Int. J. Mol. Sci. 2015, 16(3), 4838-4849; https://doi.org/10.3390/ijms16034838

Article
Nanoparticles of Copper Stimulate Angiogenesis at Systemic and Molecular Level
1
Division of Poultry Breeding, Warsaw University of Life Sciences, Ciszewskiego 8, 02-786 Warsaw, Poland
2
Division of Nanobiotechnology, Warsaw University of Life Sciences, Ciszewskiego 8, 02-786 Warsaw, Poland
3
Department of Veterinary Clinical and Animal Sciences, University of Copenhagen, Groennegaardsvej 3, 1870 Frederiksberg, Denmark
*
Author to whom correspondence should be addressed.
Academic Editor: Bing Yan
Received: 19 January 2015 / Accepted: 15 February 2015 / Published: 3 March 2015

Abstract

:
Copper is a key element affecting blood vessel growth and muscle development. However, the ions released from Cu salts are toxic. Given their specific physicochemical properties, nanoparticles of Cu (NanoCu) may have different bioactivity and affect the development of blood vessel and muscles in a different manner than Cu salts. The objective of the study was to evaluate the influence of NanoCu on embryo development and angiogenesis at the systemic and molecular level, in experiments using a chick embryo model. Fertilized chicken eggs were divided into a control group, and groups injected with a placebo, CuSO4 or NanoCu. Embryo development at the whole body level and molecular indices using an embryo chorioallantoic membrane model were measured during embryogenesis. The present study indicated for the first time that NanoCu have pro-angiogenic properties at the systemic level, to a greater degree than CuSO4 salt. The properties of NanoCu were confirmed at the molecular level, demonstrating significant effects on mRNA concentration and on mRNA gene expression of all pro-angiogenic and pro-proliferative genes measured herein.
Keywords:
angiogenesis; copper nanoparticles; chicken embryo; gene expression

1. Introduction

Copper is a key microelement required by animals and humans. Although the content of Cu in the human body is only about 100 mg it plays an important and multifunctional role as a cofactor of many enzymes [1]. Cu serves as a catalytic and structural cofactor for enzymes that function in energy generation (as a component of cytochrome c oxidase (COX), and is involved in iron acquisition, oxygen transport, cellular metabolism, peptide hormone maturation, blood clotting, signal transduction and a host of other processes [2].
Cu is essentially involved in angiogenesis as a stimulator of angiogenesis, vasculogenesis and endothelial cell migration [3]. Cu levels were found to locally regulate the growth or regression of new blood vessels. Furthermore, Cu affects the expression of structurally diverse but vital angiogenic growth factors such as vascular endothelial growth factor (VEGF), fibroblast growth factor 2 (FGF2), tumor necrosis factor (TNF)-α and platelet-derived endothelial cell growth factor (PD-ECGF) [4]. VEGF is recognized as the key regulator of angiogenesis, and is more efficient than FGF2 in the stimulation of differentiation of endothelial cells [5]. Cu is required for the activation of hypoxia-inducible factor-1 (HIF-1), a major transcription factor regulating the expression of VEGF [6]. As an angiogenic cofactor, Cu is also implicated in new vessel formation by interacting with endothelial and smooth muscle cells, leading to cell migration, invasion, proliferation and the formation of tubular structures [7]. Cu has also been shown to stimulate angiogenesis in chick embryo chorioallantoic membrane (CAM) models [4].
Muscle development is determined mainly during embryogenesis, and consequently the final number of muscle fibers is accomplished in the prenatal and early post hatch periods [8]. Moreover, muscle maturation during embryogenesis is dependent on the development of a vessel network, which provides cells with oxygen and nutrients; Cu may interfere indirectly with the molecular status of muscle maturation during embryogenesis via effects on myoblast determination protein 1 (MyoD1) and paired box protein 7 (Pax7).
At the nanometer scale (1–100 nm) there are collections of atoms or molecules, the properties of which are neither those of the individual constituents nor those of the bulk material. At this scale, many atoms are located on the surface of nanoparticles [9]. The unique bioactivity of nanoparticles together with their very small size influence the properties and behavior of nanoparticles when introduced to an organism, related to transportation, distribution, biochemical activities and molecular responses [10]. As an essential element that is present in very small amounts in the body, Cu is involved in many different processes, playing a dual role in the organism (also being a pro-cancer agent), and may in the form of nanoparticles show different effects. Chen et al. [11] reported that the LD50 for Cu nanoparticles (size 23.5 nm), Cu particles (size 17 μm) and ions in mice was 413, >5000 and 110 mg/kg body weight, respectively. This result classified both nanoparticles and ions as class 3 (moderately toxic) agents. Given that nanoparticles seem to be less toxic than ions in standard toxicological experiments, they have potential applicability as biological agents, making it important to investigate molecular responses to Cu nanoparticles.
The objective of this study was to evaluate the influence of nanoparticles of copper on angiogenesis at the systemic and molecular level in comparison to Cu salt, in experiments using a chick embryo model.

