This article presents the results of research on the impact of changing the cross-section of an atomizer’s flow channel, which is caused by changing the flow geometry of the passive part of the needle on the drop diameter distribution of the fuel spray. A three-hole type H1LMK, 148/1 atomizer with hole diameters, d_N, equal to 0.34 mm, is analyzed. A nozzle with a standard (i.e., unmodified) needle and three nozzles using needles with a modified profile in the flow part of the needle, marked by the code signatures 1L, 2L, and 3L, are tested. An increasing level of fuel turbulence characterizes the needles during the flow along their flow part due to the use of one (1L), two (2L), and three (3L) de Laval toroidal nozzles, respectively, obtained by mechanically shaping the outer surface of the flow part of the spray needle. The spray produced is tested using the Malvern Spraytec STP 500 device cooperating with the dedicated Malvern version 4.0. During the tests, measurements and an analysis of the spray droplet size distribution over the entire injection duration, equal to 7 ± 2 ms, are made for each nozzle. The experiment makes it possible to determine the effect of the nozzle needles’ profiles on the time distribution of the actual droplet diameters; the time distribution of the Sauter mean droplet diameters, D_[3,2]; the percentile shares of the droplet diameters D_v (10), D_v (50), and D_v (90); the distribution span during the development of the spray stream; and the time distribution of the shares of the droplets with diameters belonging to selected diameter classes D_[x1−x2] in the spray. The results of the measurements of the drop diameter distribution indicate that using atomizers with a modification to the flow channel allows for an increase in the share of droplets with smaller diameters compared to the standard atomizer. Full article

The Grad–Shafranov plasma equilibrium equation was originally solved analytically in toroidal geometry, which fitted the geometric shape of the first Tokamaks. The poloidal surface of the Tokamak has evolved over the years from a circular to a D-shaped ellipse. The natural geometry that describes such a shape is the prolate elliptical one, i.e., the cap-cyclide coordinate system. When written in this geometry, the Grad–Shafranov equation can be solved in terms of the general Heun function. In this paper, we obtain the complete analytical solution of the Grad–Shafranov equation in terms of the general Heun functions and compare the result with the limiting case of the standard toroidal geometry written in terms of the Fock functions. Full article

We present some solutions of the three-dimensional Laplace equation in terms of linear combinations of generalized hyperogeometric functions in prolate elliptic geometry, which simulates the current tokamak shapes. Such solutions are valid for particular parameter values. The derived solutions are compared with the solutions obtained in the standard toroidal geometry. Full article
