The objective of this research was to develop a coded language, similarly to Morse or Braille, via a haptic thermal interface. The method is based on the human thermal sense to receive and decode the messages, and is to be used as an alternative or complementary channel for various scenarios in which conventional channels are not applicable or not sufficient (e.g., communication with the handicapped or in noisy/silent environments). For the method to be effective, it must include a large variety of short recognizable cues. Hence, we designed twenty-two temporally short (<3 s) cues, each composed of a sequence of thermal pulses, meaning a combination of warm and/or cool pulses with several levels of intensity. The thermal cues were generated using specially designed equipment in a laboratory environment and displayed in random order to eleven independent participants. The participants identified all 22 cues with 95% accuracy, and 16 of them with 98.3% accuracy. These results reflect extraordinary reliability, indicating that this method can be used to create an effective innovative capability. It has many potential implications and is applicable immediately in the development of a new communication capability, either as a single-modality thermal interface, or combined with tactile sensing to form a full haptic multisensory interface. This report presents the testing and evaluating process of the proposed set of thermal cues and lays out directions for possible implementation and further investigations. Full article

In this paper, we propose a novel tactile display that can present vibration patterns and thermal stimuli simultaneously. The vibration actuator employs a shape memory alloy (SMA) wire to generate micro-vibration with a frequency control of up to 300 Hz. The micro-vibration is conducted to a tactile pin for amplifying the vibration, to be sufficiently recognized by a user. A thermal stimulation unit, on the other hand, consists of four Peltier elements with heatsinks for heat radiation. Four vibration actuators and a thermal unit are arranged in a flat plane with a size of 20 mm × 20 mm, on which a user places the tip of an index finger to feel the presented vibratory stimuli under different temperature conditions. We conducted an experiment by employing nine subjects to evaluate the performance of the proposed tactile display and also to investigate the effects of temperature on recognizing tactile sensation. The results demonstrated that the proposed device was feasible for the quantitative diagnosis of tactile sensation. In addition, we verified that the sensitivity of tactile sensation decreased with colder stimuli. Full article

Despite significant progress in modern medicine and pharmacology, damage to the nervous system with various etiologies still poses a challenge to doctors and scientists. Injuries lead to neuroimmunological changes in the central nervous system (CNS), which may result in both secondary damage and the development of tactile and thermal hypersensitivity. In our review, based on the analysis of many experimental and clinical studies, we indicate that the mechanisms occurring both at the level of the brain after direct damage and at the level of the spinal cord after peripheral nerve damage have a common immunological basis. This suggests that there are opportunities for similar pharmacological therapeutic interventions in the damage of various etiologies. Experimental data indicate that after CNS/PNS damage, the levels of 16 among the 28 CC-family chemokines, i.e., CCL1, CCL2, CCL3, CCL4, CCL5, CCL6, CCL7, CCL8, CCL9, CCL11, CCL12, CCL17, CCL19, CCL20, CCL21, and CCL22, increase in the brain and/or spinal cord and have strong proinflammatory and/or pronociceptive effects. According to the available literature data, further investigation is still needed for understanding the role of the remaining chemokines, especially six of them which were found in humans but not in mice/rats, i.e., CCL13, CCL14, CCL15, CCL16, CCL18, and CCL23. Over the past several years, the results of studies in which available pharmacological tools were used indicated that blocking individual receptors, e.g., CCR1 (J113863 and BX513), CCR2 (RS504393, CCX872, INCB3344, and AZ889), CCR3 (SB328437), CCR4 (C021 and AZD-2098), and CCR5 (maraviroc, AZD-5672, and TAK-220), has beneficial effects after damage to both the CNS and PNS. Recently, experimental data have proved that blockades exerted by double antagonists CCR1/3 (UCB 35625) and CCR2/5 (cenicriviroc) have very good anti-inflammatory and antinociceptive effects. In addition, both single (J113863, RS504393, SB328437, C021, and maraviroc) and dual (cenicriviroc) chemokine receptor antagonists enhanced the analgesic effect of opioid drugs. This review will display the evidence that a multidirectional strategy based on the modulation of neuronal–glial–immune interactions can significantly improve the health of patients after CNS and PNS damage by changing the activity of chemokines belonging to the CC family. Moreover, in the case of pain, the combined administration of such antagonists with opioid drugs could reduce therapeutic doses and minimize the risk of complications. Full article

