Open AccessArticle
Sensors 2016, 16(11), 1903;

Advanced Pedestrian Positioning System to Smartphones and Smartwatches

Telecommunications and Systems Engineering Department, Universitat Autònoma de Barcelona, Bellaterra 08193, Spain
Institute of Communications and Navigation, German Aerospace Center, Oberpfaffenhofen 82234, Germany
Author to whom correspondence should be addressed.
Academic Editor: Jörg Wagner
Received: 19 August 2016 / Revised: 7 November 2016 / Accepted: 9 November 2016 / Published: 11 November 2016
(This article belongs to the Special Issue Inertial Sensors and Systems 2016)
Full-Text   |   PDF [2532 KB, uploaded 11 November 2016]   |


In recent years, there has been an increasing interest in the development of pedestrian navigation systems for satellite-denied scenarios. The popularization of smartphones and smartwatches is an interesting opportunity for reducing the infrastructure cost of the positioning systems. Nowadays, smartphones include inertial sensors that can be used in pedestrian dead-reckoning (PDR) algorithms for the estimation of the user’s position. Both smartphones and smartwatches include WiFi capabilities allowing the computation of the received signal strength (RSS). We develop a new method for the combination of RSS measurements from two different receivers using a Gaussian mixture model. We also analyze the implication of using a WiFi network designed for communication purposes in an indoor positioning system when the designer cannot control the network configuration. In this work, we design a hybrid positioning system that combines inertial measurements, from low-cost inertial sensors embedded in a smartphone, with RSS measurements through an extended Kalman filter. The system has been validated in a real scenario, and results show that our system improves the positioning accuracy of the PDR system thanks to the use of two WiFi receivers. The designed system obtains an accuracy up to 1.4 m in a scenario of 6000 m 2 . View Full-Text
Keywords: inertial sensors and systems; smartphone navigation systems; aiding technology for INS; smartwatch; received signal strength inertial sensors and systems; smartphone navigation systems; aiding technology for INS; smartwatch; received signal strength

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
