Despite numerous studies on nanofluids in microchannel heat sinks (MCHSs), they are not yet commercialized due to long-term stability issues and high maintenance costs. Therefore, this study explores the impact of nanofluids and nanoparticle clustering on single-phase convective heat transfer inside microchannels under laminar conditions. Water and commercially available water-based nanosuspensions, including Al${}_2$O${}_3$-water (30–60 nm), TiO${}_2$-water (5–30 nm), and polystyrene-water (50 nm), are circulated through silicon MCHS having rectangular channels integrated into a closed flow loop. To assess the in situ and real-time nanoparticle clustering during heat transfer experiments, Light Extinction Spectroscopy (LES) is applied as a non-intrusive measurement technique on nanofluids without any fluid sampling. Our findings reveal the appearance of nanofluid discoloration with no measurable increase in heat transfer coefficient. This unexpected change is attributed to the interplay of abrasion, erosion, and corrosion phenomena, likely triggered by the clustering of nanoparticles within the silicon microchannels—a novel insight into the complex dynamics of nanofluid behavior (an increase in the De Brouckere mean diameter from 11 nm to 107.3 nm over a 2.5 h period for TiO${}_2$ nanoparticles). The resulting material loss could not be mitigated by altering the nanoparticle material, which may impede heat transfer enhancement under tested conditions. Full article

The metal microdroplet deposition manufacturing technique has gained extensive attention due to its potential applications in microstructure fabrication. In order to fabricate components such as microchannel heat sinks and microchannel reactors, this paper investigates the interactions and influences between microdroplets and substrates, as well as between microdroplets themselves. The transient phenomena during the fusion of metal microdroplets in contact with the substrate and the formation of inclined columns, as well as the solid–liquid coupling and morphology formation processes during the collision between microdroplets, are analyzed. The influence of microdroplet spacing on the morphology of microchannels during their formation is specifically studied. A three-dimensional finite element numerical model for the deposition of metal microdroplets forming inclined pillars is established based on the volume of fluid (VOF) method. The model treats the protective gas around the microdroplet as an empty zone and the microdroplet as a single-phase fluid. Simulation analysis is conducted to investigate the forming patterns of unsupported microdroplets at different spacing and their impact on the fusion morphology of microchannel components. Building upon this, a series of validation experiments are conducted using a piezoelectric microdroplet generator to produce uniform aluminum alloy microdroplets with a diameter of approximately 600 μm. A method for fabricating metal microchannel structures is obtained, which is expected to be applied in fields such as scattering structures for high-power electronic devices and microreactors in microchemical fields. Full article

Cooling methods for multiple heat sources with high heat flux have rarely been reported, but such situations threaten the stable operation of electronic devices. Therefore, in this paper, the use of two microchannel heat sinks is proposed, with and without grooves, labeled Type A and Type B, respectively. Experimental investigations on the flow boiling of two microchannel heat sinks connected in parallel and in series are carried out under different mass fluxes. In addition, a high-speed camera is used to observe flow patterns in the microchannels. The cold plate wall temperature (T_w), heat transfer coefficient (HTC), and pressure drop (PD) are obtained with the use of two microchannel heat sinks. The flow patterns of the bubbly flow and elongated bubbles in the microchannels are observed. The results of the analysis indicated that the T_w, HTC, and PD of the two microchannel heat sinks connected in parallel were degraded, especially when using the Type A-B parallel connection. Compared to the use of a single heat sink, the maximum decrease in HTC was 9.44 kW/(m²K) for Type A heat sinks connected in parallel, which represents a decrease of 45.95%. The influence of the series connection on the T_w, HTC, and PD of the two heat sinks is obvious. The Type A-A series connection exerted the greatest positive effect on the performance of the two heat sinks, especially in the case of the postposition heat sink. The maximum increase in HTC was 12.77 kW/(m²K) for the postposition Type A heat sink, representing an increase of 72.88%. These results could provide a reference for a two-phase flow-cooling complex for multiple heat sources with high heat flux. Full article

