Communication

Essential Oil Composition of Grindelia squarrosa from Southern Idaho

1
Aromatic Plant Research Center, 230 N 1200 E, Suite 100, Lehi, UT 84043, USA
2
Independent Researcher, 1432 W. Heartland Dr., Kuna, ID 83634, USA
3
Department of Chemistry, University of Alabama in Huntsville, Huntsville, AL 35899, USA
*
Author to whom correspondence should be addressed.
Molecules 2023, 28(9), 3854; https://doi.org/10.3390/molecules28093854
Submission received: 7 April 2023 / Revised: 20 April 2023 / Accepted: 27 April 2023 / Published: 2 May 2023
(This article belongs to the Special Issue Chemical Composition and Bioactivities of Essential Oils, 2nd Edition)

Abstract

:
Grindelia squarrosa is an arid lands herb that has been used in Native American traditional medicine, is a potential source of pharmacologically active compounds, and has been explored as a source of biofuel. The purpose of this work was to examine the essential oil composition of G. squarrosa from southern Idaho. Gas chromatographic methods revealed the essential oil of G. squarrosa var. serrulata to be rich in monoterpenoids, α-pinene (21.9%), limonene (17.1%), terpinolene (10.6%), and borneol (6.5%). The essential oil composition of G. squarrosa from Idaho is similar to that previously reported from specimens collected from Montana and confirms the volatile phytochemistry of plants growing in North America. The major essential oil components were screened for antimicrobial activity against respiratory and dermal pathogens. (–)-β-Pinene showed strong antibacterial activity against Streptococcus pneumoniae (MIC 39.1 μg/mL) and (–)-borneol showed strong activity against Staphylococcus aureus (MIC 78.1 μg/mL).

1. Introduction

The genus Grindelia Willd. (Asteraceae) is made up of around 73 species [1], naturally ranging in western and central North America, Mexico, and South America, but introduced to eastern North America and the Old World [2]. Grindelia squarrosa (Pursh) Dunal (Asteraceae), curlycup gumweed, is a short-lived herb or subshrub, with oblong to oblanceolate, crenulate-serrulate leaves (1.5–7 cm long and 0.5–1.3 cm wide), and ranges throughout the Great Plains, Rocky Mountains, and Great Basin areas of North America. The plant has been introduced elsewhere [3,4], and has become an invasive species in central Europe [5]. Several varieties of G. squarrosa have been described [6], and three have been recorded in Idaho, namely G. squarrosa var. quasiperennis Lunell, G. squarrosa var. serrulata Steyerm., and G. squarrosa var. squarrosa Cronquist [7].
The Shoshoni Native Americans used G. squarrosa in their traditional medicine. A decoction of the plant was used as a cough medicine, as an antiseptic wash, and taken internally as an expectorant, to treat stomachache, smallpox, and measles [8]. Labdane diterpenoids (e.g., grindelic acid, 6-oxogrindelic acid, and 17-hydroxygrindelic acid) have been isolated and identified from G. squarrosa [9] and the plant has been investigated as a source of biofuel [10]. In this work, we hypothesize that the essential oil may contain components supporting the Native American use of the plant; we present the essential oil composition of the aerial parts of G. squarrosa var. serrulata collected from southern Idaho and antimicrobial screening of some major essential oil components.

