Miniaturized NIR Spectrometer Based on Novel MOEMS Scanning Tilted Grating

1,2,3,*, 1,4,*, 1,5, 1,5, 1,3 and 1,3
1
Key Laboratory of Fundamental Science of Micro/Nano-Device and System Technology, Chongqing University, Chongqing 400044, China
2
College of Information Engineering, Qujing Normal University, Qujing 655000, China
3
Microsystem Research Center, College of Optoelectronic Engineering, Chongqing University, Chongqing 400044, China
4
Fraunhofer Institute for Electronic Nano Systems (ENAS), 09131 Chemnitz, Germany
5
College of Electronic and Information Engineering, Southwest University, Chongqing 400715, China
*
Authors to whom correspondence should be addressed.
Micromachines 2018, 9(10), 478; https://doi.org/10.3390/mi9100478
Received: 15 August 2018 / Revised: 15 September 2018 / Accepted: 18 September 2018 / Published: 20 September 2018
(This article belongs to the Special Issue MEMS/NEMS Sensors: Fabrication and Application)
  |
PDF [6613 KB, uploaded 20 September 2018]
  |

Abstract

This paper presents a dispersive near-infrared spectrometer with features of miniaturization, portability and low cost. The application of a resonantly-driven scanning grating mirror (SGM) as a dispersive element in a crossed Czerny–Turner configuration enables the design of a miniaturized spectrometer that can detect the full spectra using only one single InGaAs diode. In addition, a high accuracy recalculation is realized, which can convert time-dependent measurements to spectrum information by utilizing the deflection position detector integrated on SGM and its associated closed-loop control circuit. Finally, the spectrometer prototype is subjected to a series of tests to characterize the instrument’s performance fully. The results of the experiment show that the spectrometer works in a spectral range of 800 nm–1800 nm with a resolution of less than 10 nm, a size of 9 × 7 × 7 cm3, a wavelength stability better than ±1 nm and a measuring time of less than 1 ms. Furthermore, the power consumption of the instrument is 3 W at 5 V DC, and the signal-to-noise ratio is 3267 at full scale. Therefore, this spectrometer could be a potential alternative to classical spectrometers in process control applications or could be used as a portable or airborne spectroscopic sensor. View Full-Text