Due to microscale effects, the segmented microchannels or micro pin fin heat sinks emerged as a high thermal management solution. In this context, the present work analyzes the influence of different heights of square micro pin fins with an aligned array and investigates their influence on pressure drop and heat transfer behavior. The HFE-7100 is used as the working fluid, and the pressure drop and surface temperature behavior are analyzed for different mass fluxes and inlet subcooling. The single-phase flow was analyzed numerically using the computational fluid dynamics (CFD) software ANSYS FLUENT^® for comparing the simulation results with the experimental data, showing that the highest micro pin fins configuration provides a more uniform and lowest wall temperature distribution compared to the lowest configuration. There is a good agreement between the experimental results and the numerical analysis, with a mean absolute error of 6% for all the considered parameters. For the two-phase flow condition, experimental tests were performed, and for the highest subcooling, an increase in mass flux causes an enhancement in the heat transfer for low heat flux; by increasing heat flux, there is a gradual predominance of boiling heat transfer over convection as the heat transfer mechanism. The pressure drop drastically increases with the vapor amount flowing into the system, regardless of the pin fin height; the boiling curves for the higher fin height show a much smaller slope and a smaller wall superheat than the fin with the smallest height, and consequently, a high heat transfer performance. A larger region of the heat sink is filled with vapor for lower inlet subcooling temperatures, degrading the heat transfer performance compared to higher inlet subcooling temperatures. Full article

Two-phase flow in non-circular cross-section flow channels such as micro-heat sinks and micro-channel heat exchangers has received extensive attention due to its heat-enhancing properties. In this paper, under the boundary of constant heat flux, an experimental investigation of the heat transfer properties of gas–liquid two-phase flow in horizontal channels with cross-sections of 4 × 4 mm and 8 × 3 mm is carried out using air and water as working fluids. The effects of different inlet gas and liquid inlet Reynolds numbers on the wall temperature and Nusselt number are discussed. The results show that the effects of the liquid Reynolds number and the gas phase Reynolds number on the heat transfer coefficient of the square tube and the rectangular tube are different. Under the same gas–liquid Reynolds number, the Nusselt number of the gas–liquid two-phase flow in the square-section tube can be increased by 3.2 times compared with that in the single-phase flow, while the Nusselt number of the gas–liquid two-phase flow in the rectangular tubes can be increased by 1.87 times. The results of this paper provide a reference for the design of microchannel heat exchangers and the establishment of mathematical models for Taylor flow heat transfer in rectangular and square tubes. Full article

Microchannel technology rapidly established itself as a practicable solution to the problem of the removal of extremely concentrated heat generation in present-day cooling fields. By implementing a better design structure, altering the working fluids and flow conditions, using various materials for fabrication, etc., it is possible to increase the heat transfer performance of microchannels. Two parameters that affect how well a microchannel transfers heat were only recently coupled, and the complicated coupling of the parameter that affects how well a microchannel sink transfers heat is still not well understood. The newest industrial developments, such as micro-electro-mechanical systems, high performance computing systems, high heat density generating future devices, such as 5G/6G devices, fuel cell power plants, etc., all present thermal challenges that require the use of microchannel technology. In this paper, single-phase flow in microchannels of various sizes, with or without microinserts, is described in terms of its thermal-fluid flow properties, including fluid flow characteristics and heat transfer characteristics considering the compound effects of variations of channel size and addition of microinserts. The trials were carried out using distilled water that had thermo-physical characteristics that varied with temperature. A microchannel with microinserts was developed for managing the high heat generation density equipment. The fluid flow and heat transfer characteristics are explored and analyzed for Reynolds numbers ranges from 125 to 4992, for 1 mm channel size, and from 250 to 9985, for 2 mm channel size. The cooling performance criteria are pressure drop characteristics, heat transfer characteristics, and overall performance, whereas the testing parameters were chosen for the variations in channel size and the addition of microinserts. The influence of inserting microinserts on microchannels is discussed. Results suggest that by inserting microinserts, the performance of the heat transfer of microchannels is significantly improved and, also, fluid flow resistance is increased. The criteria of the thermal performance factor are employed to assess the overall performance of the microchannel. Significant intensification of heat transfer is observed with indication that the addition of microinserts to microchannels and reduction in channel sizes exhibited improved overall performance. Full article

