Constructor Graphs as Useful Tools for the Classification of Hydrogen Bonded Solids: The Case Study of the Cationic (Dimethylphosphoryl)methanaminium (dpmaH+) Tecton
Abstract
:1. Introduction
2. Results and Discussion
2.1. Salt Structures Based on Head-to-Tail Connected Hydrogen Bonded Polymers: (dpmaH+)n
- A comparison of the chain-type and strand-type structures discussed before has been simplified by the use of the modified constructor graphs.
- The intuitive dissection of these complex hydrogen bonded structures into subunits (tectons) that look like as they were taken from a “chemical toolbox”, unquestionable supports the understanding of the individual structures and should support the prediction of structural features.
2.2. Salts Based on Hydrogen Bonded (dpmaH+)2 Dimers
3. Limitations
4. Conclusions
Acknowledgments
Conflicts of Interest
References
