Real-Time Emission Prediction with Detailed Chemistry under Transient Conditions for Hardware-in-the-Loop Simulations
Abstract
:1. Introduction
1.1. Motivation for HiL-Based Simulations
1.2. Challenges in Virtual ECU Calibration
2. Real-Time Powertrain Models
2.1. Reference Powertrain, Vehicle, and Fuel
2.2. Engine Air Path and Powertrain Modeling
2.3. Stochastic Reactor Model with Tabulated Chemistry for Real-Time Emissions Prediction
3. Model Parametrization and Simulation Environment
3.1. Co-Simulation Framework Setup
3.1.1. Engine Air Path Model Calibration
- Engine mapping without EGR in warm conditions (Coolant temperature of 90 °C);
- Engine mapping with EGR in warm conditions (Coolant temperature of 90 °C);
- Full load curve in warm conditions (Coolant temperature of 90 °C).
3.1.2. Combustion Model Parametrization
3.1.3. Combustion Model Interface
3.2. FMU for HiL-Based Applications
4. Performance Evaluation
4.1. Steady-State Simulation
4.1.1. Engine Air Path Model Validation
4.1.2. In-Cylinder Combustion Model Optimization Results
4.2. Transient Simulation
5. Conclusions and Outlook
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Acknowledgments
Conflicts of Interest
References
