As the core technology for mechanized installation of tunnel folding steel arch frames, snap-fit connection optimization proves critical in enhancing the load-bearing efficiency of support systems and addressing surrounding rock deformation and instability caused by excavation-induced stress redistribution. Addressing the theoretical gaps in existing research regarding snap-fit selection mechanisms and quantitative evaluation criteria, this study adopts a combined approach of numerical simulation and field monitoring verification based on the excavation compensation concept to systematically investigate the load-bearing characteristics of folding steel arch frames with different snap-fit configurations. Key findings include (1) identification of 20 mm as the optimal joint diameter, where the vertical displacements of Type A and B snap-fit connections reached their minimum values of 43.1 mm and 39.2 mm, respectively; (2) demonstration of significant geometric configuration effects on principal stress distribution, with Type B connections exhibiting 4.5% lower maximum principal stress compared to Type A, effectively mitigating stress concentration; and (3) field monitoring data verification, revealing that Type B connections achieved 15.8% lower stress values than Type A at critical crown sections, satisfying yield strength requirements while demonstrating enhanced resistance to surrounding rock deformation induced by excavation-induced geostress redistribution. These results confirm Type B snap-fit connections as superior structural solutions for folding steel arch frames, thereby facilitating the advancement of mechanized installation technology for tunnel steel arch frames. Full article

The bearing capacity and yieldable performance of yielding U-shaped steel support are difficult to be fully exerted in roadways under complex conditions, and serious deformation and damage occur frequently. Taking the mining roadways of Tangkou Coal Mine in a kilometer-deep well as the engineering background, this paper summarizes and analyzes the typical failure modes of the on-site yielding U-shaped steel support. By utilizing the independently developed full-scale arch frame test system, the bearing performance tests of arch frames with different sectional methods were carried out. The results show that compared with the three-section U-shaped steel support, the yieldable performance of the four-section support is increased by 21.8%, while the bearing capacity is only decreased by 1.9%. Furthermore, numerical tests on yielding U-shaped steel support under different load patterns and different cross-sectional forms were conducted to clarify the deformation characteristics and internal force distribution laws of U-shaped steel support under complex stress conditions. Finally, a sectional design method for yielding U-shaped steel support and on-site engineering suggestions were put forward. Based on this methodology, it is feasible to optimize the support structure scheme that better matches the engineering geological conditions, thereby fully utilizing the yielding characteristics and load-bearing capacity of the support. This approach effectively prevents premature local failure of the support, extends its service life, and enhances the safety of roadway support engineering while achieving significant economic benefits. Full article

Tied steel box arch bridges are increasingly being used due to their attractive appearance, high load-bearing capacity, and good stress performance. Their construction involves multiple processes and factors. Construction monitoring can ensure that such a bridge remains in its intended stress and linear states during and after construction. This helps to minimize deviations from the design state at every stage of construction. Using the segmental assembly construction technique, this study conducted construction monitoring of the alignment and force at each stage of the reconstruction of bridges using MIDAS Civil software. The construction monitoring analysis indicated that the arch rib and lattice beam were correctly placed, thereby meeting the specified requirements for arch rib closure. Displacement errors between the measured and theoretical values at each stage of construction fell within an allowable range, resulting in overall smooth bridge alignment. The measured stress in the main arch and the lattice beam generally corresponded to the theoretical stress derived from the control section stress of the entire bridge. The deviation between the cable force of the suspender and the tie rod and theoretical value fell within 10%, indicating good stress reserve. The symmetrical monitoring points in the analyzed rigid-frame tied steel box arch bridges exhibited symmetrical displacement, stress, and cable force results under various working conditions. This observation further confirms the effectiveness of construction monitoring using the segmental assembly technique. Full article

