Data Assimilation to Extract Soil Moisture Information from SMAP Observations

Universities Space Research Association, Columbia, MD 21046, USA
Global Modeling and Assimilation Office, NASA Goddard Space Flight Center, Greenbelt, MD 20771, USA
Science Systems and Applications Inc., Lanham, MD 20706, USA
USDA ARS Hydrology and Remote Sensing Laboratory, Beltsville, MD 20705, USA
USDA ARS Southeast Watershed Research Center, Tifton, GA 31793, USA
Bureau of Economic Geology, The University of Texas at Austin, Austin, TX 78712, USA
Jet Propulsion Laboratory, California Institute of Technology, Pasadena, CA 91125, USA
USDA ARS Southwest Watershed Research Center, Tucson, AZ 85719, USA
USDA ARS National Soil Erosion Research Laboratory, West Lafayette, IN 47907, USA
Viterbi School of Engineering, University of Southern California, Los Angeles, CA 90089, USA
USDA ARS Grazinglands Research Laboratory, El Reno, OK 73036, USA
Author to whom correspondence should be addressed.
Remote Sens. 2017, 9(11), 1179;
Received: 3 October 2017 / Revised: 3 November 2017 / Accepted: 9 November 2017 / Published: 17 November 2017
(This article belongs to the Special Issue Retrieval, Validation and Application of Satellite Soil Moisture Data)
PDF [10582 KB, uploaded 23 November 2017]


This study compares different methods to extract soil moisture information through the assimilation of Soil Moisture Active Passive (SMAP) observations. Neural network (NN) and physically-based SMAP soil moisture retrievals were assimilated into the National Aeronautics and Space Administration (NASA) Catchment model over the contiguous United States for April 2015 to March 2017. By construction, the NN retrievals are consistent with the global climatology of the Catchment model soil moisture. Assimilating the NN retrievals without further bias correction improved the surface and root zone correlations against in situ measurements from 14 SMAP core validation sites (CVS) by 0.12 and 0.16, respectively, over the model-only skill, and reduced the surface and root zone unbiased root-mean-square error (ubRMSE) by 0.005 m 3 m 3 and 0.001 m 3 m 3 , respectively. The assimilation reduced the average absolute surface bias against the CVS measurements by 0.009 m 3 m 3 , but increased the root zone bias by 0.014 m 3 m 3 . Assimilating the NN retrievals after a localized bias correction yielded slightly lower surface correlation and ubRMSE improvements, but generally the skill differences were small. The assimilation of the physically-based SMAP Level-2 passive soil moisture retrievals using a global bias correction yielded similar skill improvements, as did the direct assimilation of locally bias-corrected SMAP brightness temperatures within the SMAP Level-4 soil moisture algorithm. The results show that global bias correction methods may be able to extract more independent information from SMAP observations compared to local bias correction methods, but without accurate quality control and observation error characterization they are also more vulnerable to adverse effects from retrieval errors related to uncertainties in the retrieval inputs and algorithm. Furthermore, the results show that using global bias correction approaches without a simultaneous re-calibration of the land model processes can lead to skill degradation in other land surface variables. View Full-Text
Keywords: data assimilation; SMAP soil moisture; neural networks; bias correction data assimilation; SMAP soil moisture; neural networks; bias correction

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Kolassa, J.; Reichle, R.H.; Liu, Q.; Cosh, M.; Bosch, D.D.; Caldwell, T.G.; Colliander, A.; Holifield Collins, C.; Jackson, T.J.; Livingston, S.J.; Moghaddam, M.; Starks, P.J. Data Assimilation to Extract Soil Moisture Information from SMAP Observations. Remote Sens. 2017, 9, 1179.
