With the further development of China’s coal resources, mining operations are constantly transferred to the deep soft rock. As such, the mine roadway is under the action of high geostress, the surrounding rock body engineering properties are poor, the overall strength is low, the traditional support method struggles to meet the needs of safe production, and the surrounding rock control has become a major technical challenge. This paper relies on the actual project, analyzes the destabilization mechanism of the roadway, analyzes the deformation of the peripheral rock of the deep roadway, determines the physical and mechanical parameters of the peripheral rock through indoor tests, establishes numerical analysis model, proposes to adopt the joint support scheme of anchor rods + anchor cables + a 36U-type steel metal bracket + a laying net + a laying mat + filling behind the wall, and monitors the displacement of peripheral rock of the roadway on a regular basis by using the numerical display convergence meter, and then obtains the displacement of the peripheral rock of the roadway after excavation as well as under the influence of the quarrying movement. Under the influence of the roadway perimeter rock displacement, we evaluate the reasonableness of the support program, as well as the safe and effective control of the roadway perimeter rock, to achieve the ideal roadway perimeter rock support and control effect. Full article

The irregular joint network unique to columnar joints separates the rock mass into several irregular polygonal prisms. Similar physical model specimens of columnar jointed rock mass (CJRM) were fabricated using a rock-like material. The effect of the irregularity of the joint network was considered in the horizontal plane, and the effect of the dip angle of the joint network was considered in the vertical plane. The strength and deformation moduli of the specimen were investigated using uniaxial compression tests. A total of four failure modes of regular columnar jointed rock mass (RCJRM) and irregular columnar jointed rock mass (ICJRM) were identified through the tests. The peak stress of the irregular columnar jointed rock mass specimen is reduced by 56.65%. The strength and deformation moduli of RCJRM were greater than those of ICJRM, while the anisotropic characteristics of ICJRM were stronger. The failure mode of CJRM was determined by the dip angle. With the increase in the dip angle, the strength and deformation moduli of irregular columnar jointed rock mass are a symmetrical “V” type distribution, 45° corresponds to the minimum strength, and 30° obtains the minimum deformation modulus. With the increase in the irregularity coefficient, the strength and deformation moduli of CJRM decreased first and then increased gradually. When the irregularity coefficient is 0.1, the linear deformation modulus reaches the minimum value. When the irregularity coefficient is 0.7, the median deformation modulus reaches the minimum value. The fitting function proposed in the form of the cosine function managed to predict the strength value of CJRM and showed the strength of the anisotropic characteristics caused by the change in the dip angle. Compared with the existing physical model test results, it is determined that the strength of the specimen is positively correlated with the addition amount of rock-like material and the loading rate, and negatively correlated with the water consumption. Full article

The Xiaolangdi Dam is a key project for the control and development of the Yellow River. It bears the functions of flood control, controlling water and sediment in the lower reaches, ice prevention, industrial and agricultural water supply, power generation, and so on. Its safety is related to people’s life and property safety and local economic and social development. It is of great significance to carry out comprehensive and regular deformation monitoring for dams since the deformation is an important evaluation index for dam safety. Interferometric Synthetic Aperture Radar (InSAR) technology has been a rapidly evolving technology in the field of space geodesy in recent years. It offers advantages such as high monitoring precision, extensive coverage, and high monitoring point density, making it a powerful tool for monitoring deformations in hydraulic engineering projects. Based on Sentinel-1 data covering the Xiaolangdi Dam from September 2020 to November 2022, the PS-InSAR technique was used to obtain the surface deformation of the Xiaolangdi Dam, and reservoir water level data on image acquisition dates were obtained for joint analysis. The results show that there is a large deformation in the center of the dam crest of the Xiaolangdi Dam, while both sides of the slope and downstream dam foot are relatively stable. The time series deformation of the dam body is closely related to the reservoir water level change. When the water level increases, the dam body tends to deform downstream; when the water level decreases, the dam body tends to deform upstream. The deformation and water level of the Xiaolangdi Dam exhibit a clear negative correlation. There is no significant cumulative deformation on the dam slopes or at the base of the dam. However, cumulative deformation occurs over time in the central area of the dam’s crest. The deformation process at the central area of the dam’s crest follows a continuous and non-disruptive pattern, which is consistent with the typical deformation behavior of the Xiaolangdi earth–rock dam structure. Therefore, it is judged that the current deformation of the Xiaolangdi Dam does not impact the safe operation of the dam. InSAR technology enables the rapid acquisition of high-precision, high-density deformation information on the surfaces of reservoir dams. With an increasing number of radar satellites in various frequency bands, such as Sentinel-1 and TerraSAR-X, there is now an ample supply of available data sources for InSAR applications. Consequently, InSAR technology can be extended to routine monitoring applications for reservoir dam deformations, especially for small and medium-sized reservoirs that may not be equipped with ground measurement tools like GNSS. This holds significant importance and potential for enhancing the safety monitoring of such reservoirs. Full article