2. Results and Discussion

Based on botanical descriptions [11] and comparison with specimens from the New York Botanical Garden [7] the plant was identified as G. squarrosa var. serrulata (see Figure 1). Hydrodistillation of G. squarrosa aerial parts gave a colorless essential oil in 0.655% yield. Gas chromatographic analysis (GC-MS and GC-FID) revealed a total of 84 compounds (Table 1). The major components were α-pinene (21.9%), limonene (17.1%), terpinolene (10.6%), and borneol (6.5%).
There have been several reports on Grindelia essential oils, which are summarized in Table 2. Not surprisingly, there are obvious differences in essential oil compositions between Grindelia species. For example, G. discoidea was dominated by sesquiterpenoids [12], while G. humilis was rich in polyacetylenes [13], and G. rubusta had high concentrations of monoterpenoids [13,14,15]. There is variation in composition within species due to the geographical source of the plant material. For example, borneol dominated the essential oils of G. rubusta from Italy [14,15], but was apparently not detected in a sample grown in Germany [16]. Likewise, bornyl acetate was a major component in G. squarrosa from Romania (10.8%) [17], but was a relatively minor constituent in G. squarrosa from Germany (1.3% [13] and 0.7% [16]). It is not clear what factors may be involved in the differences in composition, but climatic, environmental, edaphic, seasonality, or genetic differences may be important.
Interestingly, the essential oil compositions of G. squarrosa from Idaho (this work) and from Montana [19] are similar in composition even though the locations are 424 km apart and on opposite sides of the Great Continental Divide of North America. Thus, for example, α-pinene (21.9% and 23.2% for the Idaho and Montana samples, respectively), limonene (17.1% and 14.7%), β-pinene (4.2% and 3.8%), and bornyl acetate (3.3% and 5.2%) concentrations are very similar. There are conspicuous differences in borneol (6.5% and 16.6%), terpinolene (10.6% and 2.0%), and p-cymen-8-ol (0.2% and 5.8%) concentrations between the two samples, however.
In order to determine the enantiomeric distributions of terpenoid components in G. squarrosa var. serrulata, the essential oil was subjected to chiral GC-MS (Table 3). The enantiomeric distributions for α-pinene, β-pinene, limonene, camphor, and borneol are comparable to those reported by Schepetkin and co-investigators, who found 100% (–)-α-pinene, 89% (–)-β-pinene, 98% (+)-limonene, 97% (–)-camphor, and 100% (–)-borneol in the sample from Montana [19]. As far as we are aware, there are no chiral GC analyses of essential oils of other Grindelia species.
The Native American traditional medicinal use of the plant as a cough medicine and as an antiseptic wash prompted investigation of the antimicrobial activities of the major essential oil components. The compounds α-pinene, β-pinene, limonene, borneol, and bornyl acetate were screened for antimicrobial activity against the respiratory and dermal pathogenic bacteria Cutibacterium acnes, Staphylococcus aureus, Staphylococcus epidermidis, Streptococcus pneumoniae, Streptococcus pyogenes, and the dermatophytic fungi Microsporum canis, Microsporum gypseum, Serratia marcescens, Trichophyton mentagrophytes, and Trichophyton rubrum (Table 4).
Based on previously published guidelines [20,21], essential oil components showing MIC values < 500 μg/mL should be considered as showing “strong activity”. Thus, S. pneumoniae was the most susceptible microorganism and S. pyogenes was the most resistant to the essential oil components. Notably, the major enantiomers, (–)-α-pinene, (–)-β-pinene, (+)-limonene, (–)-borneol, and (–)-bornyl acetate, generally showed broad antimicrobial activity. Furthermore, (±)-α-pinene and (–)-β-pinene have shown strong activity against methicillin-resistant S. aureus (MRSA) with IC50 values of 68.6 and 51.4 μg/mL, respectively [22], and both α-pinene and β-pinene (enantiomers not indicated) were active against Klebsiella pneumoniae with MIC values of 178 μg/mL and 170 μg/mL, respectively [23]. Terpinolene, not available for screening in this study, was found to be inactive (MIC >> 2000 μg/mL) against C. acnes and S. aureus [24]. Schepetkin and co-workers found that G. squarrosa essential oil as well as (−)-borneol activated human neutrophils [19]. Neutrophils play a critical role in inflammation. The antimicrobial activities of G. squarrosa essential oil components, coupled with the modulation of human neutrophil function of (−)-borneol, are consistent with Native American use of G. squarrosa to treat respiratory and dermal conditions.

3. Materials and Methods

3.1. Plant Material

Aerial parts of Grindelia squarrosa were collected from several plants growing wild near Bogus Basin Ski Resort, Idaho on July 7, 2022 (43°43′34″ N, 116°9′28″ W, 1482 m elevation). The plant was identified by W.N. Setzer. Based on botanical descriptions [11] and comparison with specimens from the New York Botanical Garden [7] the plant was identified as G. squarrosa var. serrulata. A voucher specimen (WNS-Gss-5718) has been deposited in the University of Alabama in Huntsville herbarium. The fresh plant material from several plants was combined and 91.11 g was hydrodistilled to give 597 mg of a colorless essential oil.

