Direct-writing submicron copper circuits on glass with laser precision—without lithography, vacuum deposition, or etching—represents a transformative step in next-generation microfabrication. We present a high-resolution, maskless method for metallizing glass using ultrashort pulse Bessel beam laser processing, followed by silver ion activation and electroless copper plating. The laser-modified glass surface hosts nanoscale chemical defects that promote the in situ reduction of Ag⁺ to metallic Ag⁰ upon exposure to AgNO₃ solution. These silver seeds act as robust catalytic and adhesion sites for subsequent copper growth. Using this approach, we demonstrate circuit traces as narrow as 0.7 µm, featuring excellent uniformity and adhesion. Compared to conventional redistribution-layer (RDL) and under-bump-metallization (UBM) techniques, this process eliminates multiple lithographic and vacuum-based steps, significantly reducing process complexity and production time. The method is scalable and adaptable for applications in transparent electronics, fan-out packaging, and high-density interconnects. Full article

The conventional method of cutting quartz glass with a knife often leads to undesirable effects, such as chipping, debris generation, and an inconsistent cut quality. Additionally, implementing the current methods of laser ablation cutting and crack control cutting presents challenges in ensuring both the quality of the cut and the efficiency of the process. Previous reports have documented a single direct cut of thin quartz glass, albeit at a thickness of only 200 μm. In this study, we utilized a pulse-width-tunable Gaussian beam, in combination with an axicon and a beam-reducing mirror, to generate a high-quality Bessel beam. This process endows the quartz glass with a nano-porous structure with a thickness of 1 mm, enabling high-quality cutting in a single pass. The effects of laser-cutting speed and pulse width on the cutting cross-section and cut surface were investigated. The results of the experiments show that using the optimal cutting speed and pulse width significantly improved cutting quality, reduced surface damage and sputtering, enabled the penetration of the modified cutting cross-section throughout the material, and decreased cutting cross-section roughness to 607 nm Ra. This technique holds promise for the laser-processing industry, enhancing both the quality and efficiency of cutting 1 mm thick quartz glass. Full article

We investigate the elongated modifications resulting from a Bessel beam-shaped femtosecond laser in fused silica under three different operation modes, i.e., the single-pulse, MHz-burst, and GHz-burst regimes. The single-pulse and MHz-burst regimes show rather similar behavior in glass, featuring elongated and slightly tapered modifications. Subsequent etching with Potassium Hydroxide exhibits an etching rate and selectivity of up to 606 $\mathsf{\mu }$m/h and 2103:1 in single-pulse operation and up to 322 $\mathsf{\mu }$m/h and 2230:1 in the MHz-burst regime, respectively. Interestingly, in the GHz-burst mode, modification by a single burst of 50 pulses forms a taper-free hole without any etching. This constitutes a significant result paving the way for chemical-free, on-the-fly drilling of high aspect-ratio holes in glass. Full article

The cutting of thick glass is extensively employed in aerospace, optical, and other fields. Although ultrafast laser Bessel beams are heavily used for glass cutting, the cutting thickness and cutting quality need to be further improved. In this research, the high-quality cutting of thick glass was realized for the first time using ultrafast laser perforation assisted by CO₂ laser separation. Initially, an infrared picosecond laser Bessel beam was employed to ablate the soda-lime glass and generate a perforated structure. Subsequently, a CO₂ laser was employed to induce crack propagation along the path of the perforated structure, resulting in the separation of the glass. This study investigates the influence of hole spacing, pulse energy, and the defocusing distance of the picosecond laser Bessel beam on the average surface roughness of the glass sample cutting surface. The optimal combination of cutting parameters for 6 mm thick glass results in a minimum surface roughness of 343 nm in the cross-section. Full article

The generation of optical beam arrays with prospective uses within the realms of microscopy, photonics, non-linear optics, and material processing often requires Dammann gratings. Here, we report the direct fabrication of one- and two-dimensional Dammann grating-like structures on soda lime glass using a nanosecond pulsed laser beam with a 1064 nm wavelength. Using the fabricated grating, an axicon lens, and an optical magnification system, we propose a scheme of generation of a diverging array of zero-order Bessel beams with a sub-micron-size central core, extending longitudinally over several hundred microns. Two different grating fabrication strategies are also proposed to control the number of Bessel beams in an array. It was demonstrated that Bessel beams of 12 degrees conical half-angle in an array of up to [5 × 5] dimensions can be generated using a suitable combination of Dammann grating, axicon lens and focusing optics. Full article