The evaluation of changes in shear resistance on soft (or weathered) rock joints under cyclic shear loads with constant normal load (CNL) and constant normal stiffness (CNS) significantly contributes to increasing the safety and stability of rock slopes and underground structures. In this study, a series of cyclic shear tests were conducted on simulated soft rock joints with regular (15°-15°, 30°-30°) and irregular (15°-30°) asperities under different normal stiffnesses (k_n). The results indicated that the first peak shear stress increases with the increase in k_n up to the normal stiffness of the joints (k_nj). Beyond k_nj, no significant change was observed in the peak shear stress. The difference in peak shear stress between regular (30°-30°) and irregular joints (15°-30°) increases as k_n increases. The minimum difference of peak shear stress between regular and irregular joints was observed (8.2%) under CNL and the maximum difference was found (64.3%) on k_nj under CNS. The difference in peak shear stress between the first and subsequent cycles significantly increases as both the joint roughness and k_n increases. A new shear strength model is developed to predict peak shear stress of the joints for different k_n and asperity angles under cyclic shear loads. Full article

As an environmentally friendly and high-calorific natural gas, coalbed methane (CBM) has become one of the world’s most crucial unconventional energy sources. Undoubtedly, it is necessary to conduct in-depth research on reservoir exploration methods to ensure high and stable CBM production in the development stage. However, current methods have disadvantages such as high cost, complex devices, and poor terrain adaptability, and therefore they are unsuitable for reasonable monitoring of CBM reservoirs. In contrast, electromagnetic prospecting methods are increasingly widely employed in the rapid delineation of conductive distributions, contributing a lot to in-situ reservoir interpretation. Furthermore, a natural source Super-Low Frequency electromagnetic component method (i.e., the SLF method for short) has been proposed and applied with high potential in a CBM enrichment area, Qinshui Basin, China. In this paper, this method is thoroughly discussed. The magnetic component responses of the SLF method can be used as the characteristic responses of subsurface layers, and the forward modeling algorithms using the finite element method have been successfully developed and verified. On this basis, the direct depth transformation and one-dimensional nonlinear regularization inversion algorithms of the magnetic component responses are proposed for geo-object interpretation. With the help of the empirical mode decomposition (EMD), an SLF data processing workflow is demonstrated theoretically and practically, which is integrated into a portable instrument. The instrument’s ability to identify the low-resistivity reservoirs and their surrounding rocks has been proved by field survey. The extraction of electromagnetic radiation (EMR) anomalies also helps to refine the reservoir interpretation with higher accuracy. A joint comparative inversion test between the SLF method and the audio-magnetotelluric method (AMT) is also addressed, demonstrating that the SLF method is reliably applicable in the field survey of CBM reservoirs. A preliminary statistical analysis shows that the depth resolution of CBM reservoirs can reach the order of tens of meters. Therefore, the SLF method is expected to become one of the most potential options for in-situ CBM exploration with a cost-effective interpretation capability. Full article

