An Adaptive INS-Aided PLL Tracking Method for GNSS Receivers in Harsh Environments
Abstract
:1. Introduction
2. The Principle of Delta Doppler Aided PLL
3. Tracking Error Analysis of Delta Doppler Aided PLL
3.1. Dynamic Stress Error
3.2. Thermal Noise Error
3.3. Oscillator Phase Error
3.4. Stable Tracking Criterion of INS-Aided PLL
4. Adaptive Adjustments of Integration Time and Bandwidth of INS-Aided PLL
Algorithm 1. The adaptive method for choosing the optimal noise bandwidth and integration time. |
Input:
|
5. Software Simulation
5.1. Validation of Dynamic Stress Error
5.2. Validation of Minimum Tracking Error
5.3. Simulation Result Analysis
Method | Main Idea |
---|---|
Adaptive Method | Choose the optimal integration time and bandwidth for a given application under the minimum tracking error criterion. |
Method 1 ([15]) | The Doppler aiding error resulting from the navigation uncertainty is derived and used to design the adaptive loop filter, so as to adjust the noise bandwidth. |
Method 2 ([8]) | Using the fuzzy logic controller (FLC) to adjust the PLL noise bandwidth on-line. |
6. Hardware Simulation
6.1. The Test for the Trajectory with Lower Dynamic Condition
Position Error (m) | Velocity Error (m/s) | |||||
---|---|---|---|---|---|---|
Method | Adaptive Method | Method 1 | Method 2 | Adaptive Method | Method 1 | Method 2 |
RMS | 4.9493 | 6.4867 | 5.9646 | 0.1926 | 0.3034 | 0.3227 |
6.2. The Test for the Trajectory with Higher Dynamic Condition
Position Error (m) | Velocity Error (m/s) | |||||
---|---|---|---|---|---|---|
Method | Adaptive Method | Method 1 | Method 2 | Adaptive Method | Method 1 | Method 2 |
RMS | 8.9449 | 9.5028 | 9.5726 | 0.9431 | 1.9048 | 1.4951 |
7. Field Test
8. Conclusions
