Scribing Method for Carbon Perovskite Solar Modules

SPECIFIC, College of Engineering, Bay Campus, Swansea University, Swansea SA1 8EN, UK
Author to whom correspondence should be addressed.
Energies 2020, 13(7), 1589;
Received: 10 March 2020 / Revised: 24 March 2020 / Accepted: 26 March 2020 / Published: 1 April 2020
(This article belongs to the Special Issue Highly Efficient and Stable Hybrid Perovskite Solar Cells)
The fully printable carbon triple-mesoscopic perovskite solar cell (C-PSC) has already demonstrated good efficiency and long-term stability, opening the possibility of lab-to-fab transition. Modules based on C-PSC architecture have been reported and, at present, are achieved through the accurate registration of each of the patterned layers using screen-printing. Modules based on this approach were reported with geometric fill factor (g-FF) as high as 70%. Another approach to create the interconnects, the so-called scribing method, was reported to achieve more than 90% g-FF for architectures based on evaporated metal contacts, i.e., without a carbon counter electrode. Here, for the first time, we adopt the scribing method to selectively remove materials within a C-PSC. This approach allowed a deep and selective scribe to open an aperture from the transparent electrode through all the layers, including the blocking layer, enabling a direct contact between the electrodes in the interconnects. In this work, a systematic study of the interconnection area between cells is discussed, showing the key role of the FTO/carbon contact. Furthermore, a module on 10 × 10 cm2 substrate with the optimised design showing efficiency over 10% is also demonstrated. View Full-Text
Keywords: perovskite; solar cells; carbon; screen-printing; up-scaling; module; scribing perovskite; solar cells; carbon; screen-printing; up-scaling; module; scribing
Show Figures

Graphical abstract

MDPI and ACS Style

Meroni, S.M.P.; Hooper, K.E.A.; Dunlop, T.; Baker, J.A.; Worsley, D.; Charbonneau, C.; Watson, T.M. Scribing Method for Carbon Perovskite Solar Modules. Energies 2020, 13, 1589.

AMA Style

Meroni SMP, Hooper KEA, Dunlop T, Baker JA, Worsley D, Charbonneau C, Watson TM. Scribing Method for Carbon Perovskite Solar Modules. Energies. 2020; 13(7):1589.

Chicago/Turabian Style

Meroni, Simone M. P., Katherine E. A. Hooper, Tom Dunlop, Jenny A. Baker, David Worsley, Cecile Charbonneau, and Trystan M. Watson. 2020. "Scribing Method for Carbon Perovskite Solar Modules" Energies 13, no. 7: 1589.