2. Results

Chicken embryo development, at day 3, 6, 9, 12, 15, 18 and 20 of incubation, was compared with the Hamburger–Hamilton normal stages of chicken embryo development. All embryos developed normally and no genetic or other defects were detected. The administration of CuSO4 and NanoCu to the chicken embryo by the in ovo method did not influence the weight of the body, heart, liver or spleen evaluated at day 20 (Table 1).
Table 1. Weight of the body and chosen organs, evaluation according to Hamburger–Hamilton development stages (HH) and mortality of chick embryo at 20 day, after in ovo treatment with CuSO4 and nanoparticles of Cu (NanoCu).
Table 1. Weight of the body and chosen organs, evaluation according to Hamburger–Hamilton development stages (HH) and mortality of chick embryo at 20 day, after in ovo treatment with CuSO4 and nanoparticles of Cu (NanoCu).
IndicesGroupsANOVA
ControlCuSO4NanoCuSEMp-Value
Body Weight49.548.6749.933.672ns
Liver1.1281.0011.0010.143ns
Spleen0.0280.0260.0240.0061ns
Heart0.4340.3820.4200.0391ns
HHcorrectcorrectcorrect
Mortality %8.111.29.0
ns = non-significant, p < 0.05.
Evaluation of the development of the embryos at day 9 showed that the development of blood vessels was more intense in the NanoCu group than in the CuSO4 group and much denser than in the control group (data not shown). To verify this observation experiments were carried out on the induction of angiogenesis. Implants soaked with PBS, CuSO4 or NanoCu were placed on the CAM and after 2 days, at day 12 of incubation, the vessel network was observed. Both forms of Cu promoted the development of vessels; however, the number of branches and length of vessels was greater in the NanoCu group compared to the control and the CuSO4 group (Table 2, Figure 1).
Table 2. The number of branches of blood vessels examined on implants (with diameter 1 cm) incubated on the chick embryo chorioallantoic membrane, after in ovo treatment with CuSO4 and nanoparticles of Cu (NanoCu).
Table 2. The number of branches of blood vessels examined on implants (with diameter 1 cm) incubated on the chick embryo chorioallantoic membrane, after in ovo treatment with CuSO4 and nanoparticles of Cu (NanoCu).
IndicesGroupsANOVA
ControlCuSO4NanoCuSEMp-Value
Number of Branches7.9 a12.6 b17.3 c0.430.000
Length of vessels mm7.3 a11.5 b13.2 b0.970.000
a,b,c: within rows, means bearing different superscripts differ significantly at p < 0.05.
Figure 1. Images of implants maintained on the chicken embryo chorioallantoic membrane (CAM) for 2 days, soaked with: (1) control (not soaked); (2) control (PBS); (3) CuSO4; (4) NanoCu, evaluated at day 12 of incubation. Scale bars, 2000 µm.
Figure 1. Images of implants maintained on the chicken embryo chorioallantoic membrane (CAM) for 2 days, soaked with: (1) control (not soaked); (2) control (PBS); (3) CuSO4; (4) NanoCu, evaluated at day 12 of incubation. Scale bars, 2000 µm.
Ijms 16 04838 g001
The results concerning VEGF-A, FGF2, PCNA, MyoD1, Pax7 and COX gene expression normalized to the β-actin (ACTB) gene at the mRNA level indicated that the experimental treatments influenced mRNA synthesis in embryo breast muscle (Table 3).
Table 3. The mRNA expression of VEGF-A, FGF2, PCNA, MyoD1, PAX7 and COX genes and concentration of DNA and RNA in the samples of pectoral muscles of embryos at day 18 and day 20, after in ovo treatment with CuSO4 and nanoparticles of Cu (NanoCu).
Table 3. The mRNA expression of VEGF-A, FGF2, PCNA, MyoD1, PAX7 and COX genes and concentration of DNA and RNA in the samples of pectoral muscles of embryos at day 18 and day 20, after in ovo treatment with CuSO4 and nanoparticles of Cu (NanoCu).
IndicesGroupsANOVA
ControlCuSO4NanoCuSEMp-Value
Day 18
VEGF-A11.1413.8410.871.231ns
FGF24.12 a,b2.92 b5.42 a0.9570.012
PCNA0.900.730.680.085ns
MyoD10.37 a0.78 b0.57 a,b0.1470.014
COX4.963.153.590.805ns
Pax70.590.580.650.075ns
DNA258.7202.5249.039.18ns
RNA2194.22291.02391.9186.6ns
RNA/DNA ratio8.511.39.6
Day 20
VEGF-A21.69 a25.66 a36.96 b2.1840.000
FGF21.30 a6.72 b9.00 c0.9520.000
PCNA0.68 a0.62 a2.54 b0.1340.000
MyoD11.08 a3.10 c1.91 b0.3270.000
COX16.8116.2018.522.085ns
Pax70.62 a0.21 b0.25 b0.2690.000
DNA249.3289.9247.843.06ns
RNA1182.6 a1066.3 b1798.6 c82.170.000
RNA/DNA ratio4.73.77.3
ns = non-significant; a,b,c: within rows, means bearing different superscripts differ significantly at p < 0.05.
VEGF-A expression did not differ significantly between embryos treated with CuSO4 and NanoCu at day 18 but at day 20, expression tended to be higher in the CuSO4 group and was significantly higher in the NanoCu group than in the control group (1.8 times higher). The expression of FGF2 was not significantly affected at day 18 in comparison to the control group; however, NanoCu had a significantly greater effect than CuSO4. At day 20, FGF2 was upregulated by CuSO4, and to a greater extent by NanoCu. FGF2 expression was about five-fold higher in CuSO4 and seven-fold higher in the NanoCu group than in the control group. Neither CuSO4 nor NanoCu affected the expression of PCNA at day 18, but at day 20, expression was significantly increased by NanoCu treatment. When MyoD1 was examined at day 18, the level of expression was significantly higher in embryos treated with CuSO4 compared to the control group. At day 20, MyoD1 expression was significantly higher in the embryos treated with NanoCu and even higher (three-fold higher) in the CuSO4 than in the control group. The expression of COX, examined at day 18 and 20, was not affected. Pax7 gene expression was not influenced by experimental treatments at day 18; however, at day 20, it was significantly reduced in the CuSO4 and NanoCu groups compared to the control group. The DNA and RNA concentrations in the breast muscle at day 18 were not affected by the treatments, but at day 20 the RNA concentration was lower in the CuSO4 group and substantially higher in the NanoCu group compared to the control group.

