Phase Diagram of a Strained Ferroelectric Nanowire
Abstract
:1. Introduction
2. Materials and Methods
2.1. Functional
2.2. Phase-Field Simulations
2.3. Atomistic Simulations
3. Results
4. Discussion
5. Conclusions
Author Contributions
Funding
Data Availability Statement
Conflicts of Interest
References
