Mechanochemical Access to Elusive Metal Diphosphinate Coordination Polymer

Consiglio Nazionale delle Ricerche—Istituto di Chimica dei Composti OrganoMetallici (CNR-ICCOM) Via Madonna del Piano 10, Sesto Fiorentino, I-50019 Firenze, Italy
Dipartimento di Chimica “Ugo Schiff”, University of Florence, Via della Lastruccia 3, Sesto Fiorentino, I-50019 Firenze, Italy
Dipartimento di Chimica, Biologia e Biotecnologie, University of Perugia, Via Elce di Sotto 8, I-06123 Perugia, Italy
Author to whom correspondence should be addressed.
Crystals 2019, 9(6), 283;
Received: 24 April 2019 / Revised: 21 May 2019 / Accepted: 25 May 2019 / Published: 29 May 2019
(This article belongs to the Special Issue Metal Phosphonates and Phosphinates)
PDF [2397 KB, uploaded 27 June 2019]


Several binary metal diphosphinate compounds (ML) have been reported for diphosphinate bonded by a single methylene fragment. In case of longer bridges, binary products are difficult to isolate in crystalline form. Here, using a solvent assisted mechano-chemistry synthesis, we report two new ML crystalline phases, one hydrated and one anhydrous. The hydrated phase is a 2D coordination polymer with an open framework structure. Its network displays a new topology for coordination polymers and metal organic frameworks. The thermal behavior of the two phases has been studied. Finally, the importance of the bridge length is discussed in view of known metal diphosphinate compounds. View Full-Text
Keywords: coordination polymers; diphosphinate; copper; MOF; mechanochemistry coordination polymers; diphosphinate; copper; MOF; mechanochemistry

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Supplementary material


Share & Cite This Article

MDPI and ACS Style

Ienco, A.; Tuci, G.; Guerri, A.; Costantino, F. Mechanochemical Access to Elusive Metal Diphosphinate Coordination Polymer. Crystals 2019, 9, 283.