3. Discussion

The results indicated that copper in the form of salt (CuSO4) as well as in metal form (Cu°), introduced into chick embryos by in ovo injection, did not influence embryo growth or development. Neither form of Cu was harmful when injected as 300 μL of colloid/salt at a concentration of 50 ppm of Cu. These results confirm our earlier findings with chick embryos and growing chicks [12,13]. Moreover, our previous studies indicated that neither Cu nanoparticles nor silver or gold nanoparticles interfere with the growth and development of embryos when used at levels up to 50 ppm [14,15,16].
CuSO4 is a source of Cu ions whereas nanoparticles of Cu are a source of particles of metal with a highly bioactive surface and also a small quantity of Cu ions. Interestingly the amount of ions released is strongly dependent on the pH of the environment (compartment of cells), which is also positively correlated with the toxicity of Cu nanoparticles. Nevertheless, at pH = 7 the percentage of Cu ions originating from nanoparticles was 0.1%–0.3% [17]. The physical form (ions vs. metal) influences the majority of Cu bio-properties, hence, the key issue of the present investigation was to indicate differences between Cu salt and Cu nanoparticle bioactivities in the process of angiogenesis at the systemic and molecular level.
In our experiment, we observed more intense development of the vessel network (growing outside the chicken embryo until day 15) and increased vascularization of implants maintained on CAM after CuSO4 treatment in comparison to the control group. In experiments using the rabbit cornea vascularization model, the application of CuSO4 provoked neovascularization [18]. It is known that Cu is involved in angiogenesis, being a pleiotrophic agent that influences numerous mediators of angiogenesis [6,19]. This fundamental mechanism has even been used as a promising anticancer treatment [20]. Our observations confirm this phenomenon.
However, the pro-angiogenic effects observed after NanoCu treatment, which were significantly more potent compared to those produced by CuSO4, have never been reported. Thus, the present study is the first to indicate that nanoparticles of Cu have pro-angiogenic properties at the systemic level, to a greater degree than CuSO4 salt.
Gene expression at the mRNA level, measured in samples of breast muscle from the chick embryos, did not unambiguously support these observations. New vessel growth requires the chronological activation of many receptors by numerous ligands, but a critical rate-limiting step in angiogenesis is VEGF signaling [21]. Cu is required for the stimulation of hypoxia-inducible factor-1 (HIF-1), the most important transcription factor regulating the expression of VEGF [20]. VEGF is also responsible for the proper development of the vascular system in skeletal muscles [22], in which gene expression was measured in our experiment. Further, VEGF as an endothelial cell mitogen is involved in angiogenesis as well as vasculogenesis. In our experiment expression of VEGF-A was not affected by either treatment at day 18, or by CuSO4 treatment at day 20, but at day 20 NanoCu treatment almost doubled the expression of VEGF-A compared to the control. VEGF-A is regulated by hypoxia, oxidative stress, growth factors and cytokines [23,24]. However, during embryogenesis in normal physiological conditions, FGF plays a crucial role in VEGF-dependent vasculogenesis. Experiments with epicardial cells, which form vascular tubes, indicated that most of the FGF family of proteins, including FGF2, regulates the tubulogenic response [25]. Interestingly, FGF effects are VEGF dependent, while tubulogenesis induced by VEGF also requires FGF signaling. This interaction between VEGF-A and FGF2 was seen at the level of gene expression at day 20. The highest mRNA expression of VEGF-A and FGF2 was observed in the NanoCu treatment, consistent with vessel network development in the chicken embryo and CAM implant model.