3.2. Gas Chromatographic Analysis

The essential oil of G. squarrosa var. serrulata was analyzed via gas chromatography mass spectrometry (GC-MS), gas chromatography with flame ionization detection (GC-FID), and chiral GC-MS as previously described in [25]. Briefly, gas chromatography—mass spectrometry (GC-MS) was carried out using a Shimadzu GC-MS-QP2010 Ultra (Shimadzu Scientific Instruments, Columbia, MD, USA). The mass selective detector was operated in the electron impact (EI) mode with an electron energy of 70 eV, a scan range of 40–400 atomic mass units and a scan rate of 3.0 scans per second, using the GC-MS solution software. The GC column used was a Zebron ZB-5ms fused silica capillary column (Phenomenex, Torrance, CA, USA), 60 m in length and 0.25 mm inner diameter; the stationary phase was (5% phenyl)-polydimethylsiloxane with a film thickness of 0.25 μm. The carrier gas was helium and the column head pressure was 208.3 kPa with a flow rate of 2.00 mL/min. The injector temperature was 260 °C, the interface temperature was 260 °C, and the ion source temperature was 260 °C. The GC oven temperature was programmed with an initial temperature of 50 °C; the temperature was increased to 260 °C at a rate of 2 °C/min, and then held at 260 °C for 5 min, for a total GC acquisition time of 110 min. The solvent cut time was set at 5 min. A 5% (w/v) solution of G. squarrosa var. squarrosa essential oil in dichloromethane was prepared and a volume of 0.1 μL was injected and the splitting mode was set at 24.5:1. Retention index (RI) values were determined by calibrating the instrument using a homologous series of n- alkanes using the logarithm-based arithmetic index method developed by van den Dool and Kratz [26]. The components of the essential oil were identified by comparing the mass spectral fragmentation patterns and the retention index values available in the Adams [27], FFNSC3 [28], NIST20 [29], and Satyal [30] databases.
Gas chromatography with flame ionization detection (GC-FID) was carried out on G. squarrosa var. squarrosa essential oil using a Shimadzu GC 2010 equipped with a flame ionization detector (Shimadzu Scientific Instruments, Columbia, MD, USA) and using a Zebron ZB-5 GC column (60 m × 0.25 mm × 0.25 μm film thickness) (Phenomenex, Torrance, CA, USA). The same operating conditions were used for the GC-FID as those for GC-MS (above). The percent compositions were calculated from raw peak areas without standardization.
The G. squarrosa var. squarrosa essential oil was analyzed via chiral gas chromatography—mass spectrometry using a Shimadzu GCMS-QP2010S instrument (Shimadzu Scientific Instruments, Columbia, MD, USA). The mass selective detector was operated in the electron impact (EI) mode with an electron energy of 70 eV, a scan range of 40–400 atomic mass units and a scan rate of 3.0 scans per second that was fitted with a Restek B-Dex 325 chiral GC column (30 m length × 0.25 mm inner diameter × 0.25 μm film thickness) (Restek Corp., Bellefonte, PA, USA); the stationary phase was 25% 2,3-di-O-methyl-6-O-t-butyldimethylsilyl-β-cyclodextrin in SPB-20 poly(20% phenyl/80% dimethylsiloxane) phase with a film thickness of 0.25 μm. Helium was the carrier gas, the column head pressure was 53.6 kPa, and the flow rate was 1.00 mL/min. The injector temperature was 240 °C, the ion source temperature was 240 °C, and the interface temperature was 240 °C. The solvent cut time was 5 min. The GC oven temperature was programmed with an initial temperature of 50 °C, which was held for 5 min, then increased at a rate of 1 °C/min until a temperature of 100 °C, after which the temperature was increased at a rate of 2 °C/min to 220 °C, for a total GC acquisition time of 107 min. A 0.3-mL sample of the essential oil (5% w/v in dichloromethane) was injected using a splitting mode of 24.0:1. The compound enantiomers were determined by comparing their retention times with authentic samples obtained from Sigma-Aldrich (St. Louis, MO, USA). The ratios of enantiomers were calculated from raw peak areas.

