The process of decision-making for machining box-type components plays a crucial role in the technological design of mechanical components. Currently, the selection of process parameters for box-type parts often relies on designers consulting manuals or on personal experience. Moreover, different designers utilize independent and heterogeneous Computer-Aided Process Planning (CAPP) systems, leading to uncertainties in process design and difficulties in sharing and transmitting process knowledge. This paper proposes an ontology-based process decision-making method for the planar machining of box-type parts to infer the appropriate machining process parameters. First, a hierarchical information representation model for process decision-making in planar machining is constructed to describe the decision-making process. Second, an ontology model for process decision-making in planar machining is developed based on relevant concepts and relationships involved in the decision-making process. Third, reasoning rules for planar machining process decisions are established using Semantic Web Rule Language (SWRL), incorporating part feature information and process knowledge to infer reasonable process methods and operation dimensions. Finally, a case study of gear transmission housing is presented to illustrate the working process of the proposed method and verify its effectiveness. Full article

This study investigates the unsteady aerodynamic mechanisms underlying the efficient flight of birds and proposes a biomimetic flapping-wing aircraft design utilizing a double-crank double-rocker mechanism. Building upon a detailed analysis of avian flight dynamics, a two-stage foldable flapping mechanism was developed, integrating an optimized double-crank double-rocker structure with a secondary linkage system. This design enables synchronized wing flapping and spanwise folding, significantly enhancing aerodynamic efficiency and dynamic performance. The system’s planar symmetric layout and high-ratio reduction gear configuration ensure movement synchronicity and stability while reducing mechanical wear and energy consumption. Through precise modeling, the motion trajectories of the inner and outer wing segments were derived, providing a robust mathematical foundation for motion control and optimization. Computational simulations based on trajectory equations successfully demonstrated the characteristic figure-eight wingtip motion. Using 3D simulations and CFD analysis, key parameters—including initial angle of attack, aspect ratio, flapping frequency, and flapping speed—were optimized. The results indicate that optimal aerodynamic performance is achieved at an initial angle of attack of 9°, an aspect ratio of 5.1, and a flapping frequency and speed of 4–5 Hz and 4–5 m/s, respectively. These findings underscore the potential of biomimetic flapping-wing aircraft in applications such as UAVs and military technology, providing a solid theoretical foundation for future advancements in this field. Full article

Gears are foundational tools used to transmit or modify mechanical energy or motion. Implementing gears into planar linkage mechanisms is less common but can be a similarly valuable technique that takes advantage of the high efficiency of gears while producing complex and precise motions. While recent numerical methods for designing these geared planar linkage mechanisms (GPLMs) have proliferated in the literature, analytical approaches have their merits and have received less attention. Here, an analytical alternative is presented as a modification of the complex-number loop-based synthesis method for designing multiloop mechanisms. Some of the base topologies for geared dyad, triad, and quadriad chains are presented, along with a numerical example demonstrating the solution procedure’s effectiveness. Full article

This study proposes a design approach and the development of a low-power planar biped robot named YU-Bibot. The kinematic structure of the robot consists of six independently driven axes, and it weighs approximately 20 kg. Based on biomimetics, the robot dimensions were selected as the average anthropomorphic dimensions of the human lower extremities. The optimization of the mechanical design and actuator selection of the robot was based on the results of parametric simulations. The natural human walking gait was mimicked as a walking pattern in these simulations. As a result of the optimization, a low power-to-weight ratio of 30 W/kg was obtained. The drive system of the robot joints consists of servo-controlled brushless DC motors with reduction gears and additional bevel gears at the knee and ankle joints. The robot features spring-supported knee and ankle joints that counteract the robot’s weight and compensate for the backlash present in these joints. The robot is constrained to move only in the sagittal plane by using a lateral support structure. The robot’s feet are equipped with low-cost, force-sensitive resistor (FSR)-type sensors for monitoring ground contact and zero-moment point (ZMP) criterion. The experimental results indicate that the proposed robot mechanism can follow the posture commands accurately and demonstrate locomotion at moderate stability. The proposed parametric natural gait simulation-based design approach and the resulting biped robot design with a low power/weight ratio are the main contributions of this study. Full article