At day 18, however, neither VEGF nor FGF2 expression were significantly influenced by Cu treatments compared to the control group. Nevertheless, the FGF2 mRNA concentration was higher after NanoCu than CuSO4 treatment. The number and migration of endothelial cells was significantly increased by FGF2 [26]. FGF2 transmits signals preferentially via tyrosine kinase receptors (FGFR1–4), non-tyrosine kinase receptors and also via cell-surface FGFR-interacting proteins [26]. The spectrum of the interaction of FGF2 is very wide, and CuSO4 and NanoCu may interfere with the same or only partly the same signal pathways. NanoCu as metallic particles may be sequestered in different ways than Cu salt, and consequently the signaling properties of the two forms of Cu may differ. It is also possible that the activity of FGF2 during embryogenesis, which might be modulated by CuSO4 or NanoCu, is time dependent and that biosignaling by the metallic form (NanoCu) occurs over a longer period compared to CuSO4 salt. Furthermore, the reason that expression of FGF2 after NanoCu treatment was higher compared to the CuSO4 treatment at the end of embryogenesis, may be a more efficient transport and different signaling pathways of the metallic form. Hence, it will be crucial to investigate the behavior of NanoCu within tissue and cells in future experiments.
FGF2 activity is observed from early phases of embryogenesis and is highly involved in cell proliferation [27,28], and consequently is a strong PCNA inducer [29]. This was reflected in the expression of PCNA after NanoCu treatment at day 20. In comparison to CuSO4, NanoCu significantly increased PCNA expression—a key marker of cell division. However, this was not observed at day 18, pointing to the possibility that NanoCu extend the period of predominance of hyperplasia over hypertrophy at the end of embryogenesis.
To identify further molecular effects on breast muscle development after treatment with different forms of copper two other FGF2-dependent genes were examined: MyoD1 and Pax7. MyoD1, unlike FGF2, activates mechanisms of skeletal muscle lineage determination and differentiation [30]. Myogenic regulatory factors (including MyoD1) in the embryo muscle are markers of cell differentiation, inducing the synthesis of myogenin, which leads to the suppression of cell proliferation. This process increases at the end of embryogenesis but at the end of embryo development the proliferation of muscle cells slows down and almost ceases [31]. In the current study treatment with CuSO4 increased MyoD1 expression at day 18 two-fold and at day 20 three-fold in comparison to the control. It is possible that CuSO4 might increase cell differentiation by increasing the vessel network and transport of oxygen and nutrients to muscle cells. However, NanoCu increased the MyoD1 mRNA concentration only at day 20 and to a lower degree in comparison to CuSO4. This was also confirmed by the reduced expression of Pax7, which in contrast to the anti-proliferative MyoD1, is a marker of proliferation of satellite cells. These differences between CuSO4 and NanoCu activity also suggest that the bioactivity of NanoCu might be more prolonged.
In the light of examination of vessel network development at the systemic level, the present results show that NanoCu stimulate angiogenesis more than CuSO4. Moreover, the molecular responses demonstrate that NanoCu as well as CuSO4 affect the mRNA expression of genes involved in angiogenesis and cell proliferation. This may indicate that the level of Cu stored in the egg is insufficient, notably at the end of embryogenesis. Furthermore, NanoCu have a stronger effect on mRNA gene expression than CuSO4, which may point to a different mechanism of signaling, as well on more efficient sequestration within muscle cells.

