Lattice-based post-quantum cryptography (PQC) algorithms demand number theoretic transform (NTT)-based polynomial multiplications. NTT-based polynomials’ multiplication relies on the computation of forward number theoretic transform (FNTT) and inverse number theoretic transform (INTT), respectively. Therefore, this work presents a unified NTT hardware accelerator architecture to facilitate the polynomial multiplications of the CRYSTALS-Kyber PQC algorithm. Moreover, a unified butterfly unit design of Cooley–Tukey and Gentleman–Sande configurations is proposed to implement the FNTT and INTT operations using one adder, one multiplier, and one subtractor, sharing four routing multiplexers and one Barrett-based modular reduction unit. The critical path of the proposed butterfly unit is minimized using pipelining. An efficient controller is implemented for control functionalities. The simulation results after the post-place and -route step are provided on Xilinx Virtex-6 and Virtex-7 field-programmable gate array devices. Also, the proposed design is physically implemented for validation on Virtex-7 FPGA. The number of slices utilized on Virtex-6 and Virtex-7 devices is 398 and 312, the required number of clock cycles for one set of FNTT and INTT computations is 1410 and 1540, and the maximum operating frequency is 256 and 290 MHz, respectively. The average figure of merit (FoM), where FoM is the ratio of throughput to slices, illustrates 62% better performance than the most relevant NTT design from the literature. Full article

The effects of quantum mechanics dominate nanoscale devices, where Moore’s law no longer holds true. Additionally, with the recent rapid development of quantum computers, the development of reversible gates to overcome the problems of energy and information loss and the nano-level quantum-dot cellular automata (QCA) technology to efficiently implement them are in the spotlight. In this study, a full adder-subtractor, a core operation of the arithmetic and logic unit (ALU), the most important hardware device in computer operations, is implemented as a circuit capable of reversible operation using QCA-based reversible gates. The proposed circuit consists of one reversible QCA gate and two Feynman gates and is designed as a multi-layer structure for efficient use of area and minimization of delay. The proposed circuit is tested on QCADesigner 2.0.3 and QCADesigner-E 2.2 and shows the best performance and lowest energy dissipation. In particular, it shows tremendous improvement rates of 180% and 562% in two representative standard design cost indicators compared to the best existing studies, and also shows the highest circuit average output polarization. Full article

Reversible logic enables ultra-low power circuit design and quantum computation. Quantum-dot Cellular Automata (QCA) is the most promising technology considered to implement reversible circuits, mainly due to the correspondence between features of reversible and QCA circuits. This work aims to push forward the state-of-the-art of the QCA-based reversible circuits implementation by proposing a novel QCA design of a reversible full adder\full subtractor (FA\FS). At first, we consider an efficient XOR-gate, and based on this, new QCA circuit layouts of Feynman, Toffoli, Peres, PQR, TR, RUG, URG, RQCA, and RQG are proposed. The efficient XOR gate significantly reduces the required clock phases and circuit area. As a result, all the proposed reversible circuits are efficient regarding cell count, delay, and circuit area. Finally, based on the presented reversible gates, a novel QCA design of a reversible full adder\full subtractor (FA\FS) is proposed. Compared to the state-of-the-art circuits, the proposed QCA design of FA\FS reversible circuit achieved up to 57% area savings, with 46% and 29% reduction in cell number and delay, respectively. Full article

Reversible arithmetic and logic unit (ALU) is a necessary part of quantum computing. In this work, we present improved designs of reversible half and full addition and subtraction circuits. The proposed designs are based on a universal one type gate (G gate library). The G gate library can generate all possible permutations of the symmetric group. The presented designs are multi-function circuits that are capable of performing additional logical operations. We achieve a reduction in the quantum cost, gate count, number of constant inputs, and delay with zero garbage, compared to relevant results obtained by others. The experimental results using IBM Quantum Experience (IBM Q) illustrate the success probability of the proposed designs. Full article

One of the emerging technologies at the nanoscale level is the Quantum-Dot Cellular Automata (QCA) technology, which is a potential alternative to conventional CMOS technology due to its high speed, low power consumption, low latency, and possible implementation at the atomic and molecular levels. Adders are one of the most basic digital computing circuits and one of the main building blocks of VLSI systems, such as various microprocessors and processors. Many research studies have been focusing on computable digital computing circuits. The design of a Full Adder/Subtractor (FA/S), a composite and computing circuit, performing both the addition and the subtraction processes, is of particular importance. This paper implements three new Full Adder/Subtractor circuits with the lowest number of cells, lowest area, lowest latency, and a coplanar (single-layer) circuit design, as was shown by comparing the results obtained with those of the best previous works on this topic. Full article
