Open AccessArticle
Remote Sens. 2018, 10(4), 547; https://doi.org/10.3390/rs10040547

Multi-Annual Kinematics of an Active Rock Glacier Quantified from Very High-Resolution DEMs: An Application-Case in the French Alps

1
Université Grenoble Alpes, CNRS, Université Savoie Mont-Blanc, Laboratoire Environnements, Dynamiques et Territoire de Montagne (EDYTEM, UMR 5204), 73000 Chambéry, France
2
Université Grenoble Alpes, Irstea, UR ETGR, 2 rue de la Papeterie-BP 76, 38402 St-Martin-d’Hères, France
3
Institut des Géosciences de l’Environnement (IGE, UMR 5001), Université Grenoble Alpes, CNRS, IRD, G-INP, F-38000 Grenoble, France
*
Author to whom correspondence should be addressed.
Received: 11 January 2018 / Revised: 26 March 2018 / Accepted: 29 March 2018 / Published: 3 April 2018
(This article belongs to the Special Issue Remote Sensing of Dynamic Permafrost Regions)
Full-Text   |   PDF [13213 KB, uploaded 3 May 2018]   |

Abstract

Rock glaciers result from the long-term creeping of ice-rich permafrost along mountain slopes. Under warming conditions, deformation is expected to increase, and potential destabilization of those landforms may lead to hazardous phenomena. Monitoring the kinematics of rock glaciers at fine spatial resolution is required to better understand at which rate, where and how they deform. We present here the results of several years of in situ surveys carried out between 2005 and 2015 on the Laurichard rock glacier, an active rock glacier located in the French Alps. Repeated terrestrial laser-scanning (TLS) together with aerial laser-scanning (ALS) and structure-from-motion-multi-view-stereophotogrammetry (SFM-MVS) were used to accurately quantify surface displacement of the Laurichard rock glacier at interannual and pluri-annual scales. Six very high-resolution digital elevation models (DEMs, pixel size <50 cm) of the rock glacier surface were generated, and their respective quality was assessed. The relative horizontal position accuracy (XY) of the individual DEMs is in general less than 2 cm with a co-registration error on stable areas ranging from 20–50 cm. The vertical accuracy is around 20 cm. The direction and amplitude of surface displacements computed between DEMs are very consistent with independent geodetic field measurements (e.g., DGPS). Using these datasets, local patterns of the Laurichard rock glacier kinematics were quantified, pointing out specific internal (rheological) and external (bed topography) controls. The evolution of the surface velocity shows few changes on the rock glacier’s snout for the first years of the observed period, followed by a major acceleration between 2012 and 2015 affecting the upper part of the tongue and the snout. View Full-Text
Keywords: rock glacier deformation; very high-resolution DEM; surface displacement; image correlation; TLS; ALS; SFM-MVS rock glacier deformation; very high-resolution DEM; surface displacement; image correlation; TLS; ALS; SFM-MVS
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