4. Experimental Section

4.1. Experimental Design

Chicken eggs from 37-week-old Ross × Ross 308 hens, obtained from a commercial certificated hatchery, were stored in a refrigerator (10 °C) for 1–3 days and then placed in an incubator. The eggs were randomly divided into four groups (4 × 100 eggs): no injection (control), injected with phosphate buffered saline (PBS) as a placebo, or injected with solutions of CuSO4 (CuSO4) or hydrocolloid of nanoparticles of copper (NanoCu). At day 1 of incubation, the eggs were weighed (58 ± 1.28 g) and 0.3 mL of experimental fluids was injected under sterile conditions into the air sac, using 27-gauge, 20-mm needles. Immediately after the injection, the hole was sealed with sterile tape and the eggs were placed in an incubator. The eggs were incubated for 18 or 20 days under standard conditions (temperature 37.8 °C, humidity 55%, turned once per hour for the first 18 days, and at a temperature of 37 °C and humidity 60% from day 20).
At day 3, 6, 9, 12, 15, 18 and 20 of incubation eggs were randomly selected from each group and six embryos from each group were dissected and examined. The developmental status of the chick embryos was compared with the developmental stages described by [32]. The network of blood vessels in the chorioallantoic membrane (CAM) was evaluated at day 9 and day 12. At day 18 six samples of the breast muscle were collected in RNAlater® ribonucleic acid (RNA) stabilization solution (Applied Biosystems/Ambion, Austin, TX, USA) for mRNA expression analysis. At day 20 the embryos were weighed and decapitated, the liver, heart, spleen were weighed and the breast muscles were prepared for mRNA expression analysis.

4.2. Experimental Solutions

CuSO4 was obtained from Sigma Aldrich, St. Louis, MO, USA and was dissolved in ultra pure water to a concentration of 50 ppm of Cu. The hydrocolloid of NanoCu, at a concentration of 50 ppm, was purchased from Nano-Tech, Warsaw, Poland and was produced by a non-explosive high voltage method from high purity metals (99.9999%) and high purity demineralized water.
The Zeta potential of hydrocolloids was measured using a Zetasizer Nano-ZS90 (Malvern Instruments Ltd., Malvern, UK): the Zeta potential of NanoCu was −28.1 indicating a stable solution. The shape and size of NanoCu were visualized using a JEM-2000EX transmission electron microscope (TEM: JEOL Ltd., Tokyo, Japan) at 80 kV (Figure 2). The nanoparticles were spherical and rarely elliptical, rounded, with no sharp edges. The diameter of nanoparticles was on average 37.3 nm and varied from 15 to 70 nm.
Figure 2. Transmission electron microscopic image of Cu nanoparticles.
Figure 2. Transmission electron microscopic image of Cu nanoparticles.
Ijms 16 04838 g002

4.3. Gene Expression at the mRNA Level

Gene expression at the mRNA level was measured using the quantitative polymerase chain reaction method (qPCR). The tissue dissected from the breast muscle was homogenized in TRIzol® Reagent (Life Technologies, Naerun, Denmark), and total RNA was extracted according to the manufacturer’s instructions. The RNA samples were purified using the SV Total RNA Isolation System (Promega Corporation, Madison, WI, USA) and quantified using a NanoDrop ND 1000 spectrophotometer (Thermo Fisher Scientific, Waltham, MA, USA). Using reverse transcriptase with oligo (dT) (Promega) and random primers (TAG Copenhagen A/S, Copenhagen, Denmark), 2 mg of total RNA was reverse transcribed, after which real-time PCR was performed with complementary DNA and gene-specific primer pairs (TAG, Copenhagen A/S, Copenhagen, Denmark) mixed with LightCycler® 480 SYBR Green I Master mix (Roche Applied Science, Penzberg, Germany) in a LightCycler® 480 real-time PCR system (Roche Applied Science, Penzberg, Germany). The following primers were used: FGF2 (forward: GGCACTGAAATGTGCAACAG, reverse: TCCAGGTCCAGTTTTTGGTC), VEGF-A (forward: TGAGGGCCTAGAATGTGTCC, reverse: TCTTTTGACCCTTCCCCTTT), PCNA (forward: TGCACGCATTTGTAGAGACC, reverse: AGTCAGCTGGACTGGCTCAT), MyoD1 (forward: CGGCGGCTCAGCAAGGTCAAC, reverse: CGGCCCGCTGTACTCCATCATG), COX (forward: AGGATTCTATTTCACAGCCCTACAAG, reverse: AGACGCTGTCAGCGATTGAGA), Pax7 (forward: CCAGTAGAGACAGGCCAAGC, reverse: GGAGTTGGGAAGGAGTAGGG) and ACTB (forward: GTCCACCTTCCAGCAGATGT, reverse: ATAAAGCCATGCCAATCTCG). For each complementary DNA, the reaction was performed in triplicate. For analyses, relative quantification was conducted using ACTB as the housekeeping gene.

