Search Results (4)

In view of the problems of the complex design, difficult machining, and high manufacturing cost of a traditional nutation reducer, this paper intends to design a nutation reducer and study its meshing performance. First, the meshing pair is designed by the method of internal and external cutting of the shaper cutter, and the method of face gear tooth surface modification is proposed. Second, based on tooth contact analysis (TCA) and loaded tooth contact analysis (LTCA), the contact performance of the meshing pair is studied. Then, the nutation reducer is improved by using the pair instead of the internal bevel gear pair. Finally, examples are presented to test the feasibility of the improved design. The results show that the improved nutation reducer maintains the advantages of a large transmission ratio and high bearing capacity of the traditional nutation reducer and can make use of the advantages of face gears to further improve its transmission performance. This study can lay a foundation for the further application and popularization of nutation reducers. Full article

This paper examines the challenges of machining structural alloy steels for carburizing, with a particular focus on gear manufacturing. TiN_0.85-Ti coatings were applied to cutting tool blades to improve machining quality and tool life. The research, supported by mathematical modeling, demonstrated that these coatings significantly reduce adhesive wear and improve blade life. The Kolmogorov–Arnold Network (KAN) was identified as the most effective model comprehensively describing tool life as a function of cutting speed, coating thickness, and feed rate. The results indicate that gear production efficiency can be significantly increased using TiN_0.85-Ti coatings. Full article

CrAlN and CrAlBN coatings were prepared on the surface of high-speed steel and shaper cutter by physical vapor deposition (PVD) technique using arc ion source. In the process of coating preparation, the adhesive layers were deposited by low bias voltage (−40 V) and the working layers are deposited by high bias voltage (−130 V). The effects of the addition of B element on the microstructure, hardness, elastic modulus and wear resistance of CrAlBN coating were studied. The results show that B element and its compounds exist in amorphous form in the coating, resulting in lattice distortion of the coating, increase of coating hardness to 37.1 GPa, and decrease of elastic modulus to 406.2 GPa. The addition of B element increases the uniformity of the columnar structure distribution and decreases the width of the columnar structure and grain size. The resistance to elastic deformation and plastic deformation of CrAlBN coating is improved, the wear resistance is improved. The performance of CrAlN and CrAlBN coatings on shaper cutter was studied. It was found that the main failure mode of shaper cutters is boundary wear and the wear mechanism of coatings had changed obviously. CrAlBN coating is mainly due to fatigue induced failure, accompanied by some diffusion wear. The addition of B element makes the CrAlBN coating have excellent resistance to oxidative wear, abrasive wear and diffusion wear during cutting. The results show that the addition of B element can improve the microstructure and mechanical properties of CrAlN coating, and the preparation of CrAlBN coating on the surface of the shaper cutter can significantly improve the service life of the coated shaper cutter, which has significance for the development of the shaper cutter industry. Full article

The construction and manufacture of non-circular gears is one of the most difficult issues in machine technology. Due to the limited technological capabilities of traditional machines and tools, past manufacturing methods were unable to calculate the assumed shape of the tooth line and its profile. Modern manufacturing methods using computer numerical control allow for the generation of non-circular gears with free-form tooth profiles and curvilinear teeth in their lengthwise direction. These methods are also used to manufacture internal gears. This article provides a review of the methods of machining non-circular gears and presents the results of the research on the Fellows method using a shaper cutter, as well as the wire electrical discharge machining method. Full article
