Unmanned Aerial System-Based Data Ferrying over a Sensor Node Station Network in Maize
Abstract
:1. Introduction
2. Materials and Methods
2.1. Proposed UAS Data Ferrying Designs
2.1.1. Criteria
2.1.2. Constraints
2.1.3. Design Parameters and Proposed UAS Data Ferrying Designs
- Three wireless technologies designed for industrial/commercial applications that are mostly used for agricultural farm operations were explored for this study: long-range radio (LoRa), ZigBee, and general packet radio service (GPRS). The LoRa protocol was introduced by the LoRa Alliance for the low power and wide-area Internet of Things (IoT) communication associated with the indoor transmission, Pitì et al. [24]. The LoRa gateway can collect data from LoRa nodes to construct the topology of a star network and may communicate with a cloud server over a long communication for high scalability. The LoRa protocol has a wide range of applicability in precision agriculture [6,25,26]. Sensor nodes based on the ZigBee wireless protocol in the agricultural field can communicate with a router up to 100 m. Recent studies have employed ZigBee for precision agriculture [27,28,29] because of its low power consumption, low cost, self-forming characteristics, and suitable communication range. General packet radio service (GPRS)/3G/4G employs packet data (a bit of data that is packaged for transmission) service for GSM-based cellular phones. The GPRS technology communication rates depend on consumer volume where consumers share common communication channels and resources and frequently experience variable delays and throughputs. The sensors could be interfaced to the GPRS system sensor board to obtain and transmit information to the remote server through the GPRS board, which depends on a GSM/GPRS mobile network. Some studies have deployed a GSM/GPRS mobile network for applications in precision agriculture [30,31,32].
- Fixed-wing and multi-rotor UAS designs were considered as these are mostly used for agricultural operations. Fixed-wing UAS has a longer flight endurance capacity while multi-rotors can provide for stable and easy vertical take-off and landing [33].
- The power supply to the wireless communication setup on the UAS could be tethered from the UAS or be powered from an external battery source mounted on the UAS.
- Transmitted data could be stored on the memory storage of the UAS or transmitted to the cloud.
2.1.4. Decision Matrix
2.2. Field Experiment Description
2.3. Sensors on the UAS Data Ferry and Node Stations
2.3.1. UAS Data Ferry Sensors
RF 450 Radio
Dipole Omnidirectional Antenna
Wave Omnidirectional Antenna
2.3.2. Node Station Sensors
CR1000X Datalogger
GS-1 Soil Water Sensor
SI-111 Infrared Radiometer
2.3.3. Unmanned Aerial System (UAS)
Matrice 600 Pro Hexacopter
2.4. Experiment Design
3. Results
4. Discussion
5. Summary and Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
- Behzadan, A.; Anpalagan, A.; Woungang, I.; Ma, B.; Chao, H.-C. An Energy-Efficient Utility-Based Distributed Data Routing Scheme for Heterogenous Sensor Networks. Wirel. Commun. Mob. Comput. 2015, 16, 421–430. [Google Scholar] [CrossRef]
- Yick, J.; Mukherjee, B.; Ghosal, D. Wireless Sensor Network Survey. Comput. Netw. 2008, 52, 2292–2330. [Google Scholar] [CrossRef]
- Adamala, S.; Raghuwanshi, N.S.; Mishra, A. Development of Surface Irrigation Systems Design and Evaluation Software (SIDES). Comput. Electron. Agric. 2014, 100, 100–109. [Google Scholar] [CrossRef]
- Camilli, A.; Cugnasca, C.E.; Saraiva, A.M.; Hirakawa, A.R.; Corrêa, P.L.P. From Wireless Sensors to Field Mapping: Anatomy of an Application for Precision Agriculture. Comput. Electron. Agric. 2007, 58, 25–36. [Google Scholar] [CrossRef]
