Monitoring large-gradient surface displacement caused by underground mining remains a significant challenge for conventional Synthetic Aperture Radar (SAR)-based techniques. This study introduces optical flow methods to monitor large-gradient displacement in mining areas and conducts a comprehensive comparison with Small Baseline Subset Interferometric SAR (SBAS-InSAR) and Pixel Offset Tracking (POT) methods. Using 12 high-resolution TerraSAR-X (TSX) SAR images over the Daliuta mining area in Yulin, China, we evaluate the performance of each method in terms of sensitivity to displacement gradients, computational efficiency, and monitoring accuracy. Results indicate that SBAS-InSAR is only capable of detecting displacement at the decimeter level in the Dalinta mining area and is unable to monitor rapid, large-gradient displacement exceeding the meter scale. While POT can detect meter-scale displacements, it suffers from low efficiency and low precision. In contrast, the proposed optical flow method (OFM) achieves sub-pixel accuracy with root mean square errors of 0.17 m (compared to 0.26 m for POT) when validated against Global Navigation Satellite System (GNSS) data while improving computational efficiency by nearly 30 times compared to POT. Furthermore, based on the optical flow results, mining parameters and three-dimensional (3D) displacement fields were successfully inverted, revealing maximum vertical subsidence exceeding 4.4 m and horizontal displacement over 1.5 m. These findings demonstrate that the OFM is a reliable and efficient tool for large-gradient displacement monitoring in mining areas, offering valuable support for hazard assessment and mining management. Full article

Enhancing indoor environmental quality while reducing building energy consumption represents a critical challenge for sustainable building design, particularly in hot arid climates where cooling loads dominate energy use. Despite extensive research on green wall systems (GWSs), robust quantitative data on their combined impact on air quality and thermal performance in real-world office environments remains limited. This research quantified the synergistic effects of an active indoor green wall system on key indoor air quality indicators and cooling energy consumption in a contemporary office environment. A comparative field study was conducted over 12 months in two identical office rooms in Dhahran, Saudi Arabia, with one room serving as a control while the other was retrofitted with a modular hydroponic green wall system. High-resolution sensors continuously monitored indoor CO₂, volatile organic compounds via photoionization detection (VOC_PID; isobutylene-equivalent), and PM2.5 concentrations, alongside dedicated sub-metering of cooling energy consumption. The green wall system achieved statistically significant improvements across all parameters: 14.1% reduction in CO₂ concentrations during occupied hours, 28.1% reduction in volatile organic compounds, 20.9% reduction in PM2.5, and 13.5% reduction in cooling energy consumption (574.5 kWh annually). Economic analysis indicated financial viability (2.0-year payback; benefit–cost ratio 3.0; 15-year net present value SAR 31,865). Productivity-related benefits were valued from published relationships rather than measured in this study; base-case viability remained strictly positive in energy-only and conservative sensitivity scenarios. Strong correlations were established between evapotranspiration rates and cooling benefits (r = 0.734), with peak performance during summer months reaching 17.1% energy savings. Active indoor GWSs effectively function as multifunctional strategies, delivering simultaneous air quality improvements and measurable cooling energy reductions through evapotranspiration-mediated mechanisms, supporting their integration into sustainable building design practices. Full article

The observation of small to medium inland water targets with nadir radar altimeters is currently limited by the along-track resolution of UnFocused SAR (UFSAR) altimetry, which is approximately 300 $\mathrm{m}$ for Delay-Doppler processors. In this study, we analyze the benefits of the sub-meter along-track resolution provided by Fully Focused SAR (FFSAR) altimetry applied to Sentinel-6 Michael Freilich data over a collection of small to medium targets in the Ebre Basin, Spain. The obtained water level estimations over a 2-year period are compared to in situ data to evaluate the long-term accuracy of the algorithm. The proposed FFSAR altimetry methodology achieves an average MAD precision of roughly 4 $\mathrm{c}$$\mathrm{m}$, and allows for a full operational implementation as it can be processed in a totally unsupervised manner. The precision improvement with respect to Delay-Doppler products over the same targets is essentially attributed to the FFSAR capabilities to better filter out waveforms contaminated by off-nadir scatterers. Moreover, we evaluate the application of extended water masks, which exploit nadir–altimeter measurements where water is at nadir or up to 250 $\mathrm{m}$ across-track from nadir to increase the number of acquisitions while maintaining the same level of accuracy, increasing by an average of 48% the number of valid measurements per pass, while maintaining the same level of accuracy as nadir measurements over water. We thus demonstrate the potential of FFSAR altimetry to monitor the water level of small to medium inland water targets. Full article

