High-Precision Trace Hydrogen Sensing by Multipass Raman Scattering
Abstract
:1. Introduction
2. Background
Method | Lowest Detected Conc. (ppm) | Estimated LOD (ppm) | Measurement Time (s) | Reference |
---|---|---|---|---|
Chemiresistors | 50 | 0.01 | ∼20 | [17] |
Schottky diode | 10,000 | 0.1 | ∼10 | [44] |
MEMS | 6 | 0.1 | ∼2 | [45] |
IR absorption | 5000 at 0.1 MPa | 1000 | 1 | [23] |
Raman: | ||||
• PARS | 10 at 0.3 MPa | 3.4 | ∼10 | [28] |
• FERS | 5 | 4.7 | 1–100 | [31] |
• CERS | 100 at 0.1 MPa 0.5 at 0.1 MPa | 0.069 - | 500 2500 | [36] |
• Multipass cavity | 0.075 at 0.2 MPa | 0.06 | 600 | This work |
3. Instrumentation and Data Collection
4. Methodology for Quantification of Detected H Concentration
4.1. Numerical Curve Integral
4.2. Least-Squares Fitting (LSQF) Data Comparison
4.3. Gaussian Fitting Method
4.4. Normalization to Oxygen Concentration
4.5. Method Comparison
5. Results and Discussion
6. Conclusions