3.3. Antibacterial and Antifungal Screening

The essential oil components, (+)-α-pinene, (–)-α-pinene, (–)-β-pinene, (+)-limonene, (–)-limonene, (–)-borneol, and (–)-bornyl acetate were obtained from Sigma-Aldrich (St. Louis, MO, USA) and were used as received. The compounds were screened for antibacterial activity against Gram-positive bacteria Cutibacterium acnes (ATCC No. 11827), Staphylococcus aureus (ATCC No. 29213), Staphylococcus epidermidis (ATCC No. 12228), Streptococcus pneumoniae (ATCC No. 49136), and Streptococcus pyogenes (ATCC No. 19615), and for antifungal activity against dermatophyte molds Microsporum canis (ATCC No. 11621), Microsporum gypseum (ATCC No. 24102), Serratia marcescens (ATCC No. 14756), Trichophyton mentagrophytes (ATCC No. 18748), and Trichophyton rubrum (ATCC No. 28188), using the microbroth dilution technique [31,32].
Each of the bacterial strains was cultured on tryptic soy agar medium. A 5000-μg/mL solution of each test compound was prepared in dimethylsulfoxide (DMSO, Sigma-Aldrich, St. Louis, MO, USA), and 50 μL was diluted in 50 μL of cation-adjusted Mueller Hinton broth (CAMBH) (Sigma-Aldrich, St. Louis, MO, USA), the 100-μL mixture was added to the top well of a 96-well microdilution plate. The prepared stock solution of each compound was serially two-fold-diluted in fresh CAMBH to obtain final concentrations of 2500, 1250, 625, 312.5, 156.3, 78.1, 39.1, and 19.5 μg/mL (final DMSO concentrations of 50%, 25%, 12.5%, 6.25%, 3.13%, 1.56%, 0.78%, and 0.39%). Freshly harvested bacteria with approximately 1.5 × 108 colony-forming units (CFU) per mL final concentration (determined using McFarland standard) were added to each well of the 96-well microdilution plates, which were then incubated at 37 °C for 24 h. Gentamicin (Sigma-Aldrich, St. Louis, MO, USA) was used as the positive antibacterial control and DMSO was the negative control. The minimum inhibitory concentration (MIC) was determined to be the lowest-concentration well that did not show turbidity. Each assay was carried out in triplicate.
For the antifungal screening, the tested fungi were cultured on yeast malt agar (Sigma-Aldrich, St. Louis, MO, USA). Stock solutions (5000 μg/mL) of the test compounds were prepared in DMSO and diluted as above in fresh yeast-nitrogen growth medium (broth) (Sigma-Aldrich, St. Louis, MO, USA). The freshly harvested fungi, with approximately 7.5 × 107 CFU/mL final concentrations in yeast-nitrogen growth medium, were added to each well of the 96-well microdilution plates and were then incubated at 35 °C for 24 h. Amphotericin B (Sigma-Aldrich, St. Louis, MO, USA) served as the positive antifungal control, while the negative control was DMSO. The antifungal assays were carried out in triplicate.

4. Conclusions

This is the first report on the essential oil characterization of Grindelia squarrosa var. serrulata from southern Idaho. The essential oil was rich in monoterpenoids and comparable in composition to G. squarrosa (variety not indicated) from western Montana, which suggests chemotype stability in North American populations; however, it was very different from G. squarrosa essential oils cultivated in Europe. The antimicrobial activities of the major components of G. squarrosa essential oil support the use of the plant to treat respiratory and dermal infections.

Author Contributions

Conceptualization, W.N.S.; methodology, N.S.D., P.S. and W.N.S.; software, P.S.; validation, P.S. and W.N.S.; formal analysis, P.S. and W.N.S.; investigation, A.P., N.S.D., P.S., K.S. and W.N.S.; resources, P.S. and W.N.S.; data curation, W.N.S.; writing—original draft preparation, W.N.S.; writing—review and editing, N.S.D., P.S. and W.N.S.; supervision, P.S. and W.N.S.; project administration, W.N.S. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

Not applicable.

Informed Consent Statement

Not applicable.

Data Availability Statement

All data are available in the article.

Acknowledgments

This work was carried out as part of the activities of the Aromatic Plant Research Center (APRC, https://aromaticplant.org/, accessed on 7 April 2023).

