Tailored Algorithm for Sensitivity Enhancement of Gas Concentration Sensors Based on Tunable Laser Absorption Spectroscopy
Abstract
:1. Introduction
2. Basic Principles of DA-ATLAS Gas Sensors
Basic DA-ATLAS Gas Sensor with Two Optical Channels
3. Tailoring an Algorithm for Enhancement of the Sensor Sensitivity to the Gas Concentration
3.1. Generating Functions
3.2. Selection of the Optimum Generating Function
4. Proof of Principle Gas Sensor Setup Based on DA-ATLAS
4.1. Characterization of the Laser Line Tuning and Simulation of the Sensor Output
4.2. Simulated Generating Functions for the Experimental Sensor Setup
4.3. Experimental Measurements
4.4. Experimental Sensitivity
5. Conclusions
Author Contributions
Acknowledgments
Conflicts of Interest
References