High-aspect-ratio microholes, the fundamental building blocks for microfluidics, optical waveguides, and other devices, find wide applications in aerospace, biomedical, and photonics fields. Yttrium aluminum garnet (YAG) crystals are commonly used in optical devices due to their low stress, hardness, and excellent chemical stability. Therefore, finding efficient fabrication methods to produce high-quality microholes within YAG crystals is crucial. The Bessel beam, characterized by a uniform energy distribution along its axis and an ultra-long depth of focus, is highly suitable for creating high-aspect-ratio structures. In this study, an axicon lens was used to shape the spatial profile of a femtosecond laser into a Bessel beam. Experimental verification showed a significant improvement in the high aspect ratio of the microholes produced in YAG crystals using the femtosecond Bessel beam. This study investigated the effects of the power and defocus parameters of single-pulse Bessel beams on microhole morphology and size, and microhole units with a maximum aspect ratio of more than 384:1 were obtained. Based on these findings, single-pulse femtosecond Bessel processing parameters were optimized, and an array of 181 × 181 microholes in a 400 μm thick YAG crystal was created in approximately 13.5 min. The microhole array had a periodicity of 5 μm and a unit aspect ratio of 315:1, with near-circular top and subface apertures and high repeatability. Full article

Conical emission is a typical nonlinear phenomenon that occurs during the filamentation of femtosecond laser pulses in transparent media. In this work, the conical emission induced by two kinds of typical vortex beams (i.e., Laguerre–Gaussian (LG) and Bessel–Gaussian (BG) beams) in water is experimentally studied. By recording the light spots of different spectra components from the supercontinuum induced by the vortex beams, the characteristics of the conical emission induced by femtosecond vortex beams are studied. It is found that the spots of the supercontinuum induced by the two kinds of vortex beams differ greatly from each other. The spots of the supercontinuum induced by the BG beams are a set of concentric rings like a rainbow with a white center, while the white light spots in the case of the LG beams are circular white disks, which are different from the commonly observed white light spots. By measuring the maximum divergence angle, it is observed that the divergence angle increases with a decrease in the wavelength, while it is merely affected by the topological charge, which is explained by the formation mechanism of conical emission in terms of self-phase modulation. Based on the observed results, we discuss the transfer of optical angular momentum during the supercontinuum induced by the filamentation of femtosecond vortex beams. This work may help to better understand the transfer of optical angular momentum in non-optical parametric processes as well as the interaction of high-intensity pulses with matter. Full article

Selective laser etching is a promising candidate for the mass production of glass interposers. It comprises two steps: local modification by an ultrashort-pulsed laser and chemical etching of the modified volume. According to previous studies, when an ultrashort-pulsed laser beam is irradiated on the sample, electron excitation occurs, followed by phonon vibration. In general, the electron excitation occurs for less than a few tens of picoseconds and phonon vibration occurs for more than 100 picoseconds. Thus, in order to compare the electric absorption and thermal absorption of photons in the commercial glass, we attempt to implement an additional laser pulse of 213 ps and 10 ns after the first pulse. The modified glass sample is etched with 8 mol/L KOH solution with 110 °C to verify the effect. Here, we found that the electric absorption of photons is more effective than the thermal absorption of them. We can claim that this result helps to enhance the process speed of TGV generation. Full article

We report, for the first time to the best of our knowledge, Bessel beam dielectrics cutting with a femtosecond laser in GHz-burst mode. The non-diffractive beam shaping is based on the use of an axicon and allows for cutting glasses up to 1 mm thickness with an excellent cutting quality. Moreover, we present a comparison of the cutting results with the state-of-the-art method, consisting of short MHz-bursts of femtosecond pulses. We further illustrate the influence of the laser beam parameters such as the burst energy and the pitch between consecutive Bessel beams on the machining quality of the cutting plane and provide process windows for both regimes. Full article

We report on an optical setup to generate multi-Bessel beam profiles combining a refractive axicon and a spatial light modulator. Based on their particular beam profile, Bessel beams offer advantageous properties for micro drilling processes and internal volume processing, especially for transparent materials. In addition, the laser power of industrial, ultrashort pulsed lasers has increased significantly over the last few years, offering the possibility for highly efficient processes using multi-spot profiles. Our optical concept combines the dynamic possibilities of beam splitting using a spatial light modulator with the benefits of Bessel beams, which facilitates multi-Bessel beam processing. Beside the simulation and experimental evaluation of the generated multi-Bessel beams, we exemplify the applicability of the developed module for the perforation of thin metal foils by micro drilling. Full article

