A Detailed Review of Partial Discharge Detection Methods for SiC Power Modules Under Square-Wave Voltage Excitation

Akbar, Ghulam; Di Fatta, Alessio; Rizzo, Giuseppe; Ala, Guido; Romano, Pietro; Imburgia, Antonino

doi:10.3390/en17225793

Open AccessReview

A Detailed Review of Partial Discharge Detection Methods for SiC Power Modules Under Square-Wave Voltage Excitation

by

Ghulam Akbar

,

Alessio Di Fatta

^*

,

Giuseppe Rizzo

,

Guido Ala

,

Pietro Romano

^*

and

Antonino Imburgia

L.E.PR.E. High Voltage Laboratory, Department of Engineering, University of Palermo, 90133 Palermo, Italy

^*

Authors to whom correspondence should be addressed.

Energies 2024, 17(22), 5793; https://doi.org/10.3390/en17225793

Submission received: 29 October 2024 / Revised: 15 November 2024 / Accepted: 18 November 2024 / Published: 20 November 2024

(This article belongs to the Section F6: High Voltage)

Download

Browse Figures

Versions Notes

Abstract

Silicon carbide (SiC) power modules are increasingly being used in high-voltage and high-frequency applications due to their superior electrical and thermal qualities. However, the issue of the partial discharge (PD) phenomenon raises serious reliability difficulties resulting in insulation failure, performance degradation, and potential device collapse. This paper provides a thorough assessment of the current PD detection strategies in SiC power modules. The issues provided by SiC devices’ distinct operational features, such as high switching frequencies and higher voltage stresses, which hinder PD detection and mitigation, are widely investigated. This review compares the effectiveness, benefits, and limitations of various detection methods, emphasizing the need for better strategies to ensure long-term reliability and performance. This study gives an in-depth overview of the numerous forms of PD phenomena that occur in power modules, including internal and surface discharges, as well as how they appear under various detection systems. It examines the performance of several methods for power module technologies such as SiC. To address these PD issues, this article proposes ways to improve reliability and detection accuracy.

Keywords: SiC modules; PD detection methods; square wave excitation
