Investigation of the Concepts to Increase the Dew Point Temperature for Thermal Energy Recovery from Flue Gas, Using Aspen®

1
Institute of Fluid Mechanics (LSTM), Friedrich-Alexander University (FAU), 91058 Erlangen, Germany
2
Erlangen Graduate School in Advanced Optical Technologies (SAOT), 91054 Erlangen, Germany
*
Author to whom correspondence should be addressed.
Energies 2019, 12(9), 1585; https://doi.org/10.3390/en12091585
Received: 31 March 2019 / Revised: 18 April 2019 / Accepted: 23 April 2019 / Published: 26 April 2019
(This article belongs to the Special Issue Fluid Flow and Heat Transfer)
Thermal energy of flue gases (FG) dissipating from industrial facilities into the environment, constitute around 20% of the total dissipated thermal energy. Being part of the FG, water vapour carries thermal energy out of the system in the form of the latent heat, which can be recovered by condensation, thus increasing the overall efficiency of an industrial process. The limiting factor in this case is the low dew point temperature (usually 40–60 °C) of the water vapour in the FG. The increase of the dew point temperature can be achieved by increasing the water content or pressure. Taking these measures as a basis, the presented work investigated the following concepts for increasing the dew point temperature: humidification of the flue gas using water, humidification using steam, compression of the FG and usage of the steam ejector. Modelling of these concepts was performed using the commercial software Aspen®. The humidification of the FG using water resulted in the negligible increase in the dew point (3 °C). Using steam humidification the temperatures of up to 92 °C were reached, while the use of steam ejector led to few degrees higher dew point temperatures. However, both concepts proved to be energy demanding, due to the energy requirements for the steam generation. The FG compression enabled the achievement of a 97 °C dew point temperature, being both energy-efficient and exhibiting the lowest energy cost. View Full-Text
Keywords: thermal energy recovery; flue gas; dew point temperature; condensation; Aspen® thermal energy recovery; flue gas; dew point temperature; condensation; Aspen®
Show Figures

Figure 1

MDPI and ACS Style

Fedorova, N.; Aziziyanesfahani, P.; Jovicic, V.; Zbogar-Rasic, A.; Khan, M.J.; Delgado, A. Investigation of the Concepts to Increase the Dew Point Temperature for Thermal Energy Recovery from Flue Gas, Using Aspen®. Energies 2019, 12, 1585.