A zeroth-order, non-diffracting Bessel beam, generated by picosecond laser pulses (1064 nm, 10 Hz, 30 ps) through an axicon, was utilized to perform pulse energy-dependent (12 mJ, 16 mJ, 20 mJ, 24 mJ) laser ablation of silver (Ag) substrates in air. The fabrication resulted in finger-like Ag nanostructures (NSs) in the sub-200 nm domain and obtained structures were characterized using the FESEM and AFM techniques. Subsequently, we employed those Ag NSs in surface-enhanced Raman spectroscopy (SERS) studies achieving promising sensing results towards trace-level detection of six different hazardous materials (explosive molecules of picric acid (PA) and ammonium nitrate (AN), a pesticide thiram (TH) and the dye molecules of Methylene Blue (MB), Malachite Green (MG), and Nile Blue (NB)) along with a biomolecule (hen egg white lysozyme (HEWL)). The remarkably superior plasmonic behaviour exhibited by the AgNS corresponding to 16 mJ pulse ablation energy was further explored. To accomplish a real-time application-oriented understanding, time-dependent studies were performed utilizing the AgNS prepared with 16 mJ and TH molecule by collecting the SERS data periodically for up to 120 days. The coated AgNSs were prepared with optimized gold (Au) deposition, accomplishing a much lower trace detection in the case of thiram (~50 pM compared to ~50 nM achieved prior to the coating) as well as superior EF up to ~10⁸ (~10⁶ before Au coating). Additionally, these substrates have demonstrated superior stability compared to those obtained before Au coating. Full article

Ultrashort Bessel beams have been used in this work to study the response of a 430-μm-thick monocrystalline sapphire sample to laser–matter interaction when injecting the beam orthogonally through the whole sample thickness. We show that with a 12° Bessel beam cone angle, we are able to internally modify the material and generate tailorable elongated microstructures while preventing the formation of surface cracks, even in the picosecond regime, contrary to what was previously reported in the literature. On the other hand, by means of Bessel beam machining combined with a trepanning technique where very high energy pulses are needed, we were able to generate 100 μm diameter through-holes, eventually with negligible cracks and very low taper angles thanks to an optimization achieved by using a 60-μm-thick layer of Kapton Polyimide removable tape. Full article

Controlling the formation of high aspect ratio void channels inside glass is important for applications like the high-speed dicing of glass. Here, we investigate void formation using ultrafast Bessel beams in the single shot illumination regime. We characterize the morphology of the damages as a function of pulse energy, pulse duration, and position of the beam inside fused silica, Corning Eagle XG, and Corning Gorilla glass. While a large set of parameters allow for void formation inside fused silica, the operating window is much more restricted for Eagle XG and Gorilla glass. The transient formation of a molten layer around voids enables us interpreting the evolution of the morphology with pulse energy and duration. Full article

Nano-crystals were formed in the exposed regions of photo-thermo-refractive glass undergoing irradiation with zeroth order chirp-controlled ultrafast laser Bessel beams and subsequent heat treatment. Effects of various writing powers, pulse durations and heat treatment time on the distribution and the size of the nano-crystals were investigated. The results show that nano-crystals’ distribution depended on the laser power density spatial shape, while the size of the nano-crystals is quasi-independent. However, the average diameter of the nano-crystals was affected by the heat treatment time, decreasing from 175 to 105 nm with the time halved. In addition, using crystallographic characterization by X-ray diffraction, the nano-crystal composition in the laser-exposed regions was detected to be sodium fluoride. Full article

Micro-drilling transparent dielectric materials by using non-diffracting beams impinging orthogonally to the sample can be performed without scanning the beam position along the sample thickness. In this work, the laser micromachining process, based on the combination of picosecond pulsed Bessel beams with the trepanning technique, is applied to different transparent materials. We show the possibility to create through-apertures with diameter on the order of tens of micrometers, on dielectric samples with different thermal and mechanical characteristics as well as different thicknesses ranging from two hundred to five hundred micrometers. Advantages and drawbacks of the application of this technique to different materials such as glass, polymer, or diamond are highlighted by analyzing the features, the morphology, and the aspect-ratio of the through-holes generated. Alternative Bessel beam drilling configurations, and the possibility of optimization of the quality of the aperture at the output sample/air interface is also discussed in the case of glass. Full article
