Coordinate registration (CR) is the key technology for improving the target positioning accuracy of sky-wave over-the-horizon radar (OTHR). The CR parameters are derived by matching the sea–land clutter classification (SLCC) results with prior geographic information. However, the SLCC results often contain mixed clutter, leading to discrepancies between land and island contours and prior geographic information, which makes it challenging to calculate accurate CR parameters for OTHR. To address these challenges, we transform the sea–land clutter data from Euclidean space into graph data in non-Euclidean space, and the CR parameters are obtained by calculating the similarity between graph pairs. And then, we propose a similarity calculation via a graph neural network (SC-GNN) method for calculating the similarity between graph pairs, which involves subgraph-level interactions and node-level comparisons. By partitioning the graph into subgraphs, SC-GNN effectively captures the local features within the SLCC results, enhancing the model’s flexibility and improving its performance. For validation, we construct three datasets: an original sea–land clutter dataset, a sea–land clutter cluster dataset, and a sea–land clutter registration dataset, with the samples drawn from various seasons, times, and detection areas. Compared with the existing graph matching methods, the proposed SC-GNN achieves a Spearman’s rank correlation coefficient of at least 0.800, a Kendall’s rank correlation coefficient of at least 0.639, a p@10 of at least 0.706, and a p@20 of at least 0.845. Full article

In high-frequency (HF) radar systems, transient interference is a common phenomenon that dramatically degrades the performance of target detection and remote sensing. Up until now, various suppression algorithms of transient interference have been proposed. They mainly concentrate on the skywave over-the-horizon radar on the basis of the assumption that the interference is sparse in a coherent processing interval (CPI). However, HF surface wave radar (HFSWR) often faces more complex transient interference due to various extreme types of weather, such as thunderstorm and typhoon, etc. The above algorithms usually suffer dramatic performance loss when transient interference contaminates the enormously continuous parts of a CPI. Especially for the compact HFSWR, which suffers from severe beam broadening and fewer array degrees of freedom. In order to solve the above problem, this study developed a two-dimensional interference suppression algorithm based on space-time cascaded processing. First, according to the spatial correlation of the compact array, the statistical samples of the main-lobe transient interference are estimated using a rotating spatial beam method. Next, an adaptive selection strategy is developed to obtain the optimal secondary samples based on information geometry distance. Finally, based on a quadratic constraint approximation, a precise estimation method of the optimal weight is developed when the interference covariance matrix is singular. The experimental results of simulation and measured data demonstrate that the proposed approach provides far superior suppression performance. Full article

After exploratory research in the 1950s, HF skywave ‘over-the-horizon’ radars (OTHR) were developed as operating systems in the 1960s for defence missions, notably the long-range detection of ballistic missiles, aircraft, and ships. The potential for a variety of non-defence applications soon became apparent, but the size, cost, siting requirements, and tasking priority hindered the implementation of these societal roles. A sister technology—HF surface wave radar (HFSWR)—evolved during the same period but, in this more compact form, the non-defence applications dominated, with hundreds of such radars presently deployed around the world, used primarily for ocean current mapping and wave measurements. In this paper, we examine the ocean monitoring capabilities of the latest generation of HF skywave radars, some shared with HFSWR, some unique to the skywave modality, and explore some new possibilities, along with selected technical details for their implementation. We apply state-of-the-art modelling and experimental data to illustrate the kinds of information that can be generated and exploited for civil, commercial, and scientific purposes. The examples treated confirm the relevance and value of this information to such diverse activities as shipping, fishing, offshore resource extraction, agriculture, communications, weather forecasting, and climate change studies. Full article

For skywave over-the-horizon radar, beamforming techniques are often used to suppress airspace radio frequency interference because the high-frequency band is shared by many devices. To address the problems that the traditional beamforming method is not capable of recognizing the electromagnetic environment and that its performance is greatly affected by the accuracy of signal feature estimation, a cognitive beamforming method using range-Doppler (RD) map features for skywave radar is proposed. First, the RD map is weighted by a local attention model, and then, texture features are extracted as the inputs to a support vector machine. Finally, the support vector machine is used to predict the optimal diagonal loading factor. Simulation results show that the output signal-to-interference-plus-noise ratio is improved compared with previous methods. The proposed method is suitable for many kinds of common unsatisfactory scenarios, making it beneficial for engineering implementation. Full article

The capability of a skywave over-the-horizon radar (SWR) to achieve the continuous observation of a wide range of ocean dynamics parameters via a single ionospheric reflection has been demonstrated by many scholars. In order to expand the method of SWR detection of ocean dynamics parameters, a simulation model of an SWR sea echo spectrum based on the Barrick sea surface scattering cross-section model (Barrick model) and 3D ray-tracing method, suitable for a narrow-beam, frequency-modulated continuous-wave radar system (FMCW), was established. Based on this model, we simulated ideal and contaminated SWR sea echo spectra, respectively with the 3D electron density data output by the International Reference Ionosphere (IRI) model. Then, we further analyzed the effects of the grazing incidence angle, scattering angle, scattering azimuth angle and fetch length on the sea surface scattering cross-sections, the retrieval precision of the sea surface wind direction, and the root-mean-square (RMS) wave height, using the simulation data calculated by the Barrick model. The results show that these angles and fetch length cause a small expansion and contraction of the scattering cross-section, and have no influence on the retrieval precision of the sea surface wind direction, but will affect the retrieval precision of the RMS wave height; the influence of the grazing incidence angle and scattering angle is ~2.5 times that of the scattering azimuth angle. The ideal SWR sea echo spectrum has small broadening, but the ionosphere phase contamination will cause serious broadening and shifting of the SWR sea echo spectrum, and the higher order nonlinear term has greater contamination. Full article

In the target localization of skywave over-the-horizon radar (OTHR), the error of the ionospheric parameters is one main error source. To reduce the error of ionospheric parameters, a method using both the information of reference sources (e.g., terrain features, ADS-B) in ground coordinates and the corresponding OTHR measurements is proposed to estimate the ionospheric parameters. Describing the ionospheric electron density profile by the quasi-parabolic model, the estimation of the ionospheric parameters is formulated as an inverse problem, and is solved by a Markov chain Monte Carlo method due to the complicated ray path equations. Simulation results show that, comparing with using the a prior value of the ionospheric parameters, using the estimated ionospheric parameters based on four airliners in OTHR coordinate registration process, the ground range RMSE of interested targets is reduced from 2.86 to 1.13 km and the corresponding improvement ratio is up to 60.39%. This illustrates that the proposed method using reference sources is able to significantly improve the accuracy of target localization. Full article

Maritime safety issues have aroused great attention, and it has become a difficult problem to use the sky-wave over-the-horizon radar system to locate foreign targets or perform emergency rescue quickly and timely. In this paper, a distributed multi-point sky-wave over-the-horizon radar system is used to locate marine targets. A positioning algorithm based on the Doppler frequency is proposed, namely, the two-step weighted least squares (2WLS) method. This algorithm first converts the WGS-48 geodetic coordinates of the transceiver station to spatial rectangular coordinates; then, introduces intermediate variables to convert the nonlinear optimization problem into a linear problem. In the 2WLS method, four mobile transmitters and four mobile receivers are set up, and the Doppler frequency is calculated by transmitting and receiving signals at regular intervals; it is proven that the 2WLS algorithm has always maintained a better positioning accuracy than the WLS algorithm as the error continues to increase with a certain ionospheric height measurement error and the Doppler frequency measurement error. This paper provides an effective method for the sky-wave over-the-horizon radar to locate maritime targets. Full article
