When a planing boat sails at the free surface, the posture changes drastically with time, so the surface piercing propellers usually work in oblique flow. In this paper, numerical simulations are performed to predict the performance of PSP-841B with Unsteady Reynolds Averaged Navier–Stokes (URANS) method coupling with sliding mesh and volume of fluid (VOF) method. The results show that the predicted thrust and torque coefficients of PSP-841B are in good agreement with the experimental data. It proves the present numerical schemes are feasible and validated. These schemes are applied in the simulations of SPP-1 that is installed to a planing craft. In oblique flow, the ventilation volume of SPP-1 increases dramatically, resulting in the postponed transition of vented status that changes from the fully dry to partially wetted; at the low advance ratios, the thrust and torque coefficients are less than that in the horizontal case. As the advance speed increases, the vented mode of SPP-1 varies from full ventilation to partially wet, and the forces and moments get closer to the results in the horizontal flow. In addition, the blockage effect of air cavity to the inflow in oblique flow is more significant than the results in the horizontal case. Full article

Under the condition of large water immersion, surface-piercing propellers are inclined to be heavy loaded. In order to improve the hydrodynamic performance of the surface-piercing propeller, the installation of a vent pipe in front of a propeller disc is more widely used in the propulsion device of high speed planning crafts. Based on computational fluid dynamics (CFD) method, this paper studied the influence of diverse vent pipe diameters on hydrodynamic performance of the surface-piercing propeller under full water immersion conditions. The numerical results show that, with the increase of vent pipe diameters, the thrust and torque of the surface-piercing propeller decrease after ventilation, and the efficiency of the propeller increases rapidly; the low pressure area near the back root of the blade becomes smaller and smaller gradually; and the peak of periodic vibration of thrust and torque can be effectively reduced. The numerical results demonstrate that the installation of artificial vent pipe effectively improves the hydrodynamic performance of surface piercing propeller in the field of high speed crafts, and the increase of artificial vent pipe diameter plays an active role in the propulsion efficiency of the surface-piercing propeller. Full article

A simulation model for a prismatic hard-chine planing hull watercraft (V-shaped keel with constant deadrise) with propulsion based on a 3-phase induction motor connected directly to surface-piercing propeller (SPP) and outfitted with a motor rotational speed controller was investigated, tested, and tuned. The modularity of the model developed enables straightforward substitution of diverse and more refined modules, or even attachment of additional ones to obtain greater level of detail or simulate more complicated processes. Industry trends do suggest an increasing interest in all-electric ship development as well as the use of surface-piercing propellers for small or medium-size craft. All-electric drive plants offer distinct advantages due to their flexibility in arrangements, ability to eliminate reduction gears in many cases, low maintenance requirements and wide range of available sizes as well superb load acceptance and dynamic matching to changing operational conditions. Employing electric drives onboard small craft with planing-hulls that achieve significantly higher velocities where arrangements and maneuverability are of critical design issues is a theme that has received increased attention by designers in recent years. Refined speed regulation and tracking compounded by the feature to produce fairly constant torque across a broad speed (rpm) range enables using of unconventional thrusters such as surface-piercing propellers to small craft. By investigating towing tank test data series for a surface-piercing propeller, development of a numerical simulation tool for unconventional thrusters was demonstrated. The surface-piercing propeller simulation model, as an artificial neural network (ANN), was coupled with a 3-phase induction motor as prime mover as well as dynamic propulsion shaft model and proportional-integral-differential (PID) controller. The various sub-models were finally integrated with a sub-model implementing Savitsky’s propulsion resistance method and calculation of equilibrium trim for planing hull modeling. Simulations were conducted using full-scale real-world conditions for a high-speed small craft developed for leisure and sporting activities, rapid close-range transit, reconnaissance and surveying etc. The planing-hull watercraft considered is amenable to minor hull modifications in order to house a 50 kW electric motor and a four bladed surface-piercing propeller. Simulations performed allowed a full assessment of model functionality as well as level of detail. Full article

When operated under large water immersion, surface piercing propellers are prone to be in heavy load conditions. To improve the hydrodynamic performance of the surface piercing propellers, engineers usually artificially ventilate the blades by equipping a vent pipe in front of the propeller disc. In this paper, the influence of artificial ventilation on the hydrodynamic performance of surface piercing propellers under full immersion conditions was investigated using the Computational Fluid Dynamics (CFD) method. The numerical results suggest that the effect of artificial ventilation on the pressure distribution on the blades decreases along the radial direction. And at low advancing speed, the thrust, torque as well as the efficiency of the propeller are smaller than those without ventilation. However, with the increase of the advancing speed, the efficiency of the propeller rapidly increases and can be greater than the without-ventilation case. The numerical results demonstrates the effectiveness of the artificial ventilation approach for improving the hydrodynamic performance of the surface piercing propellers for high speed planning crafts. Full article