In the field of target detection, a prominent area is represented by ship detection in SAR imagery based on deep learning, particularly for fine-grained ship detection, with dataset quality as a crucial factor influencing detection accuracy. Datasets constructed with commonly used slice-based annotation methods suffer from a lack of scalability and low efficiency in repeated editing and reuse. Existing SAR ship datasets mostly consist of medium to low resolution imagery, leading to coarse ship categories and limited background scenarios. We developed the “annotate entire image, then slice” workflow (AEISW) and constructed a sub-meter SAR fine-grained ship detection dataset (SDFSD) by using 846 sub-meter SAR images that include 96,921 ship instances of 15 ship types across 35,787 slices. The data cover major ports and shipping routes globally, with varied and complex backgrounds, offering diverse annotation information. Several State-of-the-Art rotational detection models were used to evaluate the dataset, providing a baseline for ship detection and fine-grained ship detection. The SDFSD is a high spatial resolution ship detection dataset that could drive advancements in research on ship detection and fine-grained detection in SAR imagery. Full article

South China is dominated by mountainous agriculture and croplands that are at risk of flood disasters, posing a great threat to food security. Synthetic aperture radar (SAR) has the advantage of being all-weather, with the ability to penetrate clouds and monitor cropland inundation information. However, SAR data may be interfered with by noise, i.e., radar shadows and permanent water bodies. Existing cropland data derived from open-access landcover data are not accurate enough to mask out these noises mainly due to insufficient spatial resolution. This study proposed a method that extracted cropland inundation with a high spatial resolution cropland mask. First, the Proportional–Integral–Derivative Network (PIDNet) was applied to the sub-meter-level imagery to identify cropland areas. Then, Sentinel-1 dual-polarized water index (SDWI) and change detection (CD) were used to identify flood area from open water bodies. A case study was conducted in Fujian province, China, which endured several heavy rainfalls in summer 2022. The result of the Intersection over Union (IoU) of the extracted cropland data reached 89.38%, and the F1-score of cropland inundation achieved 82.35%. The proposed method provides support for agricultural disaster assessment and disaster emergency monitoring. Full article

Synthetic aperture radar (SAR) provides an all-weather and all-time imaging platform, which is more reliable than electro-optical (EO) remote sensing imagery under extreme weather/lighting conditions. While many large-scale EO-based remote sensing datasets have been released for computer vision tasks, there are few publicly available SAR image datasets due to the high costs associated with acquisition and labeling. Recent works have applied deep learning methods for image translation between SAR and EO. However, the effectiveness of those techniques on high-resolution images has been hindered by a common limitation. Non-linear geometric distortions, induced by different imaging principles of optical and radar sensors, have caused insufficient pixel-wise correspondence between an EO-SAR patch pair. Such a phenomenon is not prominent in low-resolution EO-SAR datasets, e.g., SEN1-2, one of the most frequently used datasets, and thus has been seldom discussed. To address this issue, a new dataset SN6-SAROPT with sub-meter resolution is introduced, and a novel image translation algorithm designed to tackle geometric distortions adaptively is proposed in this paper. Extensive experiments have been conducted to evaluate the proposed algorithm, and the results have validated its superiority over other methods for both SAR to EO (S2E) and EO to SAR (E2S) tasks, especially for urban areas in high-resolution images. Full article

Persistent scatterers interferometric Synthetic Aperture Radar (PS-InSAR) is capable of precise topography measurement up to sub-meter scale and monitoring subtle deformation up to mm/year scale for all the radar image pixels with stable radiometric characteristics. As a representative PS-InSAR method, the Stanford Method for Persistent Scatterers (StaMPS) is widely used due to its high density of PS points for both rural and urban areas. However, when it comes to layover regions, which usually happen in urban areas, the StaMPS is limited locally. Moreover, the measurement points are greatly reduced due to the removal of adjacent PS pixels. In this paper, an improved StaMPS method, called IStaMPS, is proposed. The PS pixels are selected with high density by the improved PS selection strategy. Moreover, the topography information not provided in StaMPS can be accurately measured in IStaMPS. Based on the data acquired by TerraSAR-X/TanDEM-X over the Terminal 3 E (T3 E) site of Beijing Capital International Airport and the Chaobai River of Beijing Shunyi District, a comparison between StaMPS-retrieved results and IStaMPS-retrieved ones was performed, which demonstrated that the density of PS points detected by IStaMPS is increased by about 1.8 and 1.6 times for these two areas respectively. Through comparisons of local statistical results of topography estimation and mean deformation rate, the improvement granted by the proposed IStaMPS was demonstrated for both urban areas with complex buildings or man-made targets and non-urban areas with natural targets. In terms of the spatiotemporal deformation variation, the northwest region of T3 E experienced an exceptional uplift during the period from June 2012 to August 2015, and the maximum uplift rate is approximately 4.2 mm per year. Full article

