Characterization of a Time-Resolved Diffuse Optical Spectroscopy Prototype Using Low-Cost, Compact Single Photon Avalanche Detectors for Tissue Optics Applications
Abstract
:1. Introduction
2. TR-DOS Prototype
2.1. Light Sources
2.2. Photon Counting and Timing Subsystem
2.3. Data Analysis Tool
3. Characterization Methods
3.1. Basic Instrumental Performance Protocol
3.1.1. Light Power
3.1.2. Differential non-linearity (DNL) of Photon Timing
3.1.3. Total IRF of the TR-DOS Setup
3.2. Optical Properties Quantification of Homogeneous Phantoms
3.2.1. Accuracy Assessment
3.2.2. Linearity Assessment
3.2.3. Preparation of Phantoms
3.2.4. Data Acquisition and Preprocessing
4. Results and Discussions
4.1. Differential Non-Linearity
4.2. Total Instrument Response Function (IRFTotal)
4.3. The Accuracy of the OP Quantification
4.4. The Linearity of the OP Quantification
4.5. Evaluation of this Prototype and the Potential Applications
4.6. Potential Developments of SPAD Detectors for Tissue Optics Applications
5. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