4.4. Angiogenesis Assay

Angiogenesis (state of development of the vascular network) was evaluated using the chick CAM implantation method according to [33,34]. The CAM method could be performed till day 12 of incubation because only in this period vessels grow outside the embryo body. Eggs (3 groups × 20 eggs) were incubated as described above. On the 3rd day of incubation a 1 cm2 window in the shell was opened and 3 mL of albumen was removed. The window was sealed with sterile aluminum foil and the eggs were placed back in the incubator. At day 9 of incubation the windows were opened and sterilized filter paper rings, loaded with experimental solutions (CuSO4 or NanoCu) or PBS as a placebo were placed over the developing CAM. The implants were pre-treated with 3 mg/mL of hydrocortisone sodium succinate (Sigma, St. Louis, MO, USA) and air dried under sterile conditions. The concentration of Cu in CuSO4 and NanoCu was 50 ppm. The windows were then resealed, and the eggs were incubated for a further 48 h. At day 12 of incubation, the implants were removed from the eggs [34] and the morphology of blood vessel formation around the implants was observed using a stereomicroscope under 12.5-fold magnification (SZX10, CellD software version 3.1, Olympus Corporation, Tokyo, Japan). Photos were analyzed using CellSens Dimension Desktop version 1.3 (Olympus Corporation). The vessel network (length of vessels and number of branches) present on the implants was evaluated according to [34].

4.5. Statistical Methods

Data was normally distributed and the results were analyzed by analysis of variance computed with the least squares method using statistical software SPSS 19.0 PL for Windows (SPSS Inc., Chicago, IL, USA), at a significance level of p ≤ 0.05.

5. Conclusions

We demonstrated that in ovo administration of Cu as CuSO4 salt or as NanoCu at a concentration of 50 ppm had no negative effects on embryo development. Both treatments increased vascularization of implants maintained on CAM, but the pro-angiogenic effects of NanoCu were more potent compared to those produced by CuSO4. The properties of NanoCu were confirmed at the molecular level, demonstrating significant effects on mRNA concentration and on mRNA gene expression of all pro-angiogenic and pro-proliferative genes measured herein.

Acknowledgments

This work was supported by grant 267659 “Gutfeed”, the National Centre of Research and Development, Poland.

