Electrochemical Analysis of Carbon-Based Supercapacitors Using Finite Element Modeling and Impedance Spectroscopy
Abstract
1. Introduction
2. Materials and Methods
2.1. Materials and Cell Manufacturing
2.2. Experimental Setups
2.3. Finite Element Model (FEM)
3. Results and Discussion
3.1. Experimental Results
3.2. FEM Results
4. Conclusions
Author Contributions
Funding
Data Availability Statement
Acknowledgments
Conflicts of Interest
Abbreviations
AC | Activated Carbon |
CNTs | Carbon Nanotubes |
CV | Cyclic Voltammetry |
EC | Equivalent Circuit |
EDL | Electric Double Layer |
EDLC | Electric Double Layer Capacitor |
EIS | Impedance Spectroscopy |
EV | Electric Vehicle |
FEM | Finite Element Modeling |
G | Graphite |
HESS | Hybrid Energy Storage System |
IL | Ionic Liquid |
LIB | Lithium-Ion Battery |
MD | Molecular Dynamics |
MPNP | Modified Poisson–Nernst–Planck |
OCV | Open Circuit Voltage |
PDE | Partial Differential Equations |
PNP | Poisson–Nernst–Planck |
SSA | Specific Surface Area |
SC | Supercapacitor |