With the development of miniaturized and enormous heat density generating novel technologies, the microchannel heat sink is rapidly establishing itself in modern cooling fields. Enhancement of heat transfer performance of microchannels is done by incorporating improved design structure, changing working fluids and flow conditions, using different materials for fabrication, etc. Coupling of two parameters influencing heat transfer performance of microchannels is in a nascent age, and complex coupling of heat transfer influencing parameters of microchannel sinks has not been clearly understood yet. This study provides the thermal-fluid flow features–fluid flow characteristics and heat transfer characteristics- of single-phase flow in microchannel of different sizes with or without microinserts by the use of computational fluid dynamics. The numerical simulation is performed by employing distilled water with thermophysical properties that depends on temperature for the Reynolds number range of 56–2242. The effect of microinserts on characteristics of fluid flow and heat transfer is analyzed. The results of numerical analysis show that heat transfer performance in microchannel with microinserts is enhanced effectively, however resistance in fluid flow is increased simultaneously. The 0.5 mm microchannel with microinserts shows the best performance of heat transfer characteristics with enhancement of 1–9% in the Reynolds number range of 56–2242 with simultaneous maximum increase in pressure drop by 14.5%. It’s overall performance, evaluated by thermal performance factor, is found to be best among all cases of three different channel sizes with and without microinserts. The maximum enhancement of heat transfer is found to be in case of 0.5 mm channel size with microinserts by a factor of 1.09. The maximum pressure drop is increased is found to be by factor of 2.28 in case of 2 mm channel size with microinserts. Full article

For more than 20 years, the use of nanofluids to enhance heat transfer in microchannel heat sinks (MCHSs) has been the subject of a large number of scientific articles. Despite the great potentialities reported in several works, the presence of controversial results and the lack of understanding of heat transfer enhancement mechanisms prevent further advancement in the use of nanofluids as coolants. This article reviews the scientific literature focused on several aspects of nanofluids that have a role in the heat transfer enhancement within the MCHSs: nanofluid stability, thermal conductivity, and particle clustering, as well as the particle–surface interactions, i.e., abrasion, erosion, and corrosion. We also include the most relevant works on the convective heat transfer and MCHSs operated with nanofluids in our review. Full article

In this study, a numerical approach was carried out to analyze the effects of different geometries of microchannel heat sinks on the forced convective heat transfer in single-phase flow. The simulations were performed using the commercially available software COMSOLMultiphysics 5.6^® (Burlington, MA, USA) and its results were compared with those obtained from experimental tests performed in microchannel heat sinks of polydimethylsiloxane (PDMS). Distilled water was used as the working fluid under the laminar fluid flow regime, with a maximum Reynolds number of 293. Three sets of geometries were investigated: rectangular, triangular and circular. The different configurations were characterized based on the flow orientation, type of collector and number of parallel channels. The main results show that the rectangular shaped collector was the one that led to a greater uniformity in the distribution of the heat transfer in the microchannels. Similar results were also obtained for the circular shape. For the triangular geometry, however, a disturbance in the jet impingement was observed, leading to the least uniformity. The increase in the number of channels also enhanced the uniformity of the flow distribution and, consequently, improved the heat transfer performance, which must be considered to optimize new microchannel heat sink designs. The achieved optimized design for a heat sink, with microchannels for nanofluid flow and a higher heat dissipation rate, comprised a rectangular collector with eight microchannels and vertical placement of the inlet and outlet. Full article

The temperature fluctuation in a single-phase microchannel heat sink (MCHS) is investigated using the integrated temperature sensors with deionized water as the coolant. Results show that the temperature fluctuation in single phase is not negligible. The causes of the temperature fluctuation are revealed based on both simulation and experiment. It is found that the inlet temperature fluctuation and the gas bubbles separated out from coolant are the main causes. The effect of the inlet temperature fluctuation is global, where the temperatures at different locations change simultaneously. Meanwhile, the gas bubble effect is localized where the temperature changes at different locations are not synchronized. In addition, the relation between temperature fluctuation and temperature gradient is established. The temperature fluctuation increases with the temperature gradient accordingly. Full article

It is necessary to control the temperature of solar cells for enhancing efficiency with increasing concentrations of multiple photovoltaic systems. A heterogeneous two-phase model was established after considering the interacting between temperature, viscosity, the flow of nanofluid, and the motion of nanoparticles in the nanofluid, in order to study the microchannel heat sink (MCHS) using Al₂O₃-water nanofluid as coolant in the photovoltaic system. Numerical simulations were carried out to investigate the thermal performance of MCHS with a series of trapezoidal grooves. The numerical results showed us that, (1) better thermal performance of MCSH using nanofluid can be achieved from a heterogeneous two-phase model than that from single-phase model; (2) The effects of flow field, volume fraction, nanoparticle size on the heat transfer enhancement in MCHS were interpreted by a non-dimensional parameter N_BT (i.e., ratio of Brownian diffusion and thermophoretic diffusion). In addition, the geometrical parameters of MCHS and the physical parameters of the nanofluid were optimized. This can provide a sound foundation for the design of MCHS. Full article