- Kim, Y.D.; Yang, Y.M.; Kang, W.S.; Kim, D.K. On the Design of Beacon Based Wireless Sensor Network for Agricultural Emergency Monitoring Systems. Comput. Stand. Interfaces 2014, 36, 288–299. [Google Scholar] [CrossRef]
- Siddique, A.; Prabhu, B.; Chaskar, A.; Pathak, R. A Review on Intelligent Agriculture Service Platform with Lora Based Wireless Sensor Network. Int. Res. J. Eng. Technol. 2019, 100, 2539–2542. [Google Scholar]
- Bhargava, K.; Kashyap, A.; Gonsalves, T.A. Wireless Sensor Network Based Advisory System for Apple Scab Prevention. In Proceedings of the 2014 20th National Conference on Communications, NCC, Kanpur, India, 28 February–2 March 2014. [Google Scholar]
- Gonçalves, L.B.L.; Costa, F.G.; Neves, L.A.; Ueyama, J.; Zafalon, G.F.D.; Montez, C.; Pinto, A.S.R. Influence of Mobility Models in Precision Spray Aided by Wireless Sensor Networks. In Proceedings of the Journal of Physics, Yokohama, Japan, 26–30 May 2014; Conference Series; IOP Science: Bristol, UK, 2014; Volume 574. [Google Scholar]
- Kwong, K.H.; Wu, T.T.; Goh, H.G.; Sasloglou, K.; Stephen, B.; Glover, I.; Shen, C.; Du, W.; Michie, C.; Andonovic, I. Practical Considerations for Wireless Sensor Networks in Cattle Monitoring Applications. Comput. Electron. Agric. 2012, 81, 33–44. [Google Scholar] [CrossRef]
- Zia, H.; Harris, N.R.; Merrett, G.V.; Rivers, M.; Coles, N. The Impact of Agricultural Activities on Water Quality: A Case for Collaborative Catchment-Scale Management Using Integrated Wireless Sensor Networks. Comput. Electron. Agric. 2013, 96, 126–138. [Google Scholar] [CrossRef] [Green Version]
- Malaver, A.; Motta, N.; Corke, P.; Gonzalez, F. Development and Integration of a Solar Powered Unmanned Aerial Vehicle and a Wireless Sensor Network to Monitor Greenhouse Gases. Sensors 2015, 15, 4072–4096. [Google Scholar] [CrossRef]
- Misra, S.; Singh, S. Localized Policy-Based Target Tracking Using Wireless Sensor Networks. ACM Trans. Sens. Netw. 2012, 8, 1–30. [Google Scholar] [CrossRef]
- Coates, R.W.; Delwiche, M.J.; Broad, A.; Holler, M. Wireless Sensor Network with Irrigation Valve Control. Comput. Electron. Agric. 2013, 96, 13–22. [Google Scholar] [CrossRef]
- Morais, R.; Fernandes, M.A.; Matos, S.G.; Serôdio, C.; Ferreira, P.J.S.G.; Reis, M.J.C.S. A ZigBee Multi-Powered Wireless Acquisition Device for Remote Sensing Applications in Precision Viticulture. Comput. Electron. Agric. 2008, 62, 94–106. [Google Scholar] [CrossRef]
- Garlando, U.; Bar-On, L.; Avni, A.; Shacham-Diamand, Y.; Demarchi, D. Plants and Environmental Sensors for Smart Agriculture, an Overview. Proc. IEEE Sens. 2020, 2020, 2020–2023. [Google Scholar] [CrossRef]
- Akyildiz, I.F.; Kasimoglu, I.H. Wireless Sensor and Actor Networks: Research Challenges. Ad Hoc Netw. 2004, 2, 351–367. [Google Scholar] [CrossRef]
- Ojha, T.; Misra, S.; Raghuwanshi, N.S. Wireless Sensor Networks for Agriculture: The State-of-the-Art in Practice and Future Challenges. Comput. Electron. Agric. 2015, 118, 66–84. [Google Scholar] [CrossRef]
- Sun, P.; Boukerche, A. Performance Modeling and Analysis of a UAV Path Planning and Target Detection in a UAV-Based Wireless Sensor Network. Comput. Netw. 2018, 146, 217–231. [Google Scholar] [CrossRef]
- Kirichek, R.; Kulik, V. Long-Range Data Transmission on Flying Ubiquitous Sensor Networks (FUSN) by Using LPWAN Protocols. In Proceedings of the International Conference on Distributed Computer and Communication Networks, Moscow, Russia, 21–25 November 2016; Springer: Cham, Switzerland, 2016; pp. 442–453. [Google Scholar]
- Wu, Q.; Zeng, Y.; Zhang, R. Joint Trajectory and Communication Design for Multi-UAV Enabled Wireless Networks. IEEE Trans. Wirel. Commun. 2018, 17, 2109–2121. [Google Scholar] [CrossRef] [Green Version]
