Additive Manufacturing of Information Carriers Based on Shape Memory Polyester Urethane
1
Fraunhofer Institute for Applied Polymer Research IAP, Geiselbergstr. 69, 14476 Potsdam, Germany
2
Fraunhofer Institute for Industrial Mathematics ITWM, Fraunhofer-Platz 1, 67663 Kaiserslautern, Germany
*
Author to whom correspondence should be addressed.
Polymers 2019, 11(6), 1005; https://doi.org/10.3390/polym11061005
Received: 5 April 2019 / Revised: 30 April 2019 / Accepted: 4 June 2019 / Published: 5 June 2019
(This article belongs to the Special Issue Shape Memory Polymers III)
Shape memory polymers (SMPs) are stimuli-responsive materials, which are able to retain an imposed, temporary shape and recover the initial, permanent shape through an external stimulus like heat. In this work, a novel manufacturing method is introduced for thermoresponsive quick response (QR) code carriers, which originally were developed as anticounterfeiting technology. Motivated by the fact that earlier manufacturing processes were sometimes too time-consuming for production, filaments of a polyester urethane (PEU) with and without dye were extruded and processed into QR code carriers using fused filament fabrication (FFF). Once programmed, the distinct shape memory properties enabled a heating-initiated switching from non-decodable to machine-readable QR codes. The results demonstrate that FFF constitutes a promising additive manufacturing technology to create complex, filigree structures with adjustable horizontal and vertical print resolution and, thus, an excellent basis to realize further technically demanding application concepts for shape memory polymers.
View Full-Text
Keywords:
additive manufacturing; 3D printing; shape memory polymer; fused filament fabrication; QR code carrier; thermoplastic polyurethane; filigree structures
▼
Show Figures
This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited
MDPI and ACS Style
Chalissery, D.; Pretsch, T.; Staub, S.; Andrä, H. Additive Manufacturing of Information Carriers Based on Shape Memory Polyester Urethane. Polymers 2019, 11, 1005. https://doi.org/10.3390/polym11061005
AMA Style
Chalissery D, Pretsch T, Staub S, Andrä H. Additive Manufacturing of Information Carriers Based on Shape Memory Polyester Urethane. Polymers. 2019; 11(6):1005. https://doi.org/10.3390/polym11061005
Chicago/Turabian StyleChalissery, Dilip; Pretsch, Thorsten; Staub, Sarah; Andrä, Heiko. 2019. "Additive Manufacturing of Information Carriers Based on Shape Memory Polyester Urethane" Polymers 11, no. 6: 1005. https://doi.org/10.3390/polym11061005