The World Health Organization estimates that there were around 10 million deaths due to cancer in 2020, and lung cancer was the most common type of cancer, with over 2.2 million new cases and 1.8 million deaths. While there have been advances in the diagnosis and prediction of lung cancer, there is still a need for new, intelligent methods or diagnostic tools to help medical professionals detect the disease. Since it is currently unable to detect at an early stage, speedy detection and identification are crucial because they can increase a patient’s chances of survival. This article focuses on developing a new tool for diagnosing lung tumors and providing thermal touch feedback using virtual reality visualization and thermal technology. This tool is intended to help identify and locate tumors and measure the size and temperature of the tumor surface. The tool uses data from CT scans to create a virtual reality visualization of the lung tissue and includes a thermal display incorporated into a haptic device. The tool is also tested by touching virtual tumors in a virtual reality application. On the other hand, thermal feedback could be used as a sensory substitute or adjunct for visual or tactile feedback. The experimental results are evaluated with the performance comparison of different algorithms and demonstrate that the proposed thermal model is effective. The results also show that the tool can estimate the characteristics of tumors accurately and that it has the potential to be used in a virtual reality application to “touch” virtual tumors. In other words, the results support the use of the tool for diagnosing lung tumors and providing thermal touch feedback using virtual reality visualization, force, and thermal technology. Full article

Whisker sensors are a class of tactile sensors that have recently attracted attention. Inspired by mammals’ whiskers known as mystacial vibrissae, they have displayed tremendous potential in a variety of applications e.g., robotics, underwater vehicles, minimally invasive surgeries, and leak detection. This paper provides a supplement to the recent tactile sensing techniques’ designs of whiskers that only sense at their base, as well as the materials employed, and manufacturing techniques. The article delves into the technical specifications of these sensors, such as the resolution, measurement range, sensitivity, durability, and recovery time, which determine their performance. The sensors’ sensitivity varies depending on the measured physical quantity; for example, the pressure sensors had an intermediate sensitivity of 58%/Pa and a response time of around 90 ms, whereas the force sensors that function based on piezoelectric effects exhibited good linearity in the measurements with a resolution of 3 µN and sensitivity of 0.1682 mV/µN. Some sensors were used to perform spatial mapping and the identification of the geometry and roughness of objects with a reported resolution of 25 nm. The durability and recovery time showed a wide range of values, with the maximum durability being 10,000 cycles and the shortest recovery time being 5 ms. Furthermore, the paper examines the fabrication of whiskers at the micro- and nanoscales, as well as their contributions to mechanical and thermal behavior. The commonly used manufacturing techniques of 3D printing, PDMS casting, and screen printing were used in addition to several micro and nanofabrication techniques such as photolithography, etching, and chemical vapor deposition. Lastly, the paper discusses the main potential applications of these sensors and potential research gaps in this field. In particular, the operation of whisker sensors under high temperatures or high pressure requires further investigation, as does the design of sensors to explore larger topologies. Full article

Polydimethylsiloxane (PDMS) is one of the most promising elastomers due its remarkable proprieties such as good thermal stability, biocompatibility, corrosion resistance, flexibility, low cost, ease of use, chemically inertia, hyperplastic characteristics, and gas permeability. Thus, it can be used in areas such as microfluidic systems, biomedical devices, electronic components, membranes for filtering and pervaporation, sensors, and coatings. Although pure PDMS has low mechanical properties, such as low modulus of elasticity and strength, it can be improved by mixing the PDMS with other polymers and by adding particles or reinforcements. Fiber-reinforced PDMS has proved to be a good alternative to manufacturing flexible displays, batteries, wearable devices, tactile sensors, and energy harvesting systems. PDMS and particulates are often used in the separation of liquids from wastewater by means of porosity followed by hydrophobicity. Waxes such as beeswax and paraffin have proved to be materials capable of improving properties such as the hydrophobic, corrosion-resistant, thermal, and optical properties of PDMS. Finally, when blended with polymers such as poly (vinyl chloride-co-vinyl acetate), PDMS becomes a highly efficient alternative for membrane separation applications. However, to the best of our knowledge there are few works dedicated to the review and comparison of different PDMS composites. Hence, this review will be focused on PDMS composites, their respective applications, and properties. Generally, the combination of elastomer with fibers, particles, waxes, polymers, and others it will be discussed, with the aim of producing a review that demonstrates the wide applications of this material and how tailored characteristics can be reached for custom applications. Full article

