Rut Depth Evaluation of a Triple-Bogie System for Forwarders—Field Trials with TLS Data Support

1
School of Agricultural, Forest and Food Sciences (HAFL), Bern University of Applied Sciences, 3052 Zollikofen, Switzerland
2
Staatsbetrieb Sachsenforst, Maschinenstation Königstein, 01824 Königstein, Germany
*
Author to whom correspondence should be addressed.
Sustainability 2020, 12(16), 6412; https://doi.org/10.3390/su12166412
Received: 19 June 2020 / Revised: 6 August 2020 / Accepted: 7 August 2020 / Published: 10 August 2020
In 2019, the machine manufacturer HSM presented a forwarder prototype for timber hauling in cut-to-length processes fitted with a new 10-wheel triple-bogie (TB) setup approach aimed at promoting sustainable forest management by reducing the ecological impact of forest operations, especially under soft-soil working conditions. The purpose of our study was to assess the resulting soil-protection effect emerging from additional wheel-contact surface area. For this, the rut development under known cumulative weight, related to the soil conditions of shear strength and moisture content, was recorded for later comparison. Additional terrestrial laser scanning (TLS) was used to generate a multi-temporal digital terrain model (DTM) in order to enhance the data sample, assess data quality, and facilitate visualization of the impact of local disturbance factors. In all TB configurations, a rut depth of 10 cm (5.8–7.2 cm) was not exceeded after the hauling of a reference amount of 90 m3 of timber (average soil shear strength reference of 67 kPa, volumetric water content (VMC) 43%). Compared to a reference dataset, all observed configurations ranked in the lowest-impact machine categories on related soil stability classes, and the configuration without bogie tracks revealed the highest machine weight to weight distribution trade-off potential. View Full-Text
Keywords: forest operation; forwarder; cut-to-length; soft soil; soil protection; rut depth; TLS data forest operation; forwarder; cut-to-length; soft soil; soil protection; rut depth; TLS data
Show Figures

Figure 1
