The Morphology, Dynamics and Potential Hotspots of Land Surface Temperature at a Local Scale in Urban Areas

by Jiong Wang 1,2,*, Qingming Zhan 1,2 and Huagui Guo 1,2
School of Urban Design, Wuhan University, 8 Donghu South Road, Wuhan 430072, China
Collaborative Innovation Center of Geospatial Technology, 129 Luoyu Road, Wuhan 430079, China
Author to whom correspondence should be addressed.
Academic Editors: Benjamin Bechtel, Iphigenia Keramitsoglou, Simone Kotthaus, James A. Voogt, Klemen Zakšek, Magaly Koch and Prasad S. Thenkabail
Remote Sens. 2016, 8(1), 18;
Received: 4 November 2015 / Revised: 3 December 2015 / Accepted: 15 December 2015 / Published: 30 December 2015
Current characterization of the Urban Heat Island (UHI) remains insufficient to support the effective mitigation and adaptation of increasing temperatures in urban areas. Planning and design strategies are restricted to the investigation of temperature anomalies at a city scale. By focusing on Land Surface Temperature of Wuhan, China, this research examines the temperature variations locally where mitigation and adaptation would be more feasible. It shows how local temperature anomalies can be identified morphologically. Technically, the MODerate-resolution Imaging Spectroradiometer satellite image products are used. They are first considered as noisy observations of the latent temperature patterns. The continuous latent patterns of the temperature are then recovered from these discrete observations by using the non-parametric Multi-Task Gaussian Process Modeling. The Multi-Scale Shape Index is then applied in the area of focus to extract the local morphological features. A triplet of shape, curvedness and temperature is formed as the criteria to extract local heat islands. The behavior of the local heat islands can thus be quantified morphologically. The places with critical deformations are identified as hotpots. The hotspots with certain yearly behavior are further associated with land surface composition to determine effective mitigation and adaptation strategies. This research can assist in the temperature and planning field on two levels: (1) the local land surface temperature patterns are characterized by decomposing the variations into fundamental deformation modes to allow a process-based understanding of the dynamics; and (2) the characterization at local scale conforms to planning and design conventions where mitigation and adaptation strategies are supposed to be more practical. The weaknesses and limitations of the study are addressed in the closing section. View Full-Text
Keywords: LST; morphology; local scale; hotspot; yearly dynamics; urban area LST; morphology; local scale; hotspot; yearly dynamics; urban area
Show Figures

Graphical abstract

MDPI and ACS Style

Wang, J.; Zhan, Q.; Guo, H. The Morphology, Dynamics and Potential Hotspots of Land Surface Temperature at a Local Scale in Urban Areas. Remote Sens. 2016, 8, 18.