Author Contributions

Natalia Mroczek-Sosnowska and Monika Łukasiewicz designed and performed the experiments with chicken embryos; Ewa Sawosz conceived and designed experiments, wrote the paper; Krishna Prasad Vadalasetty performed mRNA gene expression; Jan Niemiec analyzed the data; Mateusz Wierzbicki performed experiments with CAM; Marta Kutwin performed microscopic examinations; Sławomir Jaworski sampling and preparation of materials for PCR; André Chwalibog conceived, designed experiments and wrote the paper.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Linder, M.C.; Goode, C.A. Biochemistry of Copper; Springer–Verlag New York, LLC: New York, NY, USA, 1991; pp. 1–413. [Google Scholar]
  2. Kim, B.-E.; Nevitt, T.; Thiele, D.J. Mechanisms for copper acquisition, distribution and regulation. Nat. Chem. Biol. 2008, 4, 176–185. [Google Scholar] [CrossRef] [PubMed]
  3. Finney, L.; Vogt, S.; Fukai, T.; Glesne, D. Copper and angiogenesis: Unravelling a relationship key to cancer progression. Clin. Exp. Pharmcol. Phys. 2009, 36, 88–89. [Google Scholar] [CrossRef]
  4. Gupte, A.; Mumper, R.J. Elevated copper and oxidative stress in cancer cells as a target for cancer treatment. Cancer Treat. Rev. 2009, 35, 32–46. [Google Scholar] [CrossRef] [PubMed]
  5. Shinkaruk, S.; Bayle, M.; Lain, G.; Deleris, G. Vascular endothelial cell growth factor (VEGF), an emerging target for cancer chemotherapy. Curr. Med. Chem. 2003, 3, 95–117. [Google Scholar]
  6. Xie, H.; Kang, Y.J. Role of copper in angiogenesis and its medicinal implications. Curr. Med. Chem. 2009, 16, 1304–1314. [Google Scholar] [CrossRef] [PubMed]
  7. Gao, X.; Xu, Z. Mechanisms of action of angiogenin. Acta Biochim. Biophys. Sin. 2008, 40, 619–624. [Google Scholar] [CrossRef] [PubMed]
  8. Velleman, S.G. Muscle development in the embryo and hatchling. Poultry Sci. 2007, 86, 1050–1054. [Google Scholar] [CrossRef]
  9. Eustis, S.; El-Sayed, M.A. Why gold nanoparticles are more precious than pretty gold: Noble metal surface plasmon resonance and its enhancement of the radiative and nonradiative properties of nanocrystals of different shapes. Chem. Soc. Rev. 2006, 35, 209–217. [Google Scholar] [CrossRef] [PubMed]
  10. Salata, O.V. Applications of nanoparticles in biology and medicine. J. Nanobiotech. 2004, 2, 3. [Google Scholar] [CrossRef][Green Version]
  11. Chen, Z.; Meng, H.; Xing, G.; Chen, C.; Zhao, Y.; Jia, G.; Wang, T.; Yuan, H.; Ye, C.; Zhao, F.; et al. Acute toxicological effects of copper nanoparticles in vivo. Toxicol. Lett. 2006, 163, 109–120. [Google Scholar] [CrossRef] [PubMed]
  12. Pineda, L.; Sawosz, E.; Vadalasetty, K.P.; Chwalibog, A. Effect of copper nanoparticles on metabolic rate and development of chicken embryos. Anim. Feed Sci. Tech. 2013, 186, 125–129. [Google Scholar] [CrossRef]
  13. Mroczek-Sosnowska, N.; Batorska, M.; Łukasiewicz, M.; Wnuk, A.; Sawosz, E.; Jaworski, S.; Niemiec, J. Effect of nanoparticles of copper and copper sulfate administered in ovo on hematological and biochemical blood markers of broiler chickens. Ann. Warsaw Univ. Life Sci. Anim. Sci. 2013, 52, 141–149. [Google Scholar]
  14. Grodzik, M.; Sawosz, E. The influence of silver nanoparticles on chick embryo development and bursa fabricius morphology. J. Anim. Feed Sci. 2006, 15, 111–115. [Google Scholar]
  15. Sawosz, E.; Grodzik, M.; Lisowski, P.; Zwierzchowski, T.; Niemiec, T.; Zielińska, M.; Szmidt, M.; Chwalibog, A. Influence of hydrocolloids of Ag, Au and Ag/Cu alloy nanoparticles on the inflammatory state at transcriptional level. Bull. Vet. Inst. Pulawy. 2010, 54, 81–85. [Google Scholar]
  16. Pineda, L.; Sawosz, E.; Hotowy, A.; Elnif, J.; Sawosz, F.; Ali, A.; Chwalibog, A. Effect of nanoparticles of silver and gold on metabolic rate and development of broiler and layer embryos. Comp. Biochem. Physiol. A. 2011, 161, 315–319. [Google Scholar] [CrossRef]
