To study the influence of tip clearance on the working characteristics of high-altitude fans, this paper takes the MIX-140 high-altitude fan as the research object. Five different tip clearance (TC) models are selected. The CFD method is used to analyze the changes in the working characteristics of the fan under different flow rates and TCs in ground and high-altitude environments. The reliability of the numerical method is verified through a fan test bench. The results show that the tip leakage flow caused by the TC will continuously deteriorate the working characteristics of the fan. Under the rated flow rate in the ground environment, for every doubling of the blade’s TC, the static pressure difference will decrease by 5%, the efficiency will decrease by 2%, and the power will decrease by 3%. In a high-altitude environment, the flow rate corresponding to the maximum shaft power point of the fan will continuously increase with an increase in the tip clearance, which will bring about additional energy consumption. For high-altitude fans, the deformation caused by the high-speed rotation of the impeller needs to be taken into account. Undoubtedly, it is advantageous to choose the smallest possible tip clearance value. The results of the analysis and test methods in this paper will provide a basis for designing the tip clearance of high-altitude fans. Full article

The influence mechanism of the blade tip clearance (TC) of an inducer on the performance of a centrifugal pump at high speed was researched under different flow rate conditions in this work. An experiment on the pump’s external performance was carried out, and numerical calculation was also performed under four different TCs. The full characteristic performance curves, static pressure and pressure pulsation distributions of the pump were obtained. Through the research and analysis, it was found that the influence of the TC on the efficiency and the head of the centrifugal pump are related to the flow rate. Under the influence of a large flow rate, the increase in the TC is helpful to improve the efficiency and the head of the pump. The increase in the TC helps to weaken the gap jet effect on the inducer. The inlet jet of the inducer, caused by TC leakage, will form a low-pressure vortex zone at the inlet of the inducer. The splitter-bladed inducer’s pressure pulsation is affected by the TC. The peak pressure pulsation at the monitoring point at the short blades is larger than that at the long blades. With the increase in TC, the cavitation degree at the inlet of the long blade of the inducer is decreased, while the cavitation degree at the short blade is deepened. It is also found that the TC has little effect on the radial force of the inducer and the impeller. These results will provide the design basis for the tip clearance of an inducer. Full article

Numerical simulations have been performed to study the effect of the circumferential single-grooved casing treatment (CT) at multiple locations on the tip-flow stability and the corresponding control mechanism at three tip-clearance-size (TCS) schemes in a transonic axial flow compressor rotor. The results show that the CT is more efficient when its groove is located from 10% to 40% tip axial chord, and G2 (located at near 20% tip axial chord) is the best CT scheme in terms of stall-margin improvement for the three TCS schemes. For effective CTs, the tip-leakage-flow (TLF) intensity, entropy generation and tip-flow blockage are reduced, which makes the interface between TLF and mainstream move downstream. A quantitative analysis of the relative inlet flow angle indicates that the reduction of flow incidence angle is not necessary to improve the flow stability for this transonic rotor. The control mechanism may be different for different TCS schemes due to the distinction of the stall inception process. For a better application of CT, the blade tip profile should be further modified by using an optimization method to adjust the shock position and strength during the design of a more efficient CT. Full article

For a high-speed centrifugal pump, cavitation occurs easily. To equip a high-performance splitter-bladed inducer upstream of the pump is an effective method to suppress cavitation. In this paper, an external characteristics experiment of the high-speed centrifugal pump with a splitter-bladed inducer is carried out, and the corresponding numerical calculations are completed. The research shows that the results of the numerical calculation are credible. Numerical cavitation calculations under eight different tip clearance conditions are carried out. First, it is found that the tip clearance (TC) has a certain impact on the head of the centrifugal pump. When TC is in a small range, the clearance leakage is small, and the impact on the head of the pump is not so obvious, which can give the pump a higher performance. Second, it is found that TC has a certain influence on the static pressure distribution in the cascade passage of the splitter-bladed inducer. When TC is in a certain range, the increasement in TC will aggravate the cavitation at the suction surface of the long blades near the inlet. When it exceeds the certain range, it will cause cavitation at the outlet of the inducer. At last, it is found that the cavitation’s severity and position of the inducer are closely related to TC. TC affects the magnitude and position of vorticity in the inducer’s passage. In this paper the flow mechanism of TC is revealed, and its research results can provide theoretical basis and technical support for the design of the tip clearance of the inducers. Full article

Unavoidable tip clearance between blade tip and casing shroud plays an important role in the performance and characteristics of a tidal propeller turbine. In this work, the tip-leakage vortex (TLV) induced in the end-wall region was numerically illustrated by using the shear-stress transport (SST) k–ω turbulence model at various flow conditions and different tip-clearance sizes (TCSs). The swirling strength criterion was employed to visualize the tip-leakage vortex trajectory and investigate vortex evolution according to clearance size change. Although TLV occurs in both design and off-design conditions, vortex intensity develops strongly under excess flow rate with increased tip gap. The extreme influence of TCS on the turbine’s generated power and efficiency was predicted in steady simulations for four TCS cases, namely, δ = 0%, 0.25%, 0.5%, and 0.75%. With the extension of the tip gap, turbine performance was drastically reduced because of vigorous turbulent leakage flow combined with considerable volumetric loss. The effect of TCS on pressure fluctuation intensity were also explored on the basis of the transient simulation statistic. Maximal pressure variation amplitude and dominant frequency were presented in spectrum analysis utilizing fast Fourier transform. Full article

Blade tip timing (BTT) technology is considered the most promising method for blade vibration measurements due to the advantages of its simplicity and non-contact measurement capacity. Nevertheless, BTT technology still suffers from two problems, which are (1) the requirements of domain expertise and prior knowledge of BTT signals analysis due to severe under-sampling; and (2) that the traditional BTT method can only judge whether there is a defect in the blade but it cannot judge the severity and the location of the defect. Thus, how to overcome the above drawbacks has become a big challenge. Aiming at under-sampled BTT signals, a feature learning method using a convolutional neural network (CNN) is introduced. In this way, some new fault-sensitive features can be adaptively learned from raw under-sampled data and it is therefore no longer necessary to rely on prior knowledge. At the same time, research has found that tip clearance (TC) is also very sensitive to the blade state, especially regarding defect severity and location. A novel analysis method fusing TC and BTT signals is proposed in this paper. The goal of this approach is to integrate tip clearance information with tip timing information for blade fault detection. The method consists of four key steps: First, we extract the TC and BTT signals from raw pulse data; second, TC statistical features and BTT deep learning features will be extracted and fused using the kernel principal component analysis (KPCA) method; then, model training and selection are carried out; and finally, 16 sets of experiments are carried out to validate the feasibility of the proposed method and the classification accuracy achieves 95%, which is far higher than the traditional diagnostic method. Full article