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. World Flora Online, W.F.O. Grindelia Willd. Available online: http://www.worldfloraonline.org/search?query=Grindelia&limit=24&start=0&sort= (accessed on 1 March 2023).
  2. Flora of North America, E.B.  Grindelia. Available online: http://www.efloras.org/florataxon.aspx?flora_id=1&taxon_id=114086 (accessed on 1 March 2023).
  3. Flora of North America, Editorial Committee.  Grindelia squarrosa. Available online: http://www.efloras.org/florataxon.aspx?flora_id=1&taxon_id=242416609 (accessed on 27 February 2023).
  4. Kartesz, J.T. The Biota of North America Program (BONAP). Available online: http://bonap.net/MapGallery/County/Grindelia%20squarrosa.png (accessed on 13 June 2022).
  5. Shevera, M.; Kucher, O.; Zavialova, L.; Bzdęga, K.; Nowak, T.; Zarychta, A.; Tokarska-Guzik, B. Grindelia squarrosa—Economically useful or an invasive plant in Europe? In Proceedings of the 15th Ecology and Management of Alien Plant Invasions (EMAPi); Czech Academy of Sciences: Prague, Czech Republic, 2019; p. 183. [Google Scholar]
  6. World Flora Online, W.F.O. Grindelia squarrosa (Pursh) Dunal. Available online: http://www.worldfloraonline.org/search?query=Grindelia+squarrosa (accessed on 27 February 2023).
  7. New York Botanical Garden, N.Y.B.G. C. V. Starr Virtual Herbarium. Available online: https://sweetgum.nybg.org/science/vh/specimen-list/?SummaryData=Grindelia%20squarrosa (accessed on 13 June 2022).
  8. Moerman, D.E. Native American Ethnobotany; Timber Press, Inc.: Portland, OR, USA, 1998; ISBN 978-0-88192-453-4. [Google Scholar]
  9. Dictionary of Natural Products Dictionary of Natural Products on DVD; CRC Press: Boca Raton, FL, USA, 2022; ISBN 978-0-412-49150-4.
  10. Neupane, B.P.; Shintani, D.; Lin, H.; Coronella, C.J.; Miller, G.C. Grindelia squarrosa: A potential arid lands biofuel plant. ACS Sustain. Chem. Eng. 2017, 5, 995–1001. [Google Scholar] [CrossRef]
  11. Steyermark, J.A. Studies in Grindelia. II. A monograph of the North American species of the genus Grindelia. Ann. Mo. Bot. Gard. 1934, 21, 433–608. [Google Scholar] [CrossRef]
  12. Newton, M.N.; Espinar, L.A.; Grosso, N.R.; Zunino, M.P.; Maestri, D.M.; Zygadlo, J.A. Analysis of the essential oil of Grindelia discoidea. Planta Med. 1998, 64, 470–473. [Google Scholar] [CrossRef] [PubMed]
  13. El-Shamy, A.M.; El-Hawary, S.S.; El-Shabrawy, A.O.; El-Hefnawy, H.M.; Glasl, H. Essential oil composition of three Grindelia species. J. Essent. Oil Res. 2000, 12, 631–634. [Google Scholar] [CrossRef]
  14. Fraternale, D.; Giamperi, L.; Bucchini, A.; Ricci, D. Essential oil composition and antioxidant activity of aerial parts of Grindelia robusta from Central Italy. Fitoterapia 2007, 78, 443–445. [Google Scholar] [CrossRef] [PubMed]
  15. Bertaccini, A.; Contaldo, N.; Benni, A.; Curini, M.; Genovese, S.; Epifano, F.; Bellardi, M.G. Effects of “Candidatus Phytoplasma asteris” on the volatile chemical content and composition of Grindelia robusta Nutt. J. Phytopathol. 2011, 159, 124–126. [Google Scholar] [CrossRef]
  16. Schäfer, M.; Schimmer, O. Composition of the essential oils from flowers, leaves and stems of Grindelia robusta and G. squarrosa. J. Essent. Oil Res. 2000, 12, 547–552. [Google Scholar] [CrossRef]
  17. Veres, K.; Roza, O.; Laczkó-Zöldb, E.; Hohmann, J. Chemical composition of essential oils of Grindelia squarrosa and G. hirsutula. Nat. Prod. Commun. 2014, 9, 573–574. [Google Scholar] [CrossRef] [PubMed]
  18. Nowak, S.; Lisiecki, P.; Tomaszczak-Nowak, A.; Grudzińska, E.; Olszewska, M.A.; Kicel, A. Chemical composition and antimicrobial activity of the essential oils from flowers and leaves of Grindelia integrifolia DC. Nat. Prod. Res. 2019, 33, 1535–1540. [Google Scholar] [CrossRef] [PubMed]
