An FCS-MPC Strategy for Series APF Based on Deadbeat Direct Compensation
Abstract
:1. Introduction
2. The System Structure and Mathematical Model of SAPF
3. The DBDC-FCS-MPC Strategy for SAPF
3.1. The Reference Voltage Generation Mechanism Based on Direct Control
3.2. The Reference Current Generation Mechanism Based on DBC
3.3. FCS-MPC of SAPF
4. Simulation Verification and Experimental Analysis
4.1. Simulation Verification
4.1.1. Dynamic and Steady-State Performance of the Voltage Amplitude Compensation
4.1.2. Compensation Performance of the Full-Frequency Harmonic Voltage
4.2. Experimental Analysis
5. Conclusions