  17. Studer, A.M.; Limbach, L.K.; Duc, L.V.; Krumeich, F.; Athanassiou, E.K.; Gerber, L.; Moch, H.; Stark, W.J. Nanoparticle cytotoxicity depends on intracellular solubility: Comparison of stabilized copper metal and degradable copper oxide nanoparticles. Toxicol. Lett. 2010, 197, 169–174. [Google Scholar] [CrossRef] [PubMed]
  18. Parke, A.; Bhattacherjee, P.; Palmer, R.M.; Lazarus, N.R. Characterization and quantification of copper s sulfate-induced vascularization of the rabbit cornea. Am. J. Pathol. 1988, 130, 173–178. [Google Scholar] [PubMed]
  19. Harris, E.D. A requirement for copper in angiogenesis. Nutr. Rev. 2004, 62, 60–64. [Google Scholar] [CrossRef] [PubMed]
  20. Narayanan, G.; Bharathidevi, S.R.; Vuyyuru, H.; Muthuvel, B.; Konerirajapuram Natrajan, S. CTR1 silencing inhibits angiogenesis by limiting copper entry into endothelial cells. PLoS One 2013, 8, e71982. [Google Scholar] [CrossRef] [PubMed]
  21. Ferrara, N.; Gerber, H.P.; LeCoute, J. The biology of VEGF and its receptors. Nat. Med. 2003, 9, 669–676. [Google Scholar] [CrossRef] [PubMed]
  22. Tang, K.; Breen, E.C.; Gerber, H.P.; Ferrara, N.M.; Wagner, P.D. Capillary regression in vascular endothelial growth factor-deficient skeletal muscle. Physiol. Genomics 2004, 18, 63–69. [Google Scholar] [CrossRef] [PubMed]
  23. Ferrara, N. Molecular and biological properties of vascular endothelial growth factor. J. Mol. Med. 1999, 77, 527–543. [Google Scholar] [CrossRef] [PubMed]
  24. Takahashi, A.; Kureishi, Y.; Yang, J.; Luo, Z.; Guo, K.; Mukhopadhyay, D.; Ivashchenko, Y.; Branellec, D.; Walsh, K. Myogenic Akt signaling regulates blood vessel recruitment during myofiber growth. Mol. Cell. Biol. 2002, 22, 4803–4814. [Google Scholar] [CrossRef] [PubMed]
  25. Tomanek, R.J.; Christensen, L.P.; Simons, M.; Murakami, M.; Zheng, W.; Schatteman, G.C. Embryonic coronary vasculogenesis and angiogenesis are regulated by interactions between multiple FGFs and VEGF and are influenced by mesenchymal stem cells. Dev. Dyn. 2010, 239, 3182–3191. [Google Scholar] [CrossRef] [PubMed]
  26. Murakami, M.; Elfenbein, A.; Simons, M. Non-canonical fibroblast growth factor signalling in angiogenesis. Cardiovasc. Res. 2008, 78, 223–231. [Google Scholar] [CrossRef] [PubMed]
  27. Bikfalvi, A.; Klein, S.; Pintucci, G.; Rifkin, D.B. Biological roles of fibroblast growth factor-2. Endocr. Rev. 1997, 18, 26–45. [Google Scholar] [PubMed]
  28. Dorey, K.; Amaya, E. FGF signaling: Diverse roles during early vertebrate embryogenesis. Development 2010, 137, 3731–3742. [Google Scholar] [CrossRef] [PubMed]
  29. Köhler, T.; Pröls, F.; Brand-Saberi, B. PCNA in situ hybridization: a novel and reliable tool for detection of dynamic changes in proliferating activity. Histochem. Cell. Biol. 2005, 123, 315–327. [Google Scholar] [CrossRef] [PubMed]
  30. Goldhamer, D.J.; Brunk, B.P.; Faerman, A.; King, A.; Shani, M.; Emerson, C.P. Embryonic activation of the MyoD gene is regulated by a highly conserved distal control element. Development 1995, 121, 637–649. [Google Scholar] [PubMed]
  31. Amthor, H.; Christ, B.; Patel, K. A molecular mechanism enabling continuous embryonic muscle growth—A balance between proliferation and differentiation. Development 1999, 126, 1041–1053. [Google Scholar] [PubMed]
  32. Hamburger, V.; Hamilton, H.L. A series of normal stages in the development of the chick embryo. Dev. Dyn. 1951, 195, 231–272. [Google Scholar] [CrossRef]
  33. Ribatti, D.; Gualandris, A.; Bastaki, M.; Vacca, A.; Iurlaro, M.; Roncali, L.; Presta, M. New model for the study of angiogenesis and antiangiogenesis in the chick embryo chorioallantoic membrane: The gelatin sponge/chorioallantoic membrane assay. J. Vasc. Res. 1997, 34, 455–463. [Google Scholar] [CrossRef] [PubMed]
  34. Wierzbicki, M.; Sawosz, E.; Grodzik, M.; Prasek, M.; Jaworski, S.; Chwalibog, A. Comparison of anti-angiogenic properties of pristine carbon nanoparticles. Nanoscale Res. Lett. 2013, 8, 195. [Google Scholar] [CrossRef] [PubMed]
