Object-Based Thermal Image Segmentation for Fault Diagnosis of Reciprocating Compressors
Abstract
:1. Introduction
2. Experimental Facilities
2.1. Test Rig
2.2. Fault Simulation
3. Analysis of Temperature Change of Reciprocating Compressor
3.1. Temperature Change Characteristics of Reciprocating Compressor Based on Pseudo-Color Analysis
3.2. Fault Type Classification Using Support Vector Machine (SVM)
4. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