  19. Schepetkin, I.A.; Özek, G.; Özek, T.; Kirpotina, L.N.; Khlebnikov, A.I.; Quinn, M.T. Neutrophil immunomodulatory activity of (−)-borneol, a major component of essential oils extracted from Grindelia squarrosa. Molecules 2022, 27, 4897. [Google Scholar] [CrossRef] [PubMed]
  20. Duarte, M.C.T.; Leme, E.E.; Delarmelina, C.; Soares, A.A.; Figueira, G.M.; Sartoratto, A. Activity of essential oils from Brazilian medicinal plants on Escherichia coli. J. Ethnopharmacol. 2007, 111, 197–201. [Google Scholar] [CrossRef] [PubMed]
  21. Van Vuuren, S.; Holl, D. Antimicrobial natural product research: A review from a South African perspective for the years 2009–2016. J. Ethnopharmacol. 2017, 208, 236–252. [Google Scholar] [CrossRef] [PubMed]
  22. Utegenova, G.A.; Pallister, K.B.; Kushnarenko, S.V.; Özek, G.; Özek, T.; Abidkulova, K.T.; Kirpotina, L.N.; Schepetkin, I.A.; Quinn, M.T.; Voyich, J.M. Chemical composition and antibacterial activity of essential oils from Ferula L. species against methicillin-resistant Staphylococcus aureus. Molecules 2018, 23, 1679. [Google Scholar] [CrossRef] [PubMed]
  23. Yang, C.; Hu, D.-H.; Feng, Y. Antibacterial activity and mode of action of the Artemisia capillaris essential oil and its constituents against respiratory tract infection-causing pathogens. Mol. Med. Rep. 2015, 11, 2852–2860. [Google Scholar] [CrossRef] [PubMed]
  24. Lee, C.-J.; Chen, L.-W.; Chen, L.-G.; Chang, T.-L.; Huang, C.-W.; Huang, M.-C.; Wang, C.-C. Correlations of the components of tea tree oil with its antibacterial effects and skin irritation. J. Food Drug Anal. 2013, 21, 169–176. [Google Scholar] [CrossRef]
  25. Swor, K.; Satyal, P.; Timsina, S.; Setzer, W.N. Chemical composition and terpenoid enantiomeric distribution of the essential oil of Artemisia tridentata subsp. tridentata from southwestern Idaho. Nat. Prod. Commun. 2022, 17, 1934578X2211174. [Google Scholar] [CrossRef]
  26. van den Dool, H.; Kratz, P.D. A generalization of the retention index system including linear temperature programmed gas-liquid partition chromatography. J. Chromatogr. A 1963, 11, 463–471. [Google Scholar] [CrossRef] [PubMed]
  27. Adams, R.P. Identification of Essential Oil Components by Gas Chromatography/Mass Spectrometry, 4th ed.; Allured Publishing: Carol Stream, IL, USA, 2007; ISBN 978-1-932633-21-4. [Google Scholar]
  28. Mondello, L. FFNSC 3; Shimadzu Scientific Instruments: Columbia, MD, USA, 2016. [Google Scholar]
  29. NIST20; National Institute of Standards and Technology: Gaithersburg, MD, USA, 2020.
  30. Satyal, P. Development of GC-MS Database of Essential Oil Components by the Analysis of Natural Essential Oils and Synthetic Compounds and Discovery of Biologically Active Novel Chemotypes in Essential Oils. Ph.D. Thesis, University of Alabama in Huntsville, Huntsville, AL, USA, 2015. [Google Scholar]
  31. EUCAST Determination of minimum inhibitory concentrations (MICs) of antibacterial agents by broth dilution. Clin. Microbiol. Infect. 2003, 9, ix–xv. [CrossRef]
  32. Poudel, D.K.; Dangol, S.; Rokaya, A.; Maharjan, S.; Ojha, P.K.; Rana, J.; Dahal, S.; Timsina, S.; Dosoky, N.S.; Satyal, P.; et al. Quality assessment of Zingiber officinale Roscoe essential oil from Nepal. Nat. Prod. Commun. 2022, 17, 1934578X221080322. [Google Scholar] [CrossRef]
Figure 1. Grindelia squarrosa var. serrulata from southern Idaho. Photograph by K. Swor.
Figure 1. Grindelia squarrosa var. serrulata from southern Idaho. Photograph by K. Swor.
Molecules 28 03854 g001
Table 1. Chemical composition of the essential oil from the aerial parts of Grindelia squarrosa var. serrulata collected in southern Idaho.
Table 1. Chemical composition of the essential oil from the aerial parts of Grindelia squarrosa var. serrulata collected in southern Idaho.
RIcalcRIdbCompounds%RIcalcRIdbCompounds%
7887803-Methyl-2 butenal0.113921392(Z)-Jasmone0.1
849849(2E)-Hexenal0.214291427γ-Elemene1.6