Haptic displays have been developed to provide operators with rich tactile information using simple structures. In this study, a three-axis tactile actuator capable of thermal display was developed to deliver tactile senses more realistically and intuitively. The proposed haptic display uses pneumatic pressure to provide shear and normal tactile pressure through an inflation of the balloons inherent in the device. The device provides a lateral displacement of ±1.5 mm for shear haptic feedback and a vertical inflation of the balloon of up to 3.7 mm for normal haptic feedback. It is designed to deliver thermal feedback to the operator through the attachment of a heater to the finger stage of the device, in addition to mechanical haptic feedback. A custom-designed control module is employed to generate appropriate haptic feedback by computing signals from sensors or control computers. This control module has a manual gain control function to compensate for the force exerted on the device by the user’s fingers. Experimental results showed that it could improve the positional accuracy and linearity of the device and minimize hysteresis phenomena. The temperature of the device could be controlled by a pulse-width modulation signal from room temperature to 90 °C. Psychophysical experiments show that cognitive accuracy is affected by gain, and temperature is not significantly affected. Full article

Visually impaired people can take advantage of multimodal systems in which visual information is communicated through different modes of interaction and types of feedback. Among the possible interaction modes, thermal interaction in the context of assistive devices for visually impaired people lacks research in spite of its potential. In this paper, we propose a temperature-depth mapping algorithm and a thermal display system to convey depth and depth-color of artworks’ features in the context of tactile exploration by visually impaired people. Tests with a total of 18 sighted users and six visually impaired users were performed both during the mapping algorithm design and after developing a tactile temperature prototype artwork model to assess the potentials of thermal interaction for recognizing depth and color-depth in tactile art appreciation. These tests showed both an existing correlation between depth and temperature and that the mapping based on that correlation is appropriate for conveying depth during artwork tactile exploration. Full article

We demonstrate a thermal tactile sensation display that can present various thermal sensations, namely cold/cool/warm/hot feelings, by varying the effective thermal conductivity of the display. Thermal sensation is one of the major tactile sensations and needs to be further investigated for advanced virtual reality/augmented reality (VR/AR) systems. Conventional thermal sensation displays present hot/cold sensations by changing the temperature of the display surface, whereas the proposed display is the first one that controls its effective thermal conductivity. The device contains an air cavity and liquid metal that have low and high thermal conductivity, respectively. When the liquid metal is introduced to fill up the air cavity, the apparent thermal conductivity of the device increases. This difference in the thermal conductivity leads to the users experiencing different thermal tactile sensations. Using this device, the threshold to discriminate the effective thermal conductivity was experimentally deduced for the first time. This thermal tactile display can be a good platform for further study of thermal tactile sensation. Full article

Tactile displays have been extensively studied for several decades. However, owing to their bulkiness and stiffness, it has been difficult to integrate these displays with information devices to enable tactile communication between the devices and their users. This paper proposes a novel sheet-type electrovibration tactile display that consists of poly(3,4-ethylenedioxythiophene) polystyrene sulfonate conductive layers and an insulation layer of polydimethylsiloxane. The tactile display is sufficiently thin and flexible for attaching onto various surfaces. In this study, the tactile display was micro-fabricated and characterized through experiments. The experimental results indicated that the tactile display exhibited good durability under bending and that it could present various tactile sensations depending on the type of voltage waveform. In addition, the effect of using a combination of electrovibration and thermal stimuli was also demonstrated. The sheet-type display was attached onto a Peltier element; the thinness of the structure enabled the display to conform to the element and ensure good heat transfer. In the experiment, subjects were asked to scan the display with their fingertips. The results showed that multiple tactile stimuli were also successfully perceived by the subjects. Full article