- Zeng, Y.; Xu, J.; Zhang, R. Energy Minimization for Wireless Communication with Rotary-Wing UAV. IEEE Trans. Wirel. Commun. 2019, 18, 2329–2345. [Google Scholar] [CrossRef] [Green Version]
- Gili, P.; Civera, M.; Roy, R.; Surace, C. An Unmanned Lighter-than-Air Platform for Large Scale Land Monitoring. Remote Sens. 2021, 13, 2523. [Google Scholar] [CrossRef]
- Jawad, H.M.; Nordin, R.; Gharghan, S.K.; Jawad, A.M.; Ismail, M. Energy-Efficient Wireless Sensor Networks for Precision Agriculture: A Review. Sensors 2017, 17, 1781. [Google Scholar] [CrossRef] [Green Version]
- Pitì, A.; Verticale, G.; Rottondi, C.; Capone, A.; Lo Schiavo, L. The Role of Smart Meters in Enabling Real-Time Energy Services for Households: The Italian Case. Energies 2017, 10, 199. [Google Scholar] [CrossRef] [Green Version]
- Ilie-Ablachim, D.; Pǎtru, G.C.; Florea, I.M.; Rosner, D. Monitoring Device for Culture Substrate Growth Parameters for Precision Agriculture: Acronym: MoniSen. In Proceedings of the 15th RoEduNet Conference: Networking in Education and Research, Bucharest, Romania, 2 August 2016; pp. 1–7. [Google Scholar]
- Gil-Lebrero, S.; Quiles-Latorre, F.J.; Ortiz-López, M.; Sánchez-Ruiz, V.; Gámiz-López, V.; Luna-Rodríguez, J.J. Honey Bee Colonies Remote Monitoring System. Sensors 2016, 17, 55. [Google Scholar] [CrossRef] [Green Version]
- Cancela, J.J.; Fandiño, M.; Rey, B.J.; Martínez, E.M. Automatic Irrigation System Based on Dual Crop Coefficient, Soil and Plant Water Status for Vitis Vinifera (Cv Godello and Cv Mencía). Agric. Water Manag. 2015, 151, 52–63. [Google Scholar] [CrossRef]
- Rao, Y.; Jiang, Z.H.; Lazarovitch, N. Investigating Signal Propagation and Strength Distribution Characteristics of Wireless Sensor Networks in Date Palm Orchards. Comput. Electron. Agric. 2016, 124, 107–120. [Google Scholar] [CrossRef]
- Huircán, J.I.; Muñoz, C.; Young, H.; Von Dossow, L.; Bustos, J.; Vivallo, G.; Toneatti, M. ZigBee-Based Wireless Sensor Network Localization for Cattle Monitoring in Grazing Fields. Comput. Electron. Agric. 2010, 74, 258–264. [Google Scholar] [CrossRef]
- Gutierrez, J.; Villa-Medina, J.F.; Nieto-Garibay, A.; Porta-Gandara, M.A. Automated Irrigation System Using a Wireless Sensor Network and GPRS Module. IEEE Trans. Instrum. Meas. 2014, 63, 166–176. [Google Scholar] [CrossRef]
- Zhang, R.; Chen, L.; Guo, J.; Meng, Z.; Xu, G. An Energy-Efficient Wireless Sensor Network Used for Farmland Soil Moisture Monitoring. Proc. IET Conf. Publ. 2010, 2010, 2–6. [Google Scholar]
- Navarro-Hellín, H.; Torres-Sánchez, R.; Soto-Valles, F.; Albaladejo-Pérez, C.; López-Riquelme, J.A.; Domingo-Miguel, R. A Wireless Sensors Architecture for Efficient Irrigation Water Management. Agric. Water Manag. 2015, 151, 64–74. [Google Scholar] [CrossRef] [Green Version]
- Boon, M.A.; Drijfhout, A.P.; Tesfamichael, S. Comparison of a Fixed-Wing and Multi-Rotor UAV for Environmental Mapping Applications: A Case Study. Int. Arch. Photogramm. Remote Sens. Spat. Inf. Sci.-ISPRS Arch. 2017, 42, 47–54. [Google Scholar] [CrossRef] [Green Version]
- Singh, J. Design and Evaluation of Unmanned Aerial System-Based Design and Evaluation of Unmanned Aerial System-Based Wireless Sensor Network for Irrigation Management Wireless Sensor Network for Irrigation Management, Lincoln; The University of Nebraska-Lincoln: Lincoln, NE, USA, 2021. [Google Scholar]
- Singh, J.; Heeren, D.M.; Rudnick, D.R.; Woldt, W.E.; Bai, G.; Ge, Y.; Luck, J.D. Soil Structure and Texture Effects on the Precision of Soil Water Content Measurements with a Capacitance-Based Electromagnetic Sensor. Trans. ASABE 2020, 63, 141–152. [Google Scholar] [CrossRef] [Green Version]
