Search Results (3)

Search Parameters:
Keywords = smart gasket

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
10 pages, 4226 KiB
Article
Electrical Resistance Prediction for Functionalized Multi-Walled Carbon Nanotubes/Epoxy Resin Composite Gasket under Thermal Creep Conditions
by Wenlong Wang, Xia Yue, He Huang, Chao Wang, Diwei Mo, Yuyan Wu, Qingchun Xu, Chao Zhou, Houyao Zhu and Chunliang Zhang
Materials 2019, 12(17), 2704; https://doi.org/10.3390/ma12172704 - 23 Aug 2019
Cited by 5 | Viewed by 2622
Abstract
Carbon nanotube-based conductive polymer composites (CPC) showed great potentials for self-sensing and in situ structural health monitoring systems. Prediction of the long-term performance for such materials would be a meaningful topic for engineering design. In this work, the changing behavior of the long-term [...] Read more.
Carbon nanotube-based conductive polymer composites (CPC) showed great potentials for self-sensing and in situ structural health monitoring systems. Prediction of the long-term performance for such materials would be a meaningful topic for engineering design. In this work, the changing behavior of the long-term resistance of a multi-walled carbon nanotubes/epoxy resin composite gasket was studied under different temperature and loading conditions. Glass transition strongly influenced the resistance behavior of the composite during the thermal creep process. Similar to classical Kelvin–Voigt creep model, a model considering both the destruction and recovery processes of the conductive network inside the CPC was established. The long-term resistance variation can be predicted based on the model, and the results provided here may serve as a useful guide for further design of smart engineering structural health monitoring systems. Full article
Show Figures

Figure 1

4 pages, 762 KiB
Proceeding Paper
Intelligent Machine Parts: Challenges in the Condition Monitoring of Elastomer Gaskets with Integrated Sensors
by Daniel Gräbner, Robert Zahn, Ulrich Giese and Walter Lang
Proceedings 2017, 1(4), 632; https://doi.org/10.3390/proceedings1040632 - 18 Aug 2017
Cited by 1 | Viewed by 2446
Abstract
Smart factories are supposed to provide an overview on the current status of installed production machines. In order to collect data, intelligent machine parts have to be designed. We present a method to monitor the condition of elastomer gaskets, which are crucial parts [...] Read more.
Smart factories are supposed to provide an overview on the current status of installed production machines. In order to collect data, intelligent machine parts have to be designed. We present a method to monitor the condition of elastomer gaskets, which are crucial parts of many machines. The monitoring is done by a strain gauge, which is integrated into the gasket. This paper describes the overall concept of the monitoring system as well as the challenges by varying temperature and pressure of the sealed fluid on the sensors signal. Full article
(This article belongs to the Proceedings of Proceedings of Eurosensors 2017, Paris, France, 3–6 September 2017)
Show Figures

Figure 1

12 pages, 469 KiB
Article
Embedded Strain Gauges for Condition Monitoring of Silicone Gaskets
by Timo Schotzko and Walter Lang
Sensors 2014, 14(7), 12387-12398; https://doi.org/10.3390/s140712387 - 10 Jul 2014
Cited by 24 | Viewed by 9868
Abstract
A miniaturized strain gauge with a thickness of 5 µm is molded into a silicone O-ring. This is a first step toward embedding sensors in gaskets for structural health monitoring. The signal of the integrated sensor exhibits a linear correlation with the contact [...] Read more.
A miniaturized strain gauge with a thickness of 5 µm is molded into a silicone O-ring. This is a first step toward embedding sensors in gaskets for structural health monitoring. The signal of the integrated sensor exhibits a linear correlation with the contact pressure of the O-ring. This affords the opportunity to monitor the gasket condition during installation. Thus, damages caused by faulty assembly can be detected instantly, and early failures, with their associated consequences, can be prevented. Through the embedded strain gauge, the contact pressure applied to the gasket can be directly measured. Excessive pressure and incorrect positioning of the gasket can cause structural damage to the material of the gasket, which can lead to an early outage. A platinum strain gauge is fabricated on a thin polyimide layer and is contacted through gold connections. The measured resistance pressure response exhibits hysteresis for the first few strain cycles, followed by a linear behavior. The short-term impact of the embedded sensor on the stability of the gasket is investigated. Pull-tests with O-rings and test specimens have indicated that the integration of the miniaturized sensors has no negative impact on the stability in the short term. Full article
(This article belongs to the Section Physical Sensors)
Show Figures
