Search Results (4)

Search Parameters:
Keywords = radial thermoelectric generator

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
11 pages, 1756 KiB
Article
Stencil-Printed Scalable Radial Thermoelectric Device Using Sustainable Manufacturing Methods
by Eunhwa Jang, Rohan B. Ambade, Priyanshu Banerjee, L. D. Timmie Topoleski and Deepa Madan
Sustainability 2024, 16(9), 3560; https://doi.org/10.3390/su16093560 - 24 Apr 2024
Cited by 2 | Viewed by 1388
Abstract
In this study, we used n-chitosan-Bi2Te2.7Se0.3 and p-chitosan-Bi0.5Sb1.5Te3 composite inks to print a circular thermoelectric generator (TEG) device using a low-energy-input curing method. Thermoelectric (TE) composite films were fabricated using varying sizes of [...] Read more.
In this study, we used n-chitosan-Bi2Te2.7Se0.3 and p-chitosan-Bi0.5Sb1.5Te3 composite inks to print a circular thermoelectric generator (TEG) device using a low-energy-input curing method. Thermoelectric (TE) composite films were fabricated using varying sizes of thermoelectric particles and a small chitosan binder (0.05 wt. %). The particles and binder were hot pressed at an applied pressure of 200 MPa and cured at 200 °C for 30 min. We achieved ZT of 0.35 for the n-type and 0.7 for the p-type TE composite films measured at room temperature. A radial TEG was fabricated using the best-performing n-type and p-type composite inks and achieved a power output of 87 µW and a power density of 727 µW/cm2 at a temperature difference of 35 K; these are among the best-reported values for printed TEG devices. Using a low-energy-input fabrication method, we eliminated the need for high-temperature and long-duration curing processes to fabricate printing devices. Thus, we envisage that the low-energy-input curing process and cost-effective printable strategy presented in this work pave the way for sustainable manufacturing of large-scale energy harvesting TEG devices. Full article
(This article belongs to the Special Issue Progress in Sustainable and Clean Energy Technologies)
Show Figures

Figure 1

22 pages, 5521 KiB
Article
Radial Thermoelectric Model for Stranded Transmission Line Conductors
by Jordi-Roger Riba
Sensors 2023, 23(22), 9205; https://doi.org/10.3390/s23229205 - 15 Nov 2023
Cited by 4 | Viewed by 1773
Abstract
Bare-stranded conductors play a critical role in the efficiency and safe operation of transmission lines. The heat generated in the interior of the conductor is conducted radially to the outer surface, creating a radial thermal gradient. The radial temperature gradient between the core [...] Read more.
Bare-stranded conductors play a critical role in the efficiency and safe operation of transmission lines. The heat generated in the interior of the conductor is conducted radially to the outer surface, creating a radial thermal gradient. The radial temperature gradient between the core and the surface depends on multiple factors, such as stranding, number of layers, current level, electrical resistance and the effective radial thermal conductivity. Therefore, the radial temperature model must be considered when developing accurate conductor models. Such models are particularly important in the development of dynamic line rating (DLR) approaches to allow the full current carrying capacity of the conductor to be utilized while ensuring safe operation. This paper develops a radial one-dimensional thermoelectric model for bare-stranded conductors used in transmission lines. The accuracy of the proposed model is determined by experimental tests performed on three conductors. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

11 pages, 3219 KiB
Article
p-Type PVA/MWCNT-Sb2Te3 Composites for Application in Different Types of Flexible Thermoelectric Generators in Combination with n-Type PVA/MWCNT-Bi2Se3 Composites
by Jana Andzane, Krisjanis Buks, Juris Bitenieks, Lasma Bugovecka, Artis Kons, Remo Merijs-Meri, Janis Svirksts, Janis Zicans and Donats Erts
Polymers 2022, 14(23), 5130; https://doi.org/10.3390/polym14235130 - 25 Nov 2022
Cited by 11 | Viewed by 2732
Abstract
This work is devoted to the fabrication of p-type polyvinyl alcohol (PVA)-based flexible thermoelectric composites using multiwall carbon nanotubes-antimony telluride (MWCNT-Sb2Te3) hybrid filler, the study of the thermoelectrical and mechanical properties of these composites, and the application of these [...] Read more.
This work is devoted to the fabrication of p-type polyvinyl alcohol (PVA)-based flexible thermoelectric composites using multiwall carbon nanotubes-antimony telluride (MWCNT-Sb2Te3) hybrid filler, the study of the thermoelectrical and mechanical properties of these composites, and the application of these composites in two types (planar and radial) of thermoelectric generators (TEG) in combination with the previously reported PVA/MWCNT-Bi2Se3 flexible thermoelectric composites. While the power factors of PVA/MWCNT-Sb2Te3 and PVA/MWCNT-Bi2Se3 composites with 15 wt.% filler were found to be similar, the PVA/MWCNT-Sb2Te3 composite with 25 wt.% filler showed a ~2 times higher power factor in comparison with the PVA/MWCNT-Bi2Se3 composites with 30 wt.% filler, which is attributed to its reduced electrical resistivity. In addition, developed PVA/MWCNT-Sb2Te3 composites showed a superior mechanical, electrical, and thermoelectric stability during 100 consequent bending cycles down to a 3 mm radius, with insignificant fluctuations of the resistance within 0.01% of the initial resistance value of the not bent sample. Demonstrated for the first time, 2-leg TEGs composed from p-type PVA/MWCNT-Sb2Te3 and n-type PVA/MWCNT-Bi2Se3 composites showed a stable performance under different external loads and showed their potential for applications involving low temperature gradients and power requirements in the range of nW. Full article
(This article belongs to the Special Issue Polymer-Based Hybrid Composites)
Show Figures

Graphical abstract

21 pages, 6207 KiB
Article
Power and Fuel Economy of a Radial Automotive Thermoelectric Generator: Experimental and Numerical Studies
by Martí Comamala, Toni Pujol, Ivan Ruiz Cózar, Eduard Massaguer and Albert Massaguer
Energies 2018, 11(10), 2720; https://doi.org/10.3390/en11102720 - 11 Oct 2018
Cited by 17 | Viewed by 2809
Abstract
Recent developments of high performance thermoelectric (TE) materials have increased the interest of using this technology to directly convert waste heat into electricity. In the automotive sector, many automotive thermoelectric generators (ATEGs) designs use TE modules (TEMs) with high hot side temperatures to [...] Read more.
Recent developments of high performance thermoelectric (TE) materials have increased the interest of using this technology to directly convert waste heat into electricity. In the automotive sector, many automotive thermoelectric generators (ATEGs) designs use TE modules (TEMs) with high hot side temperatures to cope with high engine load regimes. Here, we develop a new concept of a radial ATEG that is specifically designed to work with low temperature TEMs, which enables the use of Pb-free modules and reduces the thermal stress of the device. A prototype is built and tested at different regimes in an engine test bench. A numerical model of the ATEG is developed and validated. The consequences of modifying (1) the exchange area between the heat absorber and the exhaust gases and (2) the effective figure of merit of TEMs on the electrical output power and fuel economy are investigated by means of simulations. Results indicate that the maximum fuel economy (1.3%) is not attained at the point of maximum output power (228 W). In terms of fuel economy, the back pressure at the exhaust penalizes high mass flow regimes. We use a dimensionless parameter to analyze the potential of the ATEG for reducing fuel consumption. Full article
Show Figures

Figure 1
