As the core component of ultra-precision machine tools, the manufacturing errors of aerostatic spindles are inevitable due to the limitations of machining and assembly processes, and these errors significantly affect the spindle’s static and dynamic performance. To address this issue, a force model of the unbalanced air film, considering the straightness errors of the rotor’s radial and thrust surfaces, was constructed. Unlike conventional studies that rely solely on idealized error assumptions, this research integrates actual straightness measurement data into the simulation process, enabling a more realistic and precise prediction of bearing performance. Rotors with different tolerance specifications were fabricated, and static performance simulations were carried out based on the measured geometry data. An experimental setup was built to evaluate the performance of the aerostatic spindle assembled with these rotors. The experimental results were compared with the simulation outcomes, confirming the validity of the proposed model. To further quantify the influence of straightness errors on the static characteristics of aerostatic spindles, ideal functions were used to define representative manufacturing error profiles. The results show that a barrel-shaped error on the radial bearing surface can cause a load capacity variation of up to 46.6%, and its positive effect on air film load capacity is more significant than that of taper or drum shapes. For the thrust bearing surface, a concave-shaped error can lead to a load capacity variation of up to 13.4%, and its enhancement effect is superior to those of the two taper and convex-shaped errors. The results demonstrate that the straightness errors on the radial and thrust bearing surfaces are key factors affecting the radial and axial load capacities of the spindle. Full article

In the working process of the gas bearings, the unbalanced force of the rotor will increase nonlinearly with the increase in the rotating speed, resulting in an increase in the rotor’s vibration amplitude. On the other hand, with the increase in the rotating speed, the hydrodynamic effect will increase, and the nonlinear increase in the gas film force and stiffness will inhibit the increase in the vibration amplitude. In order to deeply study the influence of the unbalanced force and nonlinear gas film force on the vibration amplitude of the ultra-precision aerostatic motorized spindle, taking the double slit throttling gas bearing as an example, according to the equilibrium equation of the rotor under the combined action of gravity, the gas film force, and the unbalanced force, a calculation program based on the finite difference method for solving the rotor’s equilibrium position is completed. The calculation results show that: the hydrodynamic effect can significantly increase the bearing capacity and cause the change of the static equilibrium position of the rotor, but the offset amplitude of the static equilibrium position of the rotor gradually slows down with the increase in the rotating speed. The hydrodynamic effect improves the stiffness near the static equilibrium position of the rotor, making the rotor vibration track tend to be more “round”. Although the unbalanced force of the rotor increases nonlinearly as the rotating speed increases, the maximum offset between the dynamic equilibrium position and the static equilibrium position of the rotor under the action of the rotating unbalanced force is approximately linear with the rotating speed. Compared with the air supply pressure, the rotor unbalance and rotating speed are the main factors affecting the rotor dynamic equilibrium position offset. This study has a reference role in the in-depth study of the influence of rotating speed and rotor unbalance on the rotor static equilibrium position and dynamic equilibrium position offset, as well as in the design of gas bearings and the prediction of rotor vibration amplitude. Full article

To develop an innovative aerostatic guideway without cable drag force that can be widely applied to ultra-precision machining and measurement technology, it is necessary to analyze the static performance of the aerostatic guideway. The structural properties of the cableless aerostatic guideway, i.e., the bearing capacity and internal pressure distribution, directly affect the accuracy of processing and measurement. In this work, the relevant flow equations of the cableless aerostatic guideway are established by considering the unbalanced micro-scale air film. Moreover, the finite difference method is used to solve the calculation of the global analysis of air film at different positions. In addition, this work compares and analyzes the pressure and fluid velocity vector distributions in balanced and unbalanced states and investigates the effect of varying the thicknesses of the air film on static characteristics such as bearing capacity and stiffness. By comparing the balanced and unbalanced states under the same conditions, the obtained results show that in the unbalanced situation, the bearing capacity is lower by 11.69 percent and the stiffness is slightly higher (by 16.67 percent). Furthermore, the related experiments verify the predicted dependence of the bearing capacity on the thickness of the air film, and further demonstrate the feasibility of the proposed structure of the cableless aerostatic guideway. This work provides a technical reference for the design of a cableless aerostatic guideway. Full article

In the research on the aerostatic spindle, for quantifying the influence of shaft shape errors on its rotation accuracy, the calculation models of unbalanced air film force (UAFF) and centrifugal inertia force (CIF) are established. Based on the typical shape of the shaft, three composite cylinder models are constructed. The data sources are selected from the cylindricity measurement results of the shaft and substituted into the model for calculation. The results show that, for the shaft in this paper, when the roundness deviation is ≤1.25 μm and the cylindricity deviation is ≤2 μm, the influence of shape errors on the rotation accuracy of the shaft is small enough. The harmonic analysis of the data source shows that the magnitude and stability of the UAFF on the shaft are determined by the actual shape of the shaft’s cylindrical surface, and cannot be inferred only by the value of shape errors. Full article