Earthquakes are a major external factor that induce landslides. In order to systematically study the dynamic effects and failure mechanism of anti-dip bedding rock slopes (the slope trend is the same as the joint trend, while the slope dip direction is opposite to the joint dip direction) under seismic action (as well as the spatial effects of the structural planes in the anti-dip bedding rock slopes), three-dimensional (3D) discrete-element numerical calculations were performed to analyze anti-dip bedding rock slopes with different slope angles, joint angles, and joint trends subjected to the action of natural seismic and sinusoidal waves. The results were analyzed to investigate the amplification effect, change in Fourier spectrum, failure mechanism, and permanent displacement of the slope under the applied seismic action. The permanent displacement of the slope was calculated using Newmark’s method and the results obtained were discussed and compared with those obtained from a dynamic analysis performed using the 3D discrete-element method. The results showed that the regularity of the spatial distribution of the amplification effect was less clear than that encountered in the planar problem (unidirectional or bidirectional dynamical loading), and this leads to the effect of having an overall rhythmical nature. The seismic wave decays in the high-frequency part from the bottom up of the slope, while the dominant frequency of the seismic wave decreases. The value of the permanent displacement obtained using Newmark’s method is much smaller than that obtained using the dynamic 3D discrete-element analysis approach. The angle between the joint and slope trends has a significant effect on the amplification effect, failure mode, permanent displacement, and stability of slopes subjected to seismic action. Full article

Intact rock-like specimens and specimens that include a single planar joint or triangular sawteeth joint at various angles are prepared for split Hopkinson pressure bar (SHPB) testing at loading rates of 303.1–5233.6 GPa/s. Only results that are associated with an error (e_ε) of less than 20.0% are utilized in subsequent analyses. The effects of the loading rate and angle of the load applied to various joint patterns on the failure type and dynamic peak stresses/strength of the specimens are investigated. Experimental results demonstrate that failure of each specimen can be classified into the following four types, Type A: integrated with or without tiny flake-off, Type B: slide failure, Type C: fracture failure, and Type D: crushing failure. The results of statistical analysis of variance (ANOVA) indicate that the loading rate, the angles of the base plane (β), and the asperity (α) of the sawteeth joint of the specimen all affect its dynamic peak stress when fracture failure occurs. The loading rate and β are important when the slide failure occurs, and the loading rate is the sole factor that significantly influences its dynamic peak stress when the specimen is crushed to failure. The dynamic peak stress of the specimen increases with the loading rate, while the rate of increase gradually decreases. The β and α of a jointed specimen affect the location of stress concentration during loading, further influencing the dynamic peak stress of such a specimen under slide and fracture failure. When the loading rate is high and the specimen is crushed to failure, the influences of β and α disappear, and the increase of loading rate reduces the efficiency of raising the dynamic peak stress. Full article

The coupling between hydraulic and mechanical processes in rock joints has significantly influenced the properties and applications of rock mass in many engineering fields. In this study, a series of regular shear tests and shear-flow coupled tests were conducted on artificial joints with sawtooth asperities. Shear deformation, strength, and seepage properties were comprehensively analyzed to reveal the influence of joint roughness, normal stress, and seepage pressure on shear-flow coupled behavior. The results indicate that the shear failure mode, which can be divided into sliding and cutting, is dominated by joint roughness and affected by the other two factors under certain conditions. The seepage process makes a negative impact on shear strength as a result of the mutual reinforcing of offsetting and softening effects. The evolution of hydraulic aperture during the shear-flow coupled tests embodies a consistent pattern of four stages: shear contraction, shear dilation, re-contraction, and stability. The permeability of joint sample is considerably enlarged with the increase of joint roughness, but decreases with the addition of normal stress. Full article
