Topographical Analysis of the 2013 Typhoon Haiyan Storm Surge Flooding by Combining the JMA Storm Surge Model and the FLO-2D Flood Inundation Model

by 1 and 2,*
1
Department of Agricultural & Rural Eng., Chungnam National University, Daejeon 34134, Korea
2
Climate Prediction Team, APEC Climate Center, Busan 48058, Korea
*
Author to whom correspondence should be addressed.
Water 2019, 11(1), 144; https://doi.org/10.3390/w11010144
Received: 26 November 2018 / Revised: 7 January 2019 / Accepted: 8 January 2019 / Published: 15 January 2019
(This article belongs to the Special Issue Hydrological Impact of Typhoon on Rivers)
The floods associated with the effects of an incoming tropical cyclone have an immense effect in the Philippines, especially with respect to agriculture, industry, livelihood, and public safety. Knowledge of how such storm surge flooding can affect the community is therefore of great importance. In this study, the mechanisms behind Typhoon Haiyan’s anomalous storm surge flooding in 2013, which resulted in more than 6300 casualties and 2.86 billion USD worth of damage in the Philippines, were investigated. The Japan Meteorological Agency (JMA) storm surge model and the FLO-2D flood model were used to simulate Typhoon Haiyan’s storm surge height and the extent of inundation, respectively. The storm surge input data were obtained from JMA typhoon data, and the digital terrain models used were gathered from the airborne interferometric synthetic aperture radar data. The model’s accuracy was also validated using field validation data of the extent of the observed storm surge in affected coastal areas. Topographical analysis of the inundated regions showed the effects of coastal shape, elevation, and position relative to the typhoon’s approach angle on storm surge flow depth and velocity. Storm surge maximum velocity appears to increase as the fluid flows to an increasingly elevated area. Observing fluid velocity in a coastal area with uniform storm surge discharge from all directions also showed that flow velocity tends to increase at the center. Greater flood depths were experienced in areas with lower coastal elevation and not directly located at the coast, compared to higher elevation coastal areas. Greater extents of storm surge flooding are expected in coastal areas that have a concave shape, as fluid is more likely to be dispersed when hitting a convex coast. Extents are likewise observed to be greater in coastal regions that are located perpendicular to the direction of the typhoon. The research also validated the option of using a combination of typhoon and flood models to simulate the inundation flooding caused by extreme weather events. View Full-Text
Keywords: storm surge model; flood model; extreme weather events; topographical characteristics; inundation extent; inundation depth storm surge model; flood model; extreme weather events; topographical characteristics; inundation extent; inundation depth
Show Figures

Graphical abstract

MDPI and ACS Style

Dasallas, L.; Lee, S. Topographical Analysis of the 2013 Typhoon Haiyan Storm Surge Flooding by Combining the JMA Storm Surge Model and the FLO-2D Flood Inundation Model. Water 2019, 11, 144.
