Piezoelectric Energy Harvesting Gyroscopes: Comparative Modeling and Effectiveness
Abstract
:1. Introduction
2. Modeling of Energy Harvesting Microgyroscope
2.1. Microgyroscope Energy Harvesting: Governing Equations of Motion
2.1.1. Open-Circuit (OC) Modeling
2.1.2. Constant (Average) Electric Field Open Circuit (CE-γ)
2.1.3. Constant (Average) Electric Field (CE)
2.2. Static and Eigenvalue Problem Analyses of the Multifunctional Microgyroscope
2.3. Differential Quadrature Method (DQM)
3. Model Comparison and Results
4. Conclusions
