconsortium.org/pdf/JTG2_Whitepaper_final_20171205.pdf (accessed on 25 March 2019).
- IEC. IEC TR 62541-2:2016—OPC Unified Architecture—Part 2: Security Model; Technical Report for International Electrotechnical Commission: Geneva, Switzerland, 2016. [Google Scholar]
- Internet of Things for Insights from Connected Devices: Industrie 4.0—IBM Cloud Garage Method. IBM. Available online: https://www.ibm.com/cloud/garage/architectures/iotArchitecture/industrie_40 (accessed on 28 January 2019).
- Lu, Y.; Riddick, F.; Ivezic, N. The Paradigm Shift in Smart Manufacturing System Architecture; Springer: Cham, Switzerland, 2016; pp. 767–776. [Google Scholar]
- Luder, A.; Schleipen, M.; Schmidt, N.; Pfrommer, J.; Hensen, R. One step towards an industry 4.0 component. In Proceedings of the 2017 13th IEEE Conference on Automation Science and Engineering (CASE), Xi’an, China, 20–23 August 2017; pp. 1268–1273. [Google Scholar]
- Drath, R.; Luder, A.; Peschke, J.; Hundt, L. AutomationML—The glue for seamless automation engineering. In Proceedings of the 2008 IEEE International Conference on Emerging Technologies and Factory Automation, Hamburg, Germany, 15–18 September 2008; pp. 616–623. [Google Scholar]
- 2018 NIST/OAGi Workshop: Enabling Composable Service-Oriented Manufacturing Systems. Available online: https://www.nist.gov/news-events/events/2018/04/2018-nistoagi-workshop-enabling-composable-service-oriented-manufacturing (accessed on 26 February 2019).
|Integration of shop floor, business processes, and cloud services for plug-and-produce work (P1)||✓||✓||✓||✓|
|Fully-integrated industry—inter-enterprise, cloud-based publication and sharing of services (P1)||✓|
|Service representation, composition, discovery, registration, and matching (P1)||✓|
|Service definition—shift of focus from macro to micro services in manufacturing SOA (P1)||✓|
|Representation of complex capabilities such as cognitive systems or analytics as services (P1)||✓|
|Standardized taxonomy of manufacturing processes as services (P1/P2)||✓||✓||✓|
|Asynchronous and interoperable communication mechanisms and publish/subscribe API (P1)||✓||✓||✓||✓|
|Need for ‘smarter’ objects to execute more complex services (P2)||✓|
|Standardized description of objects as prerequisite for standardization of services (P2/P4)||✓||✓|
|Common language (e.g., OPC-UA) for standardizing object and services (P2)||✓||✓||✓||✓|
|Mechanisms for orchestration, filtering, aggregation, and sharing of cloud services (P3/P4)||✓||✓||✓|
|New models for the economics of acquisition, implementation, and integration (P3)||✓|
|New models for automated, on-the-fly creation and governance of value networks (P4)||✓||✓|
|Horizontal integration of product life-cycles through micro-services (P4)||✓|
|Need for autonomous, self-/environment-aware, intelligent devices for service-orientation (P4)||✓|
|Concurrent optimization of order-to-cash and design-manufacture-maintenance cycles (P4)||✓|
|Lack of horizontal integration and reconfigurable manufacturing capabilities in ISA-95 (P5)||✓|
|Integration of ISA-95 into a cloud-based architecture (P5)||✓|
|Transition from thousands of enterprise-wide applications to consistent cloud-based services (P6)||✓|
|Lack of modularity of legacy manufacturing systems hindering ‘composability’ (P6)||✓|
|PX: Proposition X|
