Theoretical and Experimental Investigation of Explosion Characteristics of Hydrogen Explosion in a Closed Vessel
Abstract
:1. Introduction
2. Theoretical Model
Basic Assumption
3. Experimental Details
Experimental Set-Up
4. Results and Discussion
4.1. Typical Pressure Profiles
4.2. Validation of the Pressure Prediction Model
4.3. Analysis of the Predictive Model
4.4. Analysis of Explosion Parameters
5. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
