Open AccessArticle
Materials 2016, 9(11), 897;

Raman and Conductivity Analysis of Graphene for Biomedical Applications

Department of Physics, University of Texas at El Paso, El Paso, TX 79968, USA
Division of Engineering, Department of Neurologic Surgery, Mayo Clinic, Rochester, MN 55905, USA
Border Biomedical Research Center, University of Texas at El Paso, El Paso, TX 79968, USA
Author to whom correspondence should be addressed.
Academic Editor: Jie Zheng
Received: 5 October 2016 / Revised: 1 November 2016 / Accepted: 1 November 2016 / Published: 4 November 2016
(This article belongs to the Special Issue Smart Biomaterials and Biointerfaces)
Full-Text   |   PDF [4480 KB, uploaded 8 November 2016]   |


In this study, we present a comprehensive investigation of graphene’s optical and conductive properties using confocal Raman and a Drude model. A comparative analysis between experimental findings and theoretical predictions of the material’s changes and improvements as it transitioned from three-dimensional graphite is also presented and discussed. Besides spectral recording by Raman, which reveals whether there is a single, a few, or multi-layers of graphene, the confocal Raman mapping allows for distinction of such domains and a direct visualization of material inhomogeneity. Drude model employment in the analysis of the far-infrared transmittance measurements demonstrates a distinct increase of the material’s conductivity with dimensionality reduction. Other particularly important material characteristics, including carrier concentration and time constant, were also determined using this model and presented here. Furthermore, the detection of micromolar concentration of dopamine on graphene surfaces not only proves that the Raman technique facilitates ultrasensitive chemical detection of analytes, besides offering high information content about the biomaterial under study, but also that carbon-based materials are biocompatible and favorable micro-environments for such detection. Such information is valuable for the development of bio-medical sensors, which is the main application envisioned for this analysis. View Full-Text
Keywords: biomaterials; confocal Raman mapping; Drude model; conductivity; infrared absorption; dopamine detection biomaterials; confocal Raman mapping; Drude model; conductivity; infrared absorption; dopamine detection

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Qiu, C.; Bennet, K.E.; Khan, T.; Ciubuc, J.D.; Manciu, F.S. Raman and Conductivity Analysis of Graphene for Biomedical Applications. Materials 2016, 9, 897.
