VADASE Reliability and Accuracy of Real-Time Displacement Estimation: Application to the Central Italy 2016 Earthquakes

1
Geodesy and Geomatic Division, DICEA—University of Rome “La Sapienza”, via Eudossiana 18, 00184 Rome, Italy
2
Jet Propulsion Laboratory, California Institute of Technology, Pasadena, CA 91109, USA
3
INGV—Istituto Nazionale di Geofisica e Vulcanologia, via di Vigna Murata 605, 00143 Rome, Italy
*
Author to whom correspondence should be addressed.
Now at Ionospheric and Atmospheric Remote Sensing Group, Jet Propulsion Laboratory, California Institute of Technology, Pasadena, California, USA.
Remote Sens. 2018, 10(8), 1201; https://doi.org/10.3390/rs10081201
Received: 16 May 2018 / Revised: 26 July 2018 / Accepted: 27 July 2018 / Published: 31 July 2018
(This article belongs to the Special Issue Environmental Research with Global Navigation Satellite System (GNSS))
  |
PDF [8359 KB, uploaded 14 August 2018]
  |

Abstract

The goal of this article is the illustration of the new functionalities of the VADASE (Variometric Approach for Displacements Analysis Stand-alone Engine) processing approach. VADASE was presented in previous works as an approach able to estimate in real time the velocities and displacements in a global reference frame (ITRF), using high-rate (1 Hz or more) carrier phase observations and broadcast products (orbits, clocks) collected by a stand-alone GNSS receiver, achieving a displacements accuracy within 1–2 cm (usually better) over intervals up to a few minutes. It has been well known since the very first implementation and testing of VADASE that the estimated displacements might be impacted by two different effects: spurious spikes in the velocities due to outliers (consequently, displacements, obtained through velocities integration, are severely corrupted) and trends in the displacements time series, mainly due to broadcast orbit and clock errors. Two strategies are herein introduced, respectively based on Leave-One-Out cross-validation (VADASE-LOO) for a receiver autonomous outlier detection, and on a network augmentation strategy to filter common trends out (A-VADASE); they are combined (first, VADASE-LOO; second, A-VADASE) for a complete solution. Moreover, starting from this VADASE improved solution, an additional strategy is proposed to estimate in real time the overall coseismic displacement occurring at each GNSS receiver. New VADASE advances are successfully applied to the GPS data collected during the recent three strong earthquakes that occurred in Central Italy on 24 August and 26 and 30 October 2016, and the results are herein presented and discussed. The VADASE real-time estimated coseismic displacements are compared to the static ones derived from the daily solutions obtained within the standard post-processing procedure by the Istituto Nazionale di Geofisica e Vulcanologia. View Full-Text
Keywords: GNSS seismology; variometric approach improvements; real-time coseismic displacements; Central Italy 2016 earthquakes GNSS seismology; variometric approach improvements; real-time coseismic displacements; Central Italy 2016 earthquakes
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
