Energies 2017, 10(7), 868; https://doi.org/10.3390/en10070868

A Stochastic Programming Approach for the Planning and Operation of a Power to Gas Energy Hub with Multiple Energy Recovery Pathways

1
Department of Chemical Engineering, University of Waterloo, 200 University Avenue West, Waterloo, ON N2L 3G1, Canada
2
Department of Electrical and Computer Engineering, University of Waterloo, 200 University Avenue West, Waterloo, ON N2L 3G1, Canada
*
Author to whom correspondence should be addressed.
Received: 31 May 2017 / Revised: 22 June 2017 / Accepted: 24 June 2017 / Published: 28 June 2017
(This article belongs to the Special Issue Energy Production Systems)
Full-Text   |   PDF [2723 KB, uploaded 29 June 2017]   |

Abstract

There is a need for energy storage to improve the efficiency and effectiveness of energy distribution with the increasing penetration of renewable energy sources. Among the various energy storage technologies being developed, ‘power-to-gas’ is one such concept which has gained interest due to its ability to provide long term energy storage and recover the energy stored through different energy recovery pathways. Incorporation of such systems within the energy infrastructure requires analysis of the key factors influencing the operation of electrolyzers and hydrogen storage. This study focusses on assessing the benefits power-to-gas energy storage while accounting for uncertainty in the following three key parameters that could influence the operation of the energy system: (1) hourly electricity price; (2) the number of fuel cell vehicles serviced; and (3) the amount of hydrogen refueled. An hourly time index is adopted to analyze how the energy hub should operate under uncertainty. The results show that there is a potential economic benefit for the power-to-gas system if it is modeled using the two-stage stochastic programming approach in comparison to a deterministic optimization study. The power-to-gas system also offers environmental benefits both from the perspective of the producer and end user of hydrogen. View Full-Text
Keywords: power to gas; fuel cell vehicles; stochastic programming; demand response; Hydrogen Energy power to gas; fuel cell vehicles; stochastic programming; demand response; Hydrogen Energy
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Mukherjee, U.; Maroufmashat, A.; Narayan, A.; Elkamel, A.; Fowler, M. A Stochastic Programming Approach for the Planning and Operation of a Power to Gas Energy Hub with Multiple Energy Recovery Pathways. Energies 2017, 10, 868.

Show more citation formats Show less citations formats

Note that from the first issue of 2016, MDPI journals use article numbers instead of page numbers. See further details here.
