Open AccessArticle
Remote Sens. 2018, 10(11), 1771;

Underestimates of Grassland Gross Primary Production in MODIS Standard Products

Key Laboratory of Land Surface Pattern and Simulation, Institute of Geographic Sciences and Natural Resources Research, Chinese Academy of Sciences, Beijing 100101, China
College of Geography and Environment, Shandong Normal University, Jinan 250358, China
University of Chinese Academy of Sciences, Beijing 100049, China
Department of Microbiology and Plant Biology, and Center for Spatial Analysis, University of Oklahoma, Norman, OK 73019, USA
Institute of Remote Sensing and Digital Earth, Chinese Academy of Sciences, Beijing 100094, China
Ministry of Education Key Laboratory of Biodiversity Science and Ecological Engineering, Institute of Biodiversity Science, Fudan University, Shanghai, 200438, China
Authors to whom correspondence should be addressed.
Received: 26 September 2018 / Revised: 1 November 2018 / Accepted: 5 November 2018 / Published: 8 November 2018
(This article belongs to the Special Issue Terrestrial Carbon Cycle)
PDF [3900 KB, uploaded 8 November 2018]


As the biggest carbon flux of terrestrial ecosystems from photosynthesis, gross primary productivity (GPP) is an important indicator in understanding the carbon cycle and biogeochemical process of terrestrial ecosystems. Despite advances in remote sensing-based GPP modeling, spatial and temporal variations of GPP are still uncertain especially under extreme climate conditions such as droughts. As the only official products of global spatially explicit GPP, MOD17A2H (GPPMOD) has been widely used to assess the variations of carbon uptake of terrestrial ecosystems. However, systematic assessment of its performance has rarely been conducted especially for the grassland ecosystems where inter-annual variability is high. Based on a collection of GPP datasets (GPPEC) from a global network of eddy covariance towers (FluxNet), we compared GPPMOD and GPPEC at all FluxNet grassland sites with more than five years of observations. We evaluated the performance and robustness of GPPMOD in different grassland biomes (tropical, temperate, and alpine) by using a bootstrapping method for calculating 95% confident intervals (CI) for the linear regression slope, coefficients of determination (R2), and root mean square errors (RMSE). We found that GPPMOD generally underestimated GPP by about 34% across all biomes despite a significant relationship (R2 = 0.66 (CI, 0.63–0.69), RMSE = 2.46 (2.33–2.58) g Cm−2 day−1) for the three grassland biomes. GPPMOD had varied performances with R2 values of 0.72 (0.68–0.75) (temperate), 0.64 (0.59–0.68) (alpine), and 0.40 (0.27–0.52) (tropical). Thus, GPPMOD performed better in low GPP situations (e.g., temperate grassland type), which further indicated that GPPMOD underestimated GPP. The underestimation of GPP could be partly attributed to the biased maximum light use efficiency (εmax) values of different grassland biomes. The uncertainty of the fraction of absorbed photosynthetically active radiation (FPAR) and the water scalar based on the vapor pressure deficit (VPD) could have other reasons for the underestimation. Therefore, more accurate estimates of GPP for different grassland biomes should consider improvements in εmax, FPAR, and the VPD scalar. Our results suggest that the community should be cautious when using MODIS GPP products to examine spatial and temporal variations of carbon fluxes. View Full-Text
Keywords: GPP; MOD17; grassland ecosystem; grassland types; FluxNet GPP; MOD17; grassland ecosystem; grassland types; FluxNet

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Zhu, X.; Pei, Y.; Zheng, Z.; Dong, J.; Zhang, Y.; Wang, J.; Chen, L.; Doughty, R.B.; Zhang, G.; Xiao, X. Underestimates of Grassland Gross Primary Production in MODIS Standard Products. Remote Sens. 2018, 10, 1771.