To address the problem of the collapse of the roof of the Bailuyuan tunnel during construction, the causes of collapse were analyzed, targeted treatment measures were proposed, and the effects of the treatment measures were evaluated through on-site monitoring and three-dimensional numerical simulations. The results showed that the particular characteristics of loess and the synergy of groundwater were the internal causes of the tunnel’s collapse as well as, to a certain extent, atmospheric precipitation. Therefore, the combination of multiple factors contributed to the tunnel’s collapse. Untimely monitoring and measurement, as well as the low initial support parameters, reflect a lack of human understanding of the collapse. Based on the analysis of the causes of the collapse, comprehensive treatment measures for inside and outside the tunnel are proposed, which are shown to be effective and to be capable of preventing the occurrence of further collapses. After the collapse treatment, the measured maximum settlement of the tunnel vault was 65.1 mm, the maximum horizontal convergence was 25 mm, the maximum surrounding rock pressure was 0.56 MPa, and the maximum stress on the steel arch frame was 54.34 MPa. Compared with the original design plan, the vertical stress, horizontal stress, and shear stress of the surrounding rock obtained from numerical simulation after the collapse treatment were greatly reduced, the reduction rate at the vault reached 50%, and the safety factors of the initial support positions after treatment met the specification requirements. The research results can provide engineering guidance for the design and construction of large-section tunnels crossing deep-loess strata, and they are of important engineering significance. Full article

With the intensive development of China’s high-speed railway network and intercity railway network, the construction of the large-diameter shield tunnels and cross-passages is gradually increasing. The construction of large diameter shield tunnels and the excavation of cross-passages puts forward higher requirements for the stability and safety of segment structure. Based on the Wangjing tunnel project, this paper studies the segment displacement and mechanical response of the shield tunnel with a diameter of 10.5 m in the process of shield construction and cross-passage construction. The results show that during the construction of large diameter shield tunnels, the vault and invert produce inward displacement, the invert uplift usually is more severe than the vault settlement, and the arch waist on both sides produces outward displacement. Near the segment K (capping block), the mechanical performance of the segment is close to that of the hinge or chain rod, which can only effectively transmit the axial force but cannot resist the bending moment and shear force. During construction of the cross-passage, the maximum deformation and stress of shield tunnel segment are symmetrically located at the interface of the main tunnel and cross-passage. The upper and lower edges of the segment at the interface tend to change from compression to tension. At the same time, the steel bars on the inside and outside of the segment vault and the arch waist change from compressive stress to tensile stress, which can easily lead to segment damage, so these positions can be reinforced by erecting section steel frames before construction. Full article

Heat-treated high-strength rebar has many advantages, such as high strength, superior ductility, high yield ratio, excellent welding and cold bending performance, which can effectively reduce the amount of rebar and improve the project quality. Although heat-treated high-strength rebar has been successfully applied in many fields of civil engineering, its application in tunnel engineering is just getting started. In this study, the on-site test of axisymmetric heat-treated high-strength lattice girders in rail tunnels and road tunnels was carried out. Comparative analysis of the performance of axisymmetric heat-treated high-strength lattice girders and original-design I20b steel rib was conducted. The test results show that the settlement of high-strength lattice girders is decreased by about 7%~30% compared with the test section of original-design I20b steel rib. The surrounding rock pressure is similar, but the stress of high-strength lattice girders is slightly higher than that of I20b steel rib. Due to the better binding ability of the lattice girders and the concrete, the ultimate bearing capacity of the ‘lattice girders and shotcrete’ is greater than that of the ‘I20b steel rib and shotcrete’. Moreover, the steel consumption of lattice girder is about 36% less than I20b steel rib, which shows significant economic and social benefits. Full article

The concrete stress behavior and cause of cracking at the anchorage zones of top and bottom slabs of a post-tensioned prestressed concrete box beam were studied. Based on the complex stress distribution under local anchor problem for the Yichang Yangtze River Bridge, which is the longest continuous rigid frame arch railway bridge in the world, model tests were conducted. Two full-scale specimens of top and bottom slabs were fabricated and gradually loaded based on principle of equivalent stress. The goal was to analyze the longitudinal and transverse stress distributions of cross sections of specimens at various loading cases during the experiment. From the experimental results, it can be concluded that the mechanical behavior of the concrete and steel bars were in good agreement when prestressed tendons were loaded. Tensile stress of concrete in prestressed anchorage zone gradually increased and surpassed the ultimate tensile strength of concrete with the increasing load. Consequently, local longitudinal cracking was formed at the anchorage block. Some recommendations to avoid the concrete at the anchorage zone continuing to crack are summarized in this paper. Full article