923923Tricyclene0.114471447Geranylacetone0.1
926925α-Thujene0.114541454α-Humulene0.2
934933α-Pinene21.914741475γ-Muurolene0.1
950950Camphene1.714801480Germacrene D2.4
953953Thuja-2,4(10)-diene0.214871487β-Selinene0.3
972971Sabinene0.214941497Bicyclogermacrene0.2
978978β-Pinene4.214971500α-Muurolene0.1
989989Myrcene1.015011504epi-Zonarene0.1
10071006α-Phellandrene0.715041503Bornyl isovalerate0.1
10101009δ-3-Carene0.1151115101,11-Oxidocalamenene0.4
10171017α-Terpinene0.315161518δ-Cadinene0.3
10251025p-Cymene0.215351540Selina-4(15),7(11)-diene0.2
10301026Limonene17.115391542Selina-3,7(11)-diene0.1
10321031β-Phellandrene0.115571557Germacrene B3.5
103310321,8-Cineole0.115691571(3Z)-Hexenyl benzoate0.1
103510342,2,6-Trimethylcyclohexanone0.115741576Spathulenol0.1
10351034(Z)-β-Ocimenetr15771581Hexyl benzoate0.1
10461046(E)-β-Ocimene1.715831582epi-Globulol0.1
10571057γ-Terpinene0.116241624Selina-6-en-4β-ol0.1
10861086Terpinolene10.6162616271-epi-Cubenol0.1
10901093p-Cymenene0.116401638τ-Cadinol0.1
11131113(E)-4,8-Dimethylnona-1,3,7-triene0.216421640τ-Muurolol0.2
11211122Chrysanthenone0.216451644α-Muurolol (=δ-Cadinol)0.1
11271127α-Campholenal0.516531649β-Eudesmol1.4
112911291,3,8-p-Menthatriene0.216951696Juniper camphor0.2
11411141trans-Pinocarveol1.017651769Benzyl benzoate0.2
11421140cis-Verbenol0.519901994Manoyl oxide1.3
11461145trans-Verbenol2.22226aMethyl grindelate0.2
11471145Camphor0.423002300Tricosane0.3
11501150α-Phellandren-8-ol0.223562355Grindelic acid1.5
11621164Pinocarvone0.624002400Tetracosane0.2
11721170Borneol6.525002500Pentacosane1.4
11761176cis-Pinocamphone0.326002600Hexacosane0.2
11801180Terpinen-4-ol0.227002700Heptacosane1.0
11881188p-Cymen-8-ol0.228002800Octacosanetr
11961196Myrtenal0.7 Monoterpene hydrocarbons60.4
11971194Myrtenol0.4 Oxygenated monoterpenoids18.6
12081205Verbenone0.9 Sesquiterpene hydrocarbons9.5
12171217Coumaran0.5 Oxygenated sesquiterpenoids4.0
12201218trans-Carveol0.3 Diterpenoids1.7
12851285Bornyl acetate3.3 Benzenoid aromatics1.0
130813094-Vinylguaicol0.2 n-Alkanes3.2
13221322Myrtenyl acetate0.1 Others1.0
13321334Bicycloelemene0.2 Total identified99.3
13351336δ-Elemene0.3
RIcalc = Retention index determined with respect to a homologous series of n-alkanes on a ZB-5ms column. RIdb = Reference retention index obtained from the databases. tr = trace (<0.05%). a—The MS fragmentation showed 85% similarity, but a reference RI was not available.
Table 2. Major components of Grindelia essential oils.
Table 2. Major components of Grindelia essential oils.
Grindelia SpeciesGeographical OriginMajor Components (>4%)Ref.
Grindelia discoidea Hook. & Arn. (syn. G. pulchella var. pulchella)Argentina(Z,E)-Farnesol (18.2–34.9%), (E,E)-farnesol (9.0–16.8%), γ-cadinene (9.4–15.6%), globulol (6.2–10.5%), (E)-β-caryophyllene (trace-8.6%), δ-cadinene (3.2–6.1%) [12]
Grindelia hirsutula Hook. & Arn.RomaniaLimonene (7.0%), α-pinene (6.2%), germacrene D (4.2%), spathulenol (5.5%), 10,11-epoxycalamenene (4.1%) [17]
Grindelia humilis Hook. & Arn. (syn. G. hirsutula Hook. & Arn.)EgyptPolyacetylene isomer (22.1%), germacrene D (11.9%), polyacetylene isomer (10.5%), bornyl acetate (5.1%), α-pinene (4.9%), (E)-lachnophyllol acetate (4.1%) [13]
Grindelia integrifolia DC.PolandMyrcene (16.9%), spathulenol (12.3%), β-eudesmol (11.9%), limonene (10.1%), α-cadinene (6.4%), α-pinene (4.6%), germacrene D (4.5%), humulene epoxide I (4.1%) [18]
Grindelia robusta Nutt. (syn. G. hirsutula Hook. & Arn.)GermanyGermacrene D (23.3%), α-pinene (13.4%), germacrene B (8.3%), myrcene (7.2%), (E)-β-caryophyllene (4.1%) [16]
Commercial aBorneol (14.8%), α-pinene (8.8%), trans-pinocarveol (6.1%), bornyl acetate (5.4%), limonene (4.1%), p-cymen-8-ol (4.1%) [13]
ItalyBorneol (15.2%), α-pinene (10.3%), trans-pinocarveol (7.0%), bornyl acetate (4.5%), limonene (4.3%), β-eudesmol (4.1%) [14]