Gear tooth spalling is one of the inevitable fault modes in the long-term service of the traction transmission system of railway vehicles, which can worsen the dynamic load of the rotating mechanical system and reduce the operating quality. Therefore, it is necessary to study its fault mechanism to guide fault diagnosis scientifically. This paper established a planar railway vehicle model with a traction transmission system and an analytical time-varying meshing stiffness (TVMS) model of the spalling spur gear. Then, it analyzed the dynamic characteristics under traction conditions. The research found that the spalling length and depth affect the amplitude of the TVMS at the defect, while the width affects the range of the TVMS loss. The crest factor is the best evaluation indicator in ideal low-noise environments due to its sensitivity and linearity, but it is not good in strong-noise environments. Similarly, a time–frequency analysis tool cannot significantly detect the sideband characteristics that are excited by spalling. After high-pass filtering, the root mean square and variance exhibit excellent classification and vehicle speed independence in strong-noise environments. This research achievement can provide adequate theoretical support for feature selection and making strategies for fault diagnosis of railway vehicle gear systems. Full article

As the core component of the wind turbine transmission chain, the wind power gear plays a vital role in the safe and efficient operation of the whole machine. Wind power gears are subjected to varying degrees of wear on their contact surfaces due to alternating load impacts. For wind power gear repair and remanufacturing, laser cladding technology is proposed on the wind power gearbospline shaft. The effect of tungsten carbide (WC) addition on the laser-clad Fe-based coatings was investigated in this study. The morphology and composition of the composite coatings formed with different proportions of WC were studied using scanning electron microscopy (SEM) and energy-dispersive spectroscopy (EDS). The microhardness and wear resistance were measured with a digital microhardness tester and a wear testing machine, respectively. The coatings were compact with no apparent cracks or pores and the microstructures of the regions above the fusion zone gradually changed from planar crystal to columnar crystal and cellular crystal, while the middle and upper parts of the coating mainly consisted of equiaxed crystals. The microhardness of the coatings gradually increased with the increase of WC content. The coating with 16% WC addition reached a maximum microhardness of 826.2 HV. The increase of WC content improved the wear resistance of the laser-clad Fe-based composite coatings. The wear mechanism of the coatings was mainly abrasive wear, along with slight adhesion wear and oxidative wear. Full article

Dynamic pointing and tracking accuracy are the most relevant indicators of dynamic performance for the satellite antenna driving mechanism. Multi-clearance coupling in the joints will incur high-frequency vibration and dynamic errors of the system. Joints of existing analytical models are generally oversimplified as planar revolute hinges, which ignore the coupling effect of multi-clearance. It cannot proficiently predict the dynamic behavior of the driving mechanism with multi-clearance on the orbit. To address this problem, a typical 2K-H planetary gear joint model with multi-clearance coupling has been developed by considering radial clearance, backlash, tooth profile error, time-varying meshing stiffness, and damping. A dynamic model of a typical dual-axis driving mechanism is established to analyze the dynamic characteristics of multibody systems with planetary gear joints. The effects of rotational speed, radial clearance, backlash, and their coupling on the dynamic performance of the dual-axis driving mechanism under different driving modes are explored by numerical simulations. The results show that the coupling of radial clearance and backlash in joints have a significant influence on the dynamic performance of the system. Appropriate clearance design avails the dynamic pointing accuracy and tracking accuracy of the dual-axis driving mechanism. Full article

In this paper, the inequivalence of the direct-contact mechanisms and their equivalent four-bar linkages in jerk analysis is discussed. Kinematic analyses for three classical types of direct-contact mechanisms consisting of: (a) higher pairs with permanently invariant curvature centers, (b) higher pairs with suddenly changed curvature, and (c) higher pairs with continuously varying curvature are performed, respectively, through their representative case studies. The analyzed results show that the equivalent four-bar linkage cannot give a correct value of jerk for most situations in the three case studies. Subsequently, the concept of “equivalent six-bar linkage” for direct-contact mechanisms is proposed in order to discuss the infeasibility of the equivalent four-bar linkage for jerk analysis. It is found that the suddenly changed or continuously varying curvature of the higher pairs is not considered in sudden or continuous link-length variations of the equivalent four-bar linkage, which further leads to inconsistency between the angular accelerations of the coupler and the contact normal, and finally results in the infeasibility of the equivalent four-bar linkage for jerk analysis of most direct-contact mechanisms. It is also found that the concept of equivalent six-bar linkage could be applied to evaluate more higher-order time derivatives for most direct-contact mechanisms. The presented case studies and discussion can give demonstrations for understanding the inequivalence of the direct-contact mechanisms and their equivalent four-bar linkages in the aspect of jerk analysis. Full article