Persistent scatterer interferometry (PSI) has the ability to acquire submeter-scale digital elevation model (DEM) and millimeter-scale deformation. A limitation to the application of PSI is that only single persistent scatterers (SPSs) are detected, and pixels with multiple dominant scatterers from different sources are discarded in PSI processing. Synthetic aperture radar (SAR) tomography is a promising technique capable of resolving layovers. In this paper, new approaches based on a novel two-tier network aimed at robust and efficient detection of persistent scatterers (PSs) are presented. The calibration of atmospheric phase screen (APS) and the detection of PSs can be jointly implemented in the novel two-tier network. A residue-to-signal ratio (RSR) estimator is proposed to evaluate whether the APS is effectively calibrated and to select reliable PSs with accurate estimation. In the first-tier network, a Delaunay triangulation network is constructed for APS calibration and SPS detection. RSR thresholding is used to adjust the first-tier network by discarding arcs and SPS candidates (SPSCs) with inaccurate estimation, yielding more than one main network in the first-tier network. After network adjustment, we attempt to establish reliable SPS arcs to connect the main isolated networks, and the expanded largest connected network is then formed with more manual structure information subtracted. Furthermore, rather than the weighted least square (WLS) estimator, a network decomposition WLS (ND-WLS) estimator is proposed to accelerate the retrieval of absolute parameters from the expanded largest connected network, which is quite useful for large network inversion. In the second-tier network, the remaining SPSs and all the double PSs (DPSs) are detected and estimated with reference to the expanded largest connected network. Compared with traditional two-tier network-based methods, more PSs can be robustly and efficiently detected by the proposed new approaches. Experiments on interferometric high resolution TerraSAR-X SAR images are given to demonstrate the merits of the new approaches. Full article

In permafrost areas, seasonal freeze-thaw cycles result in upward and downward movements of the ground. For some permafrost areas, long-term downward movements were reported during the last decade. We measured seasonal and multi-year ground movements in a yedoma region of the Lena River Delta, Siberia, in 2013–2017, using reference rods installed deep in the permafrost. The seasonal subsidence was 1.7 ± 1.5 cm in the cold summer of 2013 and 4.8 ± 2 cm in the warm summer of 2014. Furthermore, we measured a pronounced multi-year net subsidence of 9.3 ± 5.7 cm from spring 2013 to the end of summer 2017. Importantly, we observed a high spatial variability of subsidence of up to 6 cm across a sub-meter horizontal scale. In summer 2013, we accompanied our field measurements with Differential Synthetic Aperture Radar Interferometry (DInSAR) on repeat-pass TerraSAR-X (TSX) data from the summer of 2013 to detect summer thaw subsidence over the same study area. Interferometry was strongly affected by a fast phase coherence loss, atmospheric artifacts, and possibly the choice of reference point. A cumulative ground movement map, built from a continuous interferogram stack, did not reveal a subsidence on the upland but showed a distinct subsidence of up to 2 cm in most of the thermokarst basins. There, the spatial pattern of DInSAR-measured subsidence corresponded well with relative surface wetness identified with the near infra-red band of a high-resolution optical image. Our study suggests that (i) although X-band SAR has serious limitations for ground movement monitoring in permafrost landscapes, it can provide valuable information for specific environments like thermokarst basins, and (ii) due to the high sub-pixel spatial variability of ground movements, a validation scheme needs to be developed and implemented for future DInSAR studies in permafrost environments. Full article

Low-rise gable-roof buildings are a typical building type in shantytowns and rural areas of China. They exhibit fractured and complex features in synthetic aperture radar (SAR) images with submeter resolution. To automatically detect these buildings with their whole and accurate outlines in a single very high resolution (VHR) SAR image for mapping and monitoring with high accuracy, their dominant features, i.e., two adjacent parallelogram-like roof patches, are radiometrically and geometrically analyzed. Then, a method based on multilevel segmentation and multi-feature fusion is proposed. As the parallelogram-like patches usually exhibit long strip patterns, the building candidates are first located using long edge extraction. Then, a transition region (TR)-based multilevel segmentation with geometric and radiometric constraints is used to extract more accurate edge and roof patch features. Finally, individual buildings are identified based on the primitive combination and the local contrast. The effectiveness of the proposed approach is demonstrated by processing a complex 0.1 m resolution Chinese airborne SAR scene and a TerraSAR-X staring spotlight SAR scene with 0.23 m resolution in azimuth and 1.02 m resolution in range. Building roofs are extracted accurately and a detection rate of ~86% is achieved on a complex SAR scene. Full article

Compared with optical sensors, Synthetic Aperture Radar (SAR) can provide important damage information due to its ability to map areas affected by earthquakes independently from weather conditions and solar illumination. In 2013, a new TerraSAR-X mode named staring spotlight (ST), whose azimuth resolution was improved to 0.24 m, was introduced for various applications. This data source made it possible to extract detailed information from individual buildings. In this paper, we present a new concept for individual building damage assessment using a post-event sub-meter very high resolution (VHR) SAR image and a building footprint map. With the building footprint map, the original footprints of buildings can be located in the SAR image. Based on the building imaging analysis of a building in the SAR image, the features in the building footprint can be extracted to identify standing and collapsed buildings. Three machine learning classifiers, including random forest (RF), support vector machine (SVM) and K-nearest neighbor (K-NN), are used in the experiments. The results show that the proposed method can obtain good overall accuracy, which is above 80% with the three classifiers. The efficiency of the proposed method is demonstrated based on samples of buildings using descending and ascending sub-meter VHR ST images, which were all acquired from the same area in old Beichuan County, China. Full article