ItalyBorneol (15.0%), α-pinene (11.0%), trans-pinocarveol (8.2%), β-eudesmol (5.5%), bornyl acetate (4.4%), β-selinene (4.3%), limonene (4.2%), [15]
Grindelia squarrosa (Pursh) DunalGermanyLimonene (16.2%), germacrene B (13.2%), α-pinene (10.4%), phytone (6.5%), bornyl isovalerate (4.3%) [16]
Commercial aLimonene (16.8%), α-pinene (16.1%), germacrene D (6.8%), β-pinene (5.2%), borneol (4.5%) [13]
RomaniaBornyl acetate (10.8%), α-pinene (8.3%), limonene (8.1%), spathulenol (5.4%), caryophyllene oxide (4.9%) [17]
Montana, USAα-Pinene (23.2%), borneol (16.6%), limonene (14.7%), p-cymen-8-ol (5.8%), bornyl acetate (5.1%) [19]
Idaho, USAα-Pinene (21.9%), limonene (17.1%), terpinolene (10.6%), borneol (6.5%), β-pinene (4.2%)this work
a Commercial sample, purchased in Germany, but geographical source not indicated.
Table 3. Enantiomeric distribution of terpenoids in Grindelia squarrosa var. serrulata essential oil.
Table 3. Enantiomeric distribution of terpenoids in Grindelia squarrosa var. serrulata essential oil.
CompoundsRTstdRTEO%
(–)-α-Pinene15.9215.1999.3
(+)-α-Pinene16.4016.380.7
(–)-Camphene17.7317.8699.0
(+)-Camphene18.3018.401.0
(+)-Sabinene19.7419.78100.0
(–)-Sabinene20.60nd0.0
(+)-β-Pinene20.2720.2810.7
(–)-β-Pinene20.6220.6289.3
(–)-α-Phellandrene22.59nd0.0
(+)-α-Phellandrene22.8122.85100.0
(–)-Limonene25.0625.092.8
(+)-Limonene25.9925.3997.2
(–)-β-Phellandrene26.1526.5029.4
(+)-β-Phellandrene26.8827.0670.6
(–)-Camphor49.8450.12100.0
(+)-Camphor50.34nd0.0
(–)-Borneol58.5958.31100.0
(+)-Borneol59.11nd0.0
(–)-Bornyl acetate59.4659.48100.0
(+)-Bornyl acetatenand0.0
(–)-α-Terpineol59.7359.7980.2
(+)-α-Terpineol60.5860.6219.8
(–)-Verbenone61.7061.84100.0
(+)-Verbenonenand0.0
(+)-Germacrene D73.4873.5278.5
(–)-Germacrene D73.7373.7821.5
RTstd = Retention time for standard compounds in minutes, RTEO = Retention time for the essential oil in minutes, na = standard compound not available, nd = compound not detected.
Table 4. Antibacterial and antifungal activities (MIC, μg/mL) of essential oil components.
Table 4. Antibacterial and antifungal activities (MIC, μg/mL) of essential oil components.
Bacteria
CompoundCutibacterium
acnes
Staphylococcus aureusStaphylococcus epidermidisStreptococcus pneumoniaeStreptococcus
pyogenes
(+)-α-Pinene625625312.578.1625
(–)-α-Pinene a625312.5312.578.1312.5
(–)-β-Pinene a312.5156.3312.539.1625
(+)-Limonene a625312.5312.578.1312.5
(–)-Limonene39.1312.578.178.1625
(–)-Borneol a312.578.1312.5625625
(–)-Bornyl acetate a312.5312.5312.5312.5625
Gentamicin b<19.50.61<19.5<19.5<19.5
DMSO c12501250125012501250
Fungi
Microsporum
canis
Microsporum gypseumSerratia
marcescens
Trichophyton mentagrophytesTrichophyton rubrum
(+)-α-Pinene312.5156.3312.5156.3312.5
(–)-α-Pinene a312.5312.5312.5312.5312.5
(–)-β-Pinene a312.5312.5312.5156.3312.5
(+)-Limonene a312.5312.5625312.5312.5
(–)-Limonene312.5156.3312.5156.3312.5
(–)-Borneol a312.5312.5625156.3312.5
(–)-Bornyl acetate a312.5312.5625156.3312.5
Amphotericin B b<19.5<19.5<19.5<19.5<19.5
DMSO c12501250125012501250
a Major enantiomer. b Positive control. c Dimethylsulfoxide, negative control.
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.

Share and Cite

MDPI and ACS Style

Poudel, A.; Dosoky, N.S.; Satyal, P.; Swor, K.; Setzer, W.N. Essential Oil Composition of Grindelia squarrosa from Southern Idaho. Molecules 2023, 28, 3854. https://doi.org/10.3390/molecules28093854

AMA Style

Poudel A, Dosoky NS, Satyal P, Swor K, Setzer WN. Essential Oil Composition of Grindelia squarrosa from Southern Idaho. Molecules. 2023; 28(9):3854. https://doi.org/10.3390/molecules28093854

Chicago/Turabian Style

Poudel, Ambika, Noura S. Dosoky, Prabodh Satyal, Kathy Swor, and William N. Setzer. 2023. "Essential Oil Composition of Grindelia squarrosa from Southern Idaho" Molecules 28, no. 9: 3854. https://doi.org/10.3390/molecules28093854

Article Metrics

Back to TopTop