- Singh, J.; Ge, Y.; Heeren, D.M.; Walter-shea, E.; Neale, C.M.U.; Irmak, S.; Woldt, W.E.; Bai, G.; Bhatti, S.; Maguire, M.S. Inter-Relationships between Water Depletion and Temperature Differential in Row Crop Canopies in a Sub-Humid Climate. Agric. Water Manag. 2021, 256, 107061. [Google Scholar] [CrossRef]
- Singh, J.; Heeren, D.M.; Ge, Y.; Bai, G.; Neale, C.M.U.; Maguire, S.; Bhatti, S. Sensor-Based Irrigation of Maize and Soybean in East-Central Nebraska under a Sub-Humid Climate 2021 Annual International Meeting. In Proceedings of the ASABE 2021 Annual International Meeting, American Society of Agricultural and Biological Engineers, St. Joseph, MI, USA, 17–20 July 2021; Volume 4, pp. 1–12. [Google Scholar]
- Tzounis, A.; Katsoulas, N.; Bartzanas, T.; Kittas, C. Internet of Things in Agriculture, Recent Advances and Future Challenges. Biosyst. Eng. 2017, 164, 31–48. [Google Scholar] [CrossRef]
- Kour, V.P.; Arora, S. Recent Developments of the Internet of Things in Agriculture: A Survey. IEEE Access 2020, 8, 129924–129957. [Google Scholar] [CrossRef]
- Mahmoud, M.S.; Mohamad, A.A.H. A Study of Efficient Power Consumption Wireless Communication Techniques/ Modules for Internet of Things (IoT) Applications. Adv. Internet Things 2016, 06, 19–29. [Google Scholar] [CrossRef] [Green Version]
- Wixted, A.J.; Kinnaird, P.; Larijani, H.; Tait, A.; Ahmadinia, A.; Strachan, N. Evaluation of LoRa and LoRaWAN for Wireless Sensor Networks. In Proceedings of the 2016 IEEE SENSORS, Orlando, FL, USA, 30 October–3 November 2016; pp. 5–7. [Google Scholar] [CrossRef]
- Reda, H.T.; Daely, P.T.; Kharel, J.; Shin, S.Y. On the Application of IoT: Meteorological Information Display System Based on LoRa Wireless Communication. IETE Tech. Rev. 2017, 35, 256–265. [Google Scholar] [CrossRef]
- Lloret, J.; Sendra, S.; Ardid, M.; Rodrigues, J.J.P.C. Underwater Wireless Sensor Communications in the 2.4 GHz ISM Frequency Band. Sensors 2012, 12, 4237–4264. [Google Scholar] [CrossRef] [Green Version]
- Nielsen, R.L. Grain Fill Stages in Corn. Corny News Network, Purdue University. 2017. Available online: http://www.king.corn/news/timeless/GrainFill.html (accessed on 9 February 2022).
- Trihinas, D.; Agathocleous, M.; Avogian, K.; Katakis, I. FlockAI: A Testing Suite for Ml-Driven Drone Applications. Future Internet 2021, 13, 317. [Google Scholar] [CrossRef]
Criteria 1 Wireless Technology | Criteria 2 UAS | Criteria 3 Power Supply | Criteria 4 Data Storage | Constraint 1 Cost | Constraint 2 Adoptability | Total | |
---|---|---|---|---|---|---|---|
Design A | 2 | 1 | 1 | 1 | 3 | 3 | 11 |
Design B | 3 | 2 | 2 | 2 | 4 | 5 | 18 |
Design C | 1 | 1 | 2 | 2 | 4 | 3 | 13 |
Design D | 2 | 2 | 1 | 1 | 5 | 5 | 16 |
Design E | 3 | 1 | 1 | 1 | 3 | 3 | 12 |
Design F | 1 | 2 | 2 | 2 | 5 | 4 | 16 |
Maize Growing Season | Planting Date | Vegetative Period | Reproductive Period |
---|---|---|---|
2020 | 11 May | 28 May–16 July | 17 July–29 September |
2021 | 28 April | 14 May–16 July | 17 July–26 September |
2020 Growing Season | 2021 Growing Season | ||
---|---|---|---|
Flight Date | Physiological Growth Stage | Flight Date | Physiological Growth Stage |
September 2 | R5.3 | July 27 | R1 (silking) |
September 16 | R5.75 | July 30 | R2 (early blister) |
September 29 | R6 | August 21 | R5.1 (early dent) |
August 24 | R5.2 | ||
August 25 | R5.25 | ||
September 4 | R5.4 | ||
September 6 | R5.5 | ||
September 8 | R5.55 | ||
September 10 | R5.6 |
CSR (in %) during 2020 Growing Season in Maize | |||
---|---|---|---|
Flight Date | 31 m above Ground | 61 m above Ground | 122 m above Ground |
September 2 | 100% | - | 25% |
September 16 | 100% | 50% | 50% |
September 30 | 100% | 75% | 75% |
